BA72A
LCD TFT 12.1" Flat Screen
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BA72A and is the answer not in the manual?

Questions and answers

Related Manuals for Wincor Nixdorf BA72A

Summary of Contents for Wincor Nixdorf BA72A

  • Page 1 BA72A LCD TFT 12.1" Flat Screen User Manual...
  • Page 2 Published by Wincor Nixdorf International GmbH D-33094 Paderborn Bestell-Nr./Order No.: 01750022256B Printed in Singapore...
  • Page 3 BA72A LCD TFT 12.1" Flat Screen User Manual Edition July 2002...
  • Page 4 Microsoft Corporation. ® BEETLE is a registered trademark of the Wincor Nixdorf International GmbH Copyright © Wincor Nixdorf International GmbH, 2002 The reproduction, transmission or use of this document or its contents is not permitted without express authority.

  • Page 5: Table Of Contents

    From Point-of-Sale to Point-of-Service ............1 Advantages at a Glance................2 Unpacking and checking the Delivery Unit ..........3 About this Manual..................3 BA72A Components ................. 4 Screen Module .................... 4 LCD- Controller-A TFT/PCI ................. 5 TFT-Controller-A ..................6 Capacative Touch Screen (Option) ............8 General .....................
  • Page 6 How to Operate ..................22 Cleaning Instructions................22 Installing and Securing the Screen into Place ........23 Installing the BA72A into Place (Table Top Version) ........23 Securing the screen into Place (Tubular Stand Version) ......24 Adjustable Screen Angle ................25 Ergonomic Terminal Workplace ..............26 Installation ....................27...
  • Page 7 Internal Connecting Socket ..............46 External Connecting Socket ..............47 Technical Data ..................48 Touch Screen (optional)................48 TFT/ LCD Screen ..................49 BA72A ....................... 50 Current Consumption ................51 TFT Controller ..................51 Screen Module..................51 COM6/7/8....................51 Power Consumption .................. 51 LCD-Controller-A TFT/PCI ................

  • Page 8: Introduction

    By using the BA72A you are provided with a terminal-orientated, ergonomi- cal and customer-friendly cashier’s workplace. The BA72A is the enhanced version of the BA72. It is equipped with the PanelLink technology with the new highlights: cable distance support up to 5m, flexible All-in-One cable for Touch Screen, loudspeaker and supply volt- age.

  • Page 9: Advantages At A Glance

    The low-energy, flickerfree and radiation-free colour monitor of the BA72A is an Active-Matrix-Display in TFT-technology (Thin Film Transistor). Therefore, it is especially suited for multimedia applications as it offers brilliant colour representation, an excellent contrast ratio and a high dis- play speed.

  • Page 10: Unpacking And Checking The Delivery Unit

    If damage has occurred during shipping or if the package contents do not match the delivery note, immediately inform your Wincor Nixdorf sales outlet. Transport the device only in its original packaging (to protect it against im- pact and shock).

  • Page 11: Ba72A Components

    BA72A Components Screen Module The screen module represents the main unit of the BA72A. It comprises of a TFT-LCD colour screen, the TFT-interface and an inverter that genera- tes the voltage for backlighting the screen. As an option the screens are available with Touch Screen including a loudspeaker.

  • Page 12: Lcd- Controller-A Tft/Pci

    LCD Controller “Stretching” is only possible when a separate TFT conroller is used. So, when operating with the BA72A and the integrated TFT controller at the Media GXm CPU, “stretching” is not possible. Here you will see a black margin around the centered picture.

  • Page 13: Tft-Controller-A

    TFT-Controller-A TFT-Controller-A TFT-Controller-A The TFT-controller-A is a plug-in-controller with a PCI-interface. There are two connections for a 40-pin MDR connector with integrated COM5 output a 9-pin DSUB female (for COM6) COM5 and COM6 are only ready for operation when the optional COM board is used.
  • Page 14 TFT-Controller-A Panel of TFT- controller-A COM5/ COM6 Speaker connector BA72A connector COM6 incl. COM5, LCD interface and loudspeaker MDR connector DSUB socket Board layout (TFT-controller-A) GB - 7...

  • Page 15: Capacative Touch Screen (Option)

    Capacative Touch Screen (Option) General The TFT Touch Screen works according to the principle of a change in analog capacitance. It has a glass screen with a transparent, thin-film overlay on the surface. This is fully sealed and protected by a further layer of clear glass.

