- Page 1 Gigabit Ethernet Converter 1000Base-SX/LX Multi-mode to Single-mode...
- Page 2 Copyright © PLANET Technology Corp. 2000. Contents subject to revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. The information in this manual is subject to change without notice. All other trademarks b elong to their respective owners.
- Page 3 1. Overview Thank you for purchasing PLANET GT-9XX family Gigabit Ethernet Fiber-optic Converter. This converter is used to convert one type media signal to other type equivalent that allows two type segments connect easily, efficiently and inexpensively. This converter can be used as a standalone unit or as a slide-in module to the 19”...
- Page 4 4. Product Outlook Right View (GT-922) Two fiber-optic connectors, multi-mode on the left, single-mode on the right and three LED indicators. For other GT-9XX, the outlook of fiber port is accordant to its related port, like. MT-RJ. Rear View (GT-9XX)
- Page 5 5. Installing the Converter Please follow these steps to install the converter: • Turn off the power of the device/station in a network to which the GT-9XX will be attached • Ensure that there is no activity in the network •...
- Page 6 (MHz * km) (meters) 1000Base-SX 62.5 62.5 1000Base-LX 62.5 5000* *Note: The Single-mode port (100Baes-LX port) of GT-922 is complied with LX 5 kilometers and provides additional margin allowing for a 10 kilometers Gigabit Ethernet link on single mode fiber...
- Page 7 The power jack of GT-9XX is with 2.5mm in the central post and required +5VDC power input. It will conform to the bundled AC- DC adapter and Planet’s Media Chassis. Should you have the problem to make the power connection, please contact your local sales representative.
