Placing the ISDN Order Through Your Telephone Company
AT&T To order ISDN service for the AT&T 5ESS Custom switch,
5ESS supply the telephone company with the information
Custom provided in Table A-3.
Switch
Table A-3 Line Configuration for AT&T 5ESS Custom
Required Information
Line Type
Line Code
Interface Type
Directory Numbers
Maximum Terminals
Maximum B Channels
Actual User
Circuit-switched Voice
Circuit-switched Voice Channel
Circuit-switched Data
Circuit-switched Data Channel
Terminal Type
Display
Circuit-switched Voice Limit
Circuit-switched Data Limit
Voice or Data
Call Appearance Preference
Flexible Call Offering (FCO)
* The Directory Number, Circuit-switched Voice, and Circuit-switched Voice Limit
parameters should be set to 2 to allow both analog ports to be used simultaneously.
Otherwise, if those parameters are set to 1, the ISDN line can only place or receive one
call at a time.
† FCO (also referred to as Additional Call Offering) allows you to receive an incoming call
while a dual-channel Multilink PPP call is active. If you do not want this feature, which
may cost extra, FCO is not required.
Specification
Standard (2B+D) ISDN line with
point-to-point configuration
2B1Q
U interface with an RJ-45 jack
*
2
1
2
Yes
*
2
Any
2
Any
A (Basic Terminal)
Yes
*
2
2
Both
Idle
†
Yes
A-4