  • Page 16: How To Operate

    Touch Screen Anti Reflective Etched Surface and protection ClearTek Glass Overcoat Conductive Coating Protective Noise Shield The programming interface of the screen is identical to the mouse inter- face. Touch Screen Touch Screen and Sleep Mode Using the Touch Screen with a BEETLE Pentium CPU, an entry via touch during sleep mode may lead to a faulty input.

  • Page 17: Brightness And Loudness

    Touch Screen Touching the touch glass has the same effect as clicking the left mouse button. You only need to apply a little pressure with the fingertip. In this ca- pacitive process only fingertip contact is recognized. The screen does not react in any way if touched, for example, with a pencil or a glove.

  • Page 18: Com Board For Touch Screen

    COM Board COM Board for Touch Screen COM Board The COM Board is an additional board for the TFT-controller-A with an ISA bus interface that has 2 or 4 COM interfaces (COM5, 6, 7, 8). COM5 and COM6 are linked to the BA72 controller via a plug connector. COM5 is a reduced COM interface for RxD and TxD signals and is intended for the use of the (optional) touch function.

  • Page 19: Com Interface Interrupts

    COM Board COM Interface Interrupts COM5 COM6 COM7 COM7-8 COM6-8 Interrupt IRQ9 IR10 IRQ10 IR11 IRQ11 IR12 IRQ12 IR15 IRQ15 For the default setting the jumper I1, I2, I8, IR11, IR12 and IR15 are active (closed). The interrupts IRQ9 and IRQ10 are added for PC application only. For a correct reproduction of the interrupt signals it is necessary that the jumper IR9 to IR15 are not activated.

  • Page 20: Assignment Of Com Port Addresses And Interrupts

    COM Board Assignment of COM port addresses and interrupts (installation details) Ensure that there is no conflict of hardware port addresses or interrupt re- quests (IRQs) used by your system and the AT COM Board! Essentially the AT COM Board has been designed to be configurable for a non-shared IRQ9, IRQ10, IRQ11, IRQ12, or IRQ15 for COM5 and a sha- red IRQ9, IRQ10, IRQ11, IRQ12, or IRQ15 for COM6,7,8 and even COM5.

  • Page 21: Irq12, Most Likely Conflict Mouse Port Or Ps/2 Mouse

    Nixdorf PCD product line e. g. is delivered with this type of mouse. Some systems allow to disable the mouse port in the BIOS Setup, e.g. those of the Wincor Nixdorf PCD product line. IRQ15, most likely conflict IDE controller...

  • Page 22: Using Shared Interrupts For Com Ports With Windows Nt

    COM Board The AT COM Board manual numbers the COM ports from 5 to 8. The ori- gin of this numbering is from the BEETLE, which has COM1 to COM4 on the motherboard. It is recommended for consistency, that you use this numbering also, regardless whether you have e.g.
  • Page 23 COM Board be impossible for hardware reasons! The problem is, that in such a case on the AT bus two different hardware instances would be fighting for the same IRQ! Refer to the technical information about your system for the details you need! If you configured COM ports to share a common interrupt and ‘Permit Sha- re’...

  • Page 24: Using Shared Interrupts For Com Ports Under Windows 95

    COM Board Using shared interrupts for COM ports under Windows 95 Under Windows 95, sharing COM ports doesn’t require special provisions other than correctly specifying the resources used in the Device Manager. However, in addition to avoid port address conflicts, you must ensure that no two different pieces of hardware on the AT bus are fighting for the same IRQ! Using COM ports under Windows 3.x...
  • Page 25 COM Board Interrupt Jumper IO Jumper IO 3 I 16 IO 1 Interrupt Request IR 9 IR11 IR15 IR10 IR12 COM 5 / COM 6 COM7 COM8 Board layout COM board GB - 18...

