Summary of Contents for Planet GST-802
- Page 1 User's Manual GST-802/802S GST-805A GST-806A15/806B15 GST-806A60/806B60 10/100/1000Base-T to 1000Base-LX/SX Smart Media Converter - 1 -...
-
Page 2: Fcc Warning
PLANET has made every effort to ensure that this User’s Manual is accurate; PLANET disclaims liability for any inaccuracies or omissions that may have occurred. -
Page 3: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION............................4 1.1 C ..............................4 HECKLIST 1.2 A 10/100/1000B 1000B -LX/SX S ........4 BOUT THE MART EDIA ONVERTER 1.3 F ..............................4 EATURES 1.4 S ............................5 PECIFICATION 1.5 P ........................... 7 RODUCT UTLOOK 2. -
Page 4: Introduction
The GST-80x series allows two type segments to connect easily. The Smart Media Converter can be used as a standalone unit when powered by it’s DC adapter or used as a slide-in module to the PLANET 19-inch Web Smart / Managed 16-Slots media converter chassis (MC-1600MR/MC-1600MR48 &... -
Page 5: Specification
Choice of fiber-connector from SC, LC, WDM, multi-mode / single-mode fiber / 1000Base-SX / LX mini GBIC module EMI standards complies with FCC, CE class A 1.4 Specification GST-806 GST-806 GST-806 GST-806B Model GST-802 GST-802S GST-805A Hardware Specification IEEE 802.3, 10Base-T IEEE 802.3u, 100Base-TX Standards IEEE 802.3ab, 1000Base-T IEEE 802.3z, 1000Base-SX/LX IEEE 802.3ah OAM... - Page 6 10Base-T: 2-pair UTP Cat. 3,4,5, up to 100 m Twisted-pair 100Base-TX: 2-pair UTP Cat. 5, up to 100 m Cable 1000Base-T: 4-pair STP Cat 5 up to 100m 50/125μm or 62.5/125μm multi-mode fiber cable, up to 220/550m. Fiber-optic 9/125μm single-mode cable, provides long distance for 10/20/30/40/50/70/120km Cable (vary on fiber transceiver or SFP module) LED Indicator...
-
Page 7: Product Outlook
1.5 Product Outlook Right View: there is one RJ-45 twisted-Pair jack (Auto-MDI/MDI-X), one fiber-optic connector (vary by model) and six LED indicators. Left View: there is one DC jack for DC 5V power adapter. GST-802 / GST-802S: GST-805A: - 7 -... - Page 8 GST-806A15 / GST-806B15 / GST-806A60 / GST-806B60: LED Indicators Color Status Indication Green Lights Off Power off. Lights On Power on – when +5V DC detected. Fiber LNK /ACT Green Lights Off Indicate the link through that port is not established. Lights On Indicate the link through that port is successfully established.
-
Page 9: Hardware Installation
2. HARDWARE INSTALLATION This product provides two different running speeds – 10/100/1000Base-T and 1000Base-LX/SX in the same device. This section describes the hardware installation of GST-80x. Before connecting any network device to the GST-80x, read this chapter carefully. 2.1 Stand-alone Media Converter Installation The GST-80x can use as a stand-alone Media Converter for Plug &... -
Page 10: Slide Media Converter Module Into Mc-1600Mr/R48 / Mc-1610Mr/Mr48 Chassis Installation
2.2 Slide Media Converter module into MC-1600MR/R48 / MC-1610MR/MR48 Chassis installation Step 1- Unscrew and pull out the GST-80x Media Converter board. Step 2- Remove a blank faceplate from an empty expansion slot on the front of the chassis. The GST-80x Media Con- verter board can be installed in any expansion slot. -
Page 11: Real Ethernet Environment Application
Step 4- Secure the GST-80x Media Converter board to the chassis by tightening the thumbscrew. 2.3 Real Ethernet environment application Fiber-Optic Networking for ISP, Enterprise, and Home The GST-80x provides advanced Media conversion technology- 10/100/1000Base-T and 1000Base-SX/LX interfaces to fulfill different kinds of demand as the current network grows and expanding. The GST-80x provides diverse fiber connect type options for different network applications. - Page 12 Figure 2: GST-80x FTTX application - 12 -...
