Advantech AIMB-769 Startup Manual

AIMB-769 Socket LGA775 Intel
with VGA, 2 COM, Single LAN
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• AIMB-769 ATX IMB
• 1 AIMB-769 Startup Manual
• 1 Driver CD (user's manual is included)
• 2 Serial ATA HDD data cables
• 1 Serial ATA HDD power cable
• 1 I/O port bracket
• 1 jumper package
• 1 warranty card
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Products/acrobat/readstep2.
html (Acrobat is a trademark of Adobe)
Specifications

Standard SBC Functions

• CPU: LGA775 Intel
Core™ 2 Quad/Core™ 2 Duo/Penti-
®
um Dual Core/Celeron
®
• BIOS: AMI 16 Mb SPI BIOS
• FSB: 800/1066/1333 MHz
• Chipset: G41 with ICH7
• System memory: Up to 4 GB with two 240-pin DIMM
sockets. Supports dual channel DDR3 800/1066 SDRAM.
Note:
Due to the inherent limitations of PC architecture,
the system may not fully detect 4 GB RAM when
4 GB RAM is installed.
• SATA II Interface: Four on-board serial SATA II connec-
tors with a data transmission rate of up to 300 MB/s and
supporting Advanced Host Controller Interface (AHCI)
technology.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/intelligent-systems
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the AIMB-769 series Rev. A2
Part No. 2006076911
®
2nd Edition
October 2014
Core™2 Quad ATX
®
Specifications
• FDD interface: Supports one FDD
• Serial ports: Two RS-232 serial ports with DC power (+5
V or +12 V) support for industrial applications.
• Keyboard/mouse connector: Supports standard PS/2
keyboard and mouse.
• Watchdog timer: 255 level timer intervals.
• USB 2.0: Supports up to eight USB 2.0 ports.

VGA Interface

• Chipset: Chipset integrated VGA controller.
• Display Memory: Dynamically shared system memory
up to 352 MB.
• Resolution: Up to resolution 2048 x 1536 @ 75 Hz
refresh rate.

Ethernet interface

• Interface: 10/100/1000 Base-T
• Controller: LAN1: REALTEK RTL8111G-CG

Mechanical and Environmental

• Dimensions (L x W): 304.8 x 228.6 mm
• Power supply voltage: +3.3 V, +5 V, ±12 V, 5 VSB
• Power requirements: Maximum: +5 V at 1.76 A, +3.3 V
at 2.28 A, +12 V at 4.7 A, 5 VSB at 0.19 A, (Intel
2 Quad Q9650 3.0 GHz, two 1GB DDR3 1066 MHz
SDRAM)
• Operating temperature: 0 ~ 60 °C (depending on CPU)
• Weight: 0.5 Kg (weight of board)
Jumpers and Connectors
The board has a number of jumpers that allow you to con-
figure your system to suit your application. The table below
lists the function of each of the jumpers and connectors.
Connector/Jumper list
Label Function
CMOS1 Clear CMOS
JWDT1 Watchdog Timer Output Option
FDD1 FDD connector
LAN1_USB34 LAN1 / USB port 3, 4
VGA1 VGA connector
COM12 Serial port: RS-232
AIMB-769 Startup Manual 1
Core
™
®