  • Page 26: Lcd-Tft Adapter A-Mediagxm

    LCD-TFT Adapter A-MediaGXm LCD-TFT Adapter A-MediaGXm LCD-TFT Adapter A-MediaGXm In the case of the BEETLE with GXm CPU the TFT adapter can be connec- ted with GXm CPU without TFT con- troller and without COM board. The LCD TFT adapterA is a submodule of the GXm CPU which is necessary for the connecting process.
  • Page 27 LCD-TFT Adapter A-Celeron LCD-TFT Adapter A-Celeron LCD-TFT Adapter A-Celeron In the case of the BEETLE with Ce- leron CPU the TFT adapter can be connected with the Celeron CPU wi- thout TFT controller and without COM board. The LCD TFT adapterA is a submodule of the Celeron CPU which is necessary for the connec- ting process.

  • Page 28: Resistive Touch Screen (Option)

    Resistive Touch Screen (Option) General The resistive TFT Touch Screen is constructed of a hard-coated polyester topsheet that is overlaid on a conductively-coated glass layer. Voltage is applied to the topsheet. As the user touches the screen, the topsheet com- presses into contact with the glass layer, and current flows to the four cor- ners in proportion to the distance from the edge.

  • Page 29: How To Operate

    Touch Screen Construction of the resistive Touch Screen: Hard-coated poly- ester topsheet Adhesive Glass substrate with spa- cer dots How to Operate Touching the touch screen has the same effect as clicking the left mouse button. You only need to apply a little pressure with the fingertip. In this re- sistive process not only fingertip contact is recognized.

  • Page 30: Installing And Securing The Screen Into Place

    The screens can be installed either with or without attached operating elements, as a table top terminal or on a tubular stand. Securing into Place Installing the BA72A into Place (Table Top Version) Remove the footed stand and screen element from the card- board packaging.

  • Page 31: Securing The Screen Into Place (Tubular Stand Version)

    Tubular Stand Version Tubular Stand Version Now fasten the screw on the footed stand into place again using the crosstip screw- driver. Ensure that the screw is in the correct position. Securing the screen into Place (Tubular Stand Version) The system has been designed for securing into place on a tubular stand, with a tube with 35.2 ±...

  • Page 32: Adjustable Screen Angle

    Adjustable Screen Angle Adjustable Screen Angle Adjustable Screen Angle The BA72A is fitted with a joint on the rear. You can optimize the angle of the screen depending on the viewing and lighting conditions. loose tight Use a screwdriver to...

  • Page 33: Ergonomic Terminal Workplace

    Ergonomic Terminal Workplace Ergonomic Terminal Workplace Ergonomic Terminal Workplace Please observe the following when setting up your terminal workplace: Avoid direct glaring and reflective glaring. Install the device with a viewing direction that is parallel to the windows. Avoid reflective glaring caused by electric light sources.

  • Page 34: Installation

    Installation Installing the Controller in the BEETLE First ensure that the controller is switched off and the mains supply plug has been pulled out. Remove the housing upwards. Take care in doing so that you do not tilt or jam the housing in any way.
  • Page 35 Installing the Controller in the BEETLE /L Installation Metal tracks Speaker connector In order to be able to install the TFT controller, you must first remove the metal panel that covers the free slots by loosening the screw. Set the jumper for the I/O addresses and the interrupt requests on the COM board.

  • Page 36: Connecting The Speaker Cable

    Installation Connecting the Speaker Cable Connecting the Speaker Cable Connecting the Speaker Cable Remove the speaker cable from the BEETLE-CPU by simply unplugging the connector. The BEETLE /L speaker is then inactive. The 4-pin plug connector is next to the RAM module. Use the TFT speaker TFT Controller cable (delivered with...

  • Page 37: Connecting The Ba72A To The Beetle /20

    Connecting the BA72A to the BEETLE /20 The hardware installation is carried out according to the installation of the BA72A to the BEETLE /L. When installing the TFT controller, you have op- tionally two further COM interfaces (COM7 and COM8) at your disposal.

  • Page 38: Connecting The Ba72A To The Pc

    “Installing the TFT adapter" at the end of this chapter. If a TFT adapter-A is installed, a BA72A can be connected to the BEETLE /M without assigning a slot. The connection to the system is effected via a 40-pin data cable.

  • Page 39: The Jumper Layout Of The Gxm Board

    Connecting the BA72A to the BEETLE/M Installation The touch function with a LCD TFT adapter-A has to be activated via a jumper (see also jumper settings). The COM2 interface has to be covered and may no longer be used externally.