-
Page 13: Manage The Media Converter
3. MANAGE THE MEDIA CONVERTER This product provides two different managed methods – configure through its DIP Switch or install into the central Web Smart / Management Media converter chassis for centralize management. This section describes how to managed the GST-80x through its DIP Switch and Web Smart / Management Media con- verter chassis. -
Page 14: Managed Media Converter Module Through Mc-1600Mr/R48 & Mc-1610Mr/R48 Chassis
3.2 Managed Media Converter module through MC-1600MR/R48 & MC-1610MR/R48 Chassis The Web Smart / Management Media Coverter Chassis that can control GST-80x through the management system, GST-80x can be controlled through Web Browser and terminal emulation program. The Web Smart Media Coverter Chassis-MC-1600MR/R48 will display out the status of GST-80x, also the Web Smart Media Coverter Chassis can control the function through the management system. - Page 15 The Management Coverter Chassis-MC-1610MR/R48 will display out the status of GST-80x, also the Management Media Coverter Chassis can control the function and OAM / Bandwidth control setting through the management system. Through the Management Media Coverter Chassis System, you can control the setting of GST-80X, such as device (Disable / Enable), LFP (Disable / Enable).UTP (Auto-negotiation / Manual), speed (10/100/1000Mbps) , duplex mode (Half / Full duplex mode), Flow control (Disable / Enable).
- Page 16 For easily to know the TP / Fiber port link status of oppsite device, the Management Media Coverter Chassis System provide OAM Setting that include TS-1000 OAM / IEEE 802.3ah OAM / Loop Back Test function. Also the bandwidth control function allow to define available transmit / receive bandwidth on TP / Fiber port of GST-80x. Item Description OAM Setting...
-
Page 17: Link Pass Through Function
4. LINK PASS THROUGH FUNCTION The LFP function includes the Link Fault Pass Through function (LLCF/LLR) and the DIP Switch design. LLCF/LLR can immediately alarm administrators the problem of the link media and provide efficient solution to monitor the net. The DIP Switch provides disable or enable the LFP function. -
Page 18: Link Loss Return (Llr)
4.2 Link Loss Return (LLR) The fiber ports of GST-80X have been designed with an LLR function for troubleshooting a remote connection. LLR works in conjunction with LLCF. When LLR is enabled*, the port’s transmitter shuts down when its receiver fails to detect a valid receive link. LLR should only be enabled on one end of the link and is typically enabled on either the unmanaged or remote device. -
Page 19: Troubleshooting
5. TROUBLESHOOTING This chapter contains information to help you solve issues. If the GST-80x is not functioning properly, make sure the GST-80x was set up according to instructions in this manual. The Power LED is not lit Solution: Check the power cable connection between power adapter and GST-80X. Why I connect GST-80x to device with 1000Base-LX/SX interface and the 1000Base-LX/SX fiber con- nection fail? Solution:... -
Page 20: Appendix A Networking Connection
APPENDIX A NETWORKING CONNECTION A.1 Switch‘s RJ-45 Pin Assignments 1000Mbps, 1000Base T Contact MDI-X BI_DA+ BI_DB+ BI_DA- BI_DB- BI_DB+ BI_DA+ BI_DC+ BI_DD+ BI_DC- BI_DD- BI_DB- BI_DA- BI_DD+ BI_DC+ BI_DD- BI_DC- A.2 RJ-45 cable pin assignment The standard RJ-45 receptacle/connector There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight cable and crossover cable connection: Figure A-1: Straight-Through and Crossover Cable Please make sure your connected cables are with same pin assignment and color as above picture before deploying the... -
Page 21: Cable Connection Parameter
5000* Notice: 1: Consult your local dealer for more about PLANET single mode fiber connectivity. 2. The Single-mode port (1000Base-LX port) of GST-802S, GST-805A, GST-806A15/B15 and GST-806A60/B60 is complied with LX 5 kilometers and provides additional margin allowing for a 10 / 15 / 60 kilometers Gigabit Ethernet link on single mode fiber. -
Page 22: Ec Declaration Of Conformity
EC Declaration of Conformity For the following equipment: *Type of Product : 10/100/1000Base-T to 1000Base-SX/LX Smart Gigabit Media Converter *Model Number : GST-802 / GST-802S * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address: 11F, No 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan, R.O.C. - Page 23 *Model Number : GST-805A * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address: 11F, No 96, Min Chuan Road Hsin Tien, Taipei, Taiwan, R.O.C. is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility Directive on (89/336/EEC,92/31/EEC,93/68/EEC).
- Page 24 (Tx: 1310/1550) - 15KM/60KM *Model Number : GST-806A15 / GST-806B15 / GST-806A60 / GST-806B60 * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address: 11F, No 96, Min Chuan Road Hsin Tien, Taipei, Taiwan, R.O.C. is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility Directive on (89/336/EEC,92/31/EEC,93/68/EEC).
