Advantech AIMB-762 Startup Manual

AIMB-762 Socket LGA 775 Intel® Pentium® D /
Pentium® 4 / Celeron® D 800 MHz FSB ATX
Motherboard with PCI-E, DDR2 and Dual GbE
Packing List
Before you begin installing your card, please make
sure that the following materials have been shipped:
• AIMB-762 Pentium® 4 / Celeron® D processor
based industrial motherboard
• 1 AIMB-762 startup manual
• 1 CD with driver utility and
manual
• 1 FDD cable
• 2 Ultra ATA 66/100 HDD cables
• 2 Serial ATA HDD data cable
• 2 Serial ATA HDD power cable
• 1 ATX 12 V power converter
cable
• 1 COM port cable kit
• 1 I/O port bracket
• 1 jumper package
• 1 warranty card
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/read-
step.html (Acrobat is a trademark of Adobe).
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the AIMB-762 series Rev. A1
Part No. 2002076210
Printed in Taiwan
Specifications
Standard SBC Functions
• CPU: LGA 775 Pentium D/Pentium 4/Celeron D up to
3.2/3.8/3.06 GHz, FSB 533/800 MHz.The CPU has
built-in 2 x 1024KB/2 x 2048KB (for Pentium D CPU),
1024KB/2048KB (for Pentium 4 CPU), 256KB/512 KB
(For Celeron D CPU) full-speed L2 cache.
• BIOS: Award 8 Mb flash memory BIOS
• Chipset: Intel 945G with ICH7R
• System Memory: Up to 4 GB; four 240-pin DIMM
sockets. Supports dual channel DDR2 400/533/667
p/n:1700340640
SDRAM.
p/n: 1701400452
Note:
p/n: 1700071000
p/n: 1703150102
• SATA2/IDE Interface: Four on-board serial ATA2 con-
p/n:170304015K
nectors with a data transmission rate of up to 300 MB/s
supporting Advanced Host Controller Interface (AHCI)
technology. One IDE hard disk drive or two enhanced
p/n: 1701090401
IDE devices. Supports PIO mode 4 (16.67 MB/s data
p/n: 1962015680
transfer rate) and ATA 33/66/100 (33/66/100 MB/s data
transfer rate) BIOS enabled/disabled.
p/n: 9689000068
• FDD interface: Supports one FDD
p/n: 2190000902
• Serial ports: Two serial ports, COM1 is of RS 232;
COM2 is of RS 232/422/485.
• Parallel port: One parallel port, supports SPP/EPP/
ECP mode
• Keyboard/mouse connector: Supports one standard
PS/2 keyboard and mouse
• Watchdog timer: 255 level timer intervals
• USB 2.0: Supports up to eight USB 2.0 ports
VGA Interface
• Chipset: Chipset integrated VGA controller
• Display memory: Dynamically shared system memory
up to 224 MB
• Resolution: Up to 2048 x 1536 @ 75 MHz refresh rate
Ethernet Interface
• Single 10/100/1000Base-T: Intel® 82573
• Dual 10/100/1000Base-T: Intel® 82573 x 2
Mechanical and Environmental
• Dimensions (L x W): 304.8 x 243.8 mm
• Power supply voltage: +5 V, ± 12 V
• Power requirements: Maximum: +5 V at 3.10 A, +3.3V
at 1.54A, +12V at 9.90 A (Intel Pentium D 3.2GHz (800
MHz FSB), 4 x 1GB DDR2 667 SDRAM)
• Operating temperature: 0 ~ 60° C (depending on
CPU)
• Weight: 0.5 kg (weight of board)
1st Edition
March 2006
Due to the inherent limitations of PC architec-
ture, the system may not fully detect 4 GB
RAM when 4 GB RAM is installed.
