Planet SMART MEDIA CONVERTER GST-70X Specifications

1000Base-T to 1000Base-LX / SX Smart Media Converter
F
or the feature of plug and play and powerful smart function, PLANET
releases the new 1000Base-T to 1000Base-LX / SX Smart Media Converter
GST-70x series.
The GST-70x series Smart Media Converter provide Media conversion
between 1000Base-T and 1000Base-LX / SX interfaces, such as multi-mode
LC/SC connectors (220m/550m), single-mode LC / SC connector
(10/20/40/50/70/120km) and single fiber connector (WDM, 15/60km).
These connection options are able to for various applications.
The GST-70x series Smart Media Converter provide auto MDI/MDI-X on
their TP ports and use the DIP switch from the GST-70x to configure the
available smart functions, such as the auto-negotiation / force for fiber
interface and Link Pass Through function (LLCF / LLR). The LLCF sets default
on the board and works with LLR in diagnosed network connections, the
LLR function can also immediately alarm network administrators for the
media link issue and provide efficient solutions to monitor the entire
network.
The GST-70x series Smart Media Converter can allow two types of
segments connecting easily with efficient and cost effective. These Smart
Media converter can be use as a standalone when its power on by its DC
adapter. Or use as a slide-in module to the PLANET new 19-inch Web
Smart 16-Slots Media converter chassis (MC-1600MR/MC-1600MR48).
With this Web Smart Media converter chassis, the GST-70x are able to
manage and monitor status through the local RS-232 console and remote
web interface.
Data Sheet
1
Key Feature
•
Complies with IEEE 802.3ab, 1000Base-T and IEEE 802.3z
1000Base-LX / SX Ethernet standard
•
Provides one 1000Base-T port with RJ-45 connector and one
1000Base-LX / SX port with LC / SC / WDM connector for
supporting multi-mode or single-mode fiber optic cable
•
LED indicators for converter status
•
Provides DIP switch to set fiber (Auto-negotiation / Manual) and
LLR (Disable / Enable)
•
Auto-MDI / MDI-X for 1000Base-T port
•
Back-pressure, IEEE 802.3x compliant flow control and full wire
speed forwarding rate
•
Link Loss Return (LLR) switch on each fiber optic to aid in
troubleshooting remote network connections
•
Link Loss Carry Forward (LLCF) works with LLR in diagnosing
network connections
•
Manageable through Web Smart Media Converter Chassis System
•
Uses as a stand-alone device or with a chassis for up to 16
converter with redundant power supply for optional expanding use
•
EMI standards comply with FCC, CE class B
GST-70X
