Troubleshooting

Error codes

In the event of a system error, these codes will appear on the display.
1 Motor internal error
4
Cadence sensor error
5
Motor speed sensor malfunction
6
Brake lever cut-off sensor malfunction
7
Throttle malfunction
Most of the time, these errors can be resolved easily by checking the wiring connections
for the affected component. Call EBCC customer service, or see your dealer for more
information.

Charging issues

ISSUE: Charger LED indicator flashes red
LED flashes red after charging for a while:
 Battery is not responding to charging.
• The battery voltage is less than 25V, and does not rise above 25V after 30 minutes
of charging.
• The battery voltage is between 25V and 30V, and does not rise above 30V after one
hour of charging.
 Reset charging by unplugging the charger from the wall outlet, then
Solution
 Battery has not finished charging after 10 hours.
Solution  The battery may be damaged and should be inspected by your dealer.
LED flashes red immediately after being plugged in:
 The polarity between the charger and battery does not match.
 The battery or charger may be damaged. Stop using the battery and
Solution
 The output of the charger is short-circuited.
10/29/14
SYSTEM ERROR CODES
plugging it back in. If charging fails after a second attempt, the battery
or charger may need to be replaced. Bring them to your dealer for
inspection.
charger immediately, and bring them to your dealer for inspection.