  • Page 40: Com2 With Gxm Board

    Installation Connecting the BA72A to the BEETLE/M COM2 with GXm Board COM2 for peripherals parking position for jumper COM2 for touch function using the TFT adapter If the BEETLE is delivered with TFT adapter with touch function, the jum- per is already set ex works.

  • Page 41: The Jumper Layout Of The Celeron Board

    Connecting the BA72A to the BEETLE/M Installation The Jumper layout of the Celeron Board PS2/Mouse 32KB or 512KB 128KB BIOS XILINX 49F002T KYB/E PROG COM4* SuperI/O PC97317 AD1816AJS COM3* PCI/ISA IRQ I PT PCI-ONBOARD COM2*/I COM2* COM1 CELERON 82443BX 69000...

  • Page 42: Com2 With Celeron Board

    Installation Connecting the BA72A to the BEETLE/M COM2 with Celeron Board COM2 for peripherals COM2 for touch function ussing a TFT adapter If the BEETLE is delivered with TFT adapter with touch function, the jum- per is already set ex works.

  • Page 43: Connecting The Cable

    Connecting the BA72A to the BEETLE/M Installation Connecting the cable The data cable is to be connected with the 40-pin connector of the TFT adapter. Take care that the thickening of the cable (Ferrit) is principally po- sitioned on the side of the TFT adapter.

  • Page 44: Installing A Lcd-Tft Adapter A

    Installation TFT adapter Now plug in the cable until it snaps in (see il- lustration). When removing the cable press on the connector release. Installing a LCD-TFT Adapter A Never open the BEETLE /M when the circuit is switched on. Plug in the TFT adapt- er on the CPU module via the sub module as...

  • Page 45: Inserting The Cable

    , and then remove it from the guide rail. PULL PULL Insert the 40-pin BA72A cable of the keyboard. The cable will be carried in a cur- ve from the small co- ver of the screen module to the cable co- ver.

  • Page 46: Releasing The Cable Connection

    Installation Releasing the Cable Connection Releasing the Cable Connection Releasing the Cable Connection Never remove a cable from a connector socket by simply pulling on the cable. Always remove the cable by the connector housing. Please follow the instructions below when removing cables: Turn off all switches to the mains and electrical equipment.

  • Page 47: Software Installation

    Software Installation The software installation refers to the installation of corresponding display drivers; the installation of the touch screen comprises the allocation of re- sources for the COM interfaces, too. For this, corresponding diskettes are available. The installation of display drivers is normally done after a VGA card is re- placed with the TFT controller.

  • Page 48: Software Interfaces

    Touch Screen Software Interfaces Touch Screen Touch Screen Touching the screen corresponds to press the left mouse key. The touch screen programming interface is identical to that of the mouse interface. Touch Screen and Sleep Mode Using the Touch Screen with a BEETLE Pentium CPU, an entry via touch during sleep mode may lead to a faulty input.

  • Page 49: Automated Logic Diagram (Ald) And Pin Assignments

    Touch Screen Automated Logic Diagram (ALD) and Pin Assignments Bildschirmm Screen module Inverter for two Backlights TFT-Interface TFT-Display Touch Screen (Option) Touch Screen Controller (Option) Loudspeaker (Option) Signals: TFT-PLINK, COM5, Loudspeaker (Option) 40pin. MDR TFT Controller-A (PCI Interface) 40pin MDR COM8* COM Board (ISA Interface) COM6...

  • Page 50: Interface

    Automated Logic Diagram Touch Screen Interface Automated Logic Diagram The LCD interface is connected to the TFT controller via a 40-pin cable. The inverter, LCD display, touch screen controller and beeper are connec- ted to this interface in the TFT screen module. Inverter (High-Voltage Generator) Inside the TFT, the high voltage needed for backlighting the LCD display is generated by the inverter!

  • Page 51: Pin Assignments

    Controller Pin Assignments Pin Assignments Pin Assignments Controller BA72A Connectors of the 40-pin TFT Interface PIN # Signal PIN # Signal HUOUT RXCN RXCP P5VLCD P5VLCD RX0N RX0P FPEN RxD1 TxD1 P12VLCD P12VLCD RXIN RXIP P12VLCD RX2N RX2P GB - 44...

