The display's electrical system functions

The display shows information about the bike's electric assist, and gives the rider access
to several important functions:

Assist level

The current assist level is shown on the display (assist level indicator).

Battery level

The battery level indicator shows the current charge level of the battery. Each bar
represents about 20% capacity.
The low battery warning indicator lights up when the battery has
charge.

Maintenance information

The maintenance indicator lights up when there is a system error. An error code shown
on the display helps to diagnose the problem. See "Error codes" below.

Control pad functions

The control pad is used to control the various functions of the bike and display.
The control pad's four buttons perform the following functions:
Increase assist level (1–4), or to switch to throttle pure mode "T".
Hold 2 seconds for backlight (and light set if installed).
Decrease assist level (4-1).
Turn bike on, one quick press
(turn on battery first, p.4)
Change cyclecomputer display, quick presses to cycle through the options
(after bike is on)
Set power assist to 0, one 2 second press
(no pedal or throttle assistance, just power for the display)
Turn power off, one 2 second press
(must be in assist level 0 first)
Activate cruise control.
The display backlight and any attached headlight/taillight is also controlled by the ambient
light sensor; they will automatically turn on in low light.
CONTROL PAD FUNCTIONS
less than 5% remaining
