Advantech AIMB-760 Startup Manual

AIMB-760 Socket LGA 775 Intel® Pentium® 4 /
Celeron® D 800 MHz FSB Industrial ATX
Motherboard with PCI-E, DDR2 and Dual GbE
Packing List
Before you begin installing your card, please make
sure that the following materials have been shipped:
• AIMB-760 Pentium® 4 / Celeron® D processor
based industrial motherboard
• 1 AIMB-760 startup manual
• 1 CD with driver utility and
manual
• 1 FDD cable
• 2 Ultra ATA 66/100 HDD cables
• 2 Serial ATA HDD data cable
• 2 Serial ATA HDD power cable
• 1 ATX 12 V power converter
cable
• 1 COM port cable kit
• 1 I/O port bracket
• 1 Jumper package
• 1 Warranty card
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/read-
step.html (Acrobat is a trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the AIMB-760 series Rev. A1
Part No. 2002076011
Printed in Taiwan
Specifications
Standard SBC Functions
• CPU: Intel LGA 775 Pentium 4® up to 3.8 GHz, Cele-
ron® D up to 3.06 GHz, FSB 533/800 MHz
• BIOS: Award 4 Mb flash memory BIOS
• Chipset: Intel 915GV with ICH6
• System Memory: Up to 4 GB; four 240-pin DIMM sock-
ets. Supports dual channel DDRII 400/533 SDRAM.
Note:
p/n:1700340640
p/n: 1701400452
• SATA/IDE Interface: Four on-board serial ATA connec-
tors with a data transmission rate of up to 150 MB/s
p/n: 1700071000
supporting Advanced Host Controller Interface (AHCI)
p/n: 1703150102
technology. One IDE hard disk drive or two enhanced
IDE devices. Supports PIO mode 4 (16.67 MB/s data
p/n:170304015K
transfer rate) and ATA 33/66/100 (33/66/100 MB/s data
transfer rate) BIOS enabled/disabled.
p/n: 1701090401
• FDD interface: Supports one FDD
• Serial ports: Two serial RS-232 ports
p/n: 1960004027
• Parallel port: One parallel port, supports SPP/EPP/
p/n: 9689000068
ECP mode
p/n: 2190000902
• Keyboard/mouse connector: Supports one standard
PS/2 keyboard and mouse
• Watchdog timer: 255 level timer intervals
• USB 2.0: Supports up to eight USB 2.0 ports
VGA Interface
• Chipset: Chipset integrated VGA controller
• Display memory: Dynamically shared system memory
up to 128 MB
• Resolution: Up to 2048 x 1536 @ 85 MHz refresh rate
Ethernet Interface
• Single 10/100/1000Base-T: Broadcom BCM5721 x 1
• Dual 10/100/1000Base-T: Broadcom BCM5721 x 2
Mechanical and Environmental
• Dimensions (L x W): 304.8 x 243.8 mm
• Power supply voltage: +5 V, ± 12 V
• Power requirements: Maximum: +5 V @ 6.64 A, +12 V
@ 12.59 A (3.4 GHz Intel Pentium 4 with 800 MHz FSB,
2 x 256 MB, 2 x 512 MB DDRII 533 SDRAM)
• Operating temperature: 0 ~ 60° C (depending on
CPU's speed and cooler solution)
2nd Edition
• Weight: 0.5 kg (weight of board)
January 2006
Due to the inherent limitations of PC architec-
ture, the system may not fully detect 4 GB
RAM when 4 GB RAM is installed.
AIMB-760 Startup Manual 1