  • Page 52: Com 6 Interface Of The Controller

    Pin Assignments Controller COM 6 Interface of the Controller PIN # signal P12VF RxD2 TxD2 DTR2 GNDF1 DSR2 RTS2 CTS2 P5VF Internal Speaker Connector for Controller and BEETLE-CPU PIN # signal n.c. n.c. n.c. HUIN COM7 and COM8 Interfaces of the Controllers for the BEETLE /XL (Option) Pin Assignments Controller These plug connectors are available only for the BEETLE /XL and...

  • Page 53: Internal Connecting Socket

    Controller Pin Assignments Internal Connecting Socket PIN# COM7 COM8 P5VF P5VF GNDF GNDF DCD3 DCD4 CTS3 CTS4 DTR3 DTR4 RTS3 RTS4 TxD3 TxD4 DSR3 DSR4 RxD3 RxD4 P12VF P12VF GNDF GNDF GB - 46...

  • Page 54: External Connecting Socket

    Pin Assignments Controller External Connecting Socket PIN# with power supply w/o power supply +12V GB - 47...

  • Page 55: Technical Data

    Technical Data The following operating conditions are valid for a BA72A TFT that is fitted with all the available modules (LCD flat screen, touch screen): IEC 721 3/3 Class 3K3 Climate class Operating ° ° C - + 40 temperature 5% - 85% Absolute humidity 1g/m³...

  • Page 56: Tft/ Lcd Screen

    Vertical (Hz) Horizontal 800 pixel (SVGA) Solutions Vertical 600 lines (SVGA) Colour RGB 16, 256, 64k BA72A: 0.30 mm x 0.30 mm Pixel Format 5V from interface Power Supply TFT, 18 Bit LCD Technology BA72A: approx. 190 cd Brightness Reading Angle +/- 35°...

  • Page 57: Ba72A

    BA72A Technical Data BA72A Screen size 12.1" (30,7 cm) Active screen size 246 mm x 185 mm (horizontal x vertical) Cable length 3 m / 5m Dimension Display Housing Dimensions without foot. Stand/Hinge 315 x 248 x 53 mm (W x H X D) Dimension Display Housing with foot.

  • Page 58: Current Consumption

    Technical Data Current Consumption Current Consumption Current Consumption TFT Controller 370 mA + 5V 50 mA +12V 50 mA -12V Screen Module Consisting of an LCD display, touch screen incl. controller, inverter, inter- face. Please check whether the system offers enough power to supply the screen module.

  • Page 59: Lcd-Controller-A Tft/Pci

    1. 40-pin MDR connector for LCD interface, touch screen and loudspeaker Connections 2. 9-pin socket for COM6, if COM Board exists BA72A cable 40-pin connector, EMC protected 2.5 W Power consumption Current consumption 5V 370 mA, ±12V 50 mA / 30 mA...

  • Page 60: Com Board

    TFT controller Connection for COM7/8 and COM7*/8* Interface for BEETLE /XL , /M and /20, COM7 and COM8 PC standard or Wincor Nixdorf retail (optional) standard with connector adapter for 9pin DSUB connector or socket GB - 53...

  • Page 61: Manufacturer's Declaration And Approval

    Manufacturer’s Declaration and Approval General Authorization This device fulfills the requirements of the EEC standard 89/336/EWG “Electromagnetic Compatibility”. Therefore, you will find the CE mark on the device or packaging. FCC-Class A Declaration This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 62: Tested Safety

    TV interference and faults that are caused by unauthorized changes that have been made to the devices. Furthermore, cables or other devices that have not been approved by Wincor Nixdorf may not be connected to the device. The user is responsible for any faults and interference that are caused as a result.

  • Page 63: Safety Instructions

    BEETLE or PC should be removed, and the Wincor Nixdorf customer service should be contacted. If the LCD display element is broken and the liquid crystal solution...

  • Page 64: Instructions For Maintenance

    Wincor Nixdorf customer service. Recycling Environmental protection does not begin when the time has come to dispo- se of the BA72A; it begins with the manufacturer. This product was de- signed according to our internal norm “Environmental conscious product design and development”.
  • Page 65 Wincor Nixdorf guarantees the environmentally safe disposal of these parts in a Recycling Center, which is certified pursuant to ISO 9001. So don’t simply throw your BA72A on the scrap heap when it has served its time, but take advantage of the environmentally smart up-to-date...

  • Page 66: Appendix
