- Page 1 BA72R 12" TFT LCD Monitor Operating Manual...
- Page 2 Offenders will be liable for damages. All rights, including rights created by patent grant or registration of a utility model or design, are reserved. Delivery subject to availability; technical modifications possible. Copyright© Wincor Nixdorf International GmbH, 2007...
- Page 3 BA72R 12" TFT LCD Monitor Operating Manual Edition Oct 2009...
-
Page 4: Table Of Contents
Resistive Touch Screen (Option)..............13 General ....................13 Construction of the resistive Touch screen...........14 How to Operate ...................14 Cleaning Instructions ................14 Installing the BA72R (Table Top version) ..........15 Securing the screens (Tubular Stand Version) .........17 Adjustable Screen Angle................18 Ergonomic Terminal Workplace ...............19 01750140683 F... - Page 5 Color setting ..................28 Image setting..................30 Tools menu..................31 Audio setting..................33 Exit OSD Menu..................34 Technical Data................35 Models.....................35 Operating Conditions ................36 Touch Screen (optional)................36 Display Specification................37 Display Mode...................39 Interface Definition ..............40 VGA interface ..................40 Touch Interface..................41 BA72R LCD Display – Operating Manual 01750140683 F...
-
Page 7: Manufacturer's Declaration And Approval
Modifications not authorized by the manufacturer may void users authority to operate this device. This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NBM-003 du Canada. BA72R LCD Display – Operating Manual 01750140683 F... -
Page 8: Tested Safety
The BA72R has been awarded the GS symbol for "Gepruefte Sicherheit" (test safety). BA72R fulfills the requirements for ergonomy according to ISO13406-2 Additionally, the BA72R has also been awarded to cUL- and UL- symbol. User Information Wincor Nixdorf (WN) does not accept responsibility for radio and TV interference and faults that care caused by unauthorized changes that have been made to the devices. -
Page 9: Safety Instructions
In case of emergencies (e.g. damaged housing, liquid or foreign objects getting into the device), the device should be switched off immediately, the mains plug of the BEETLE or PC should be removed, and the Wincor Nixdorf customer service should be contacted. -
Page 10: Instructions For Maintenance
Please observe the maintenance and cleaning instructions for each of the BA72R components. These instructions can be found in their respective chapters. -
Page 11: Recycling
Nixdorf guarantees the environmentally safe disposal of these parts in a Recycling Center, which is certified pursuant to ISO 9001. So don’t simply throw your BA72R on the scrap heap when it has served its time, but take advantage of the environmentally smart up-to-date recycling methods! -
Page 12: Introduction
Introduction Introduction The BA72R is a new addition to our range of flat-panel display. This display features a standard analog RGB interface allowing connection to PC's CRT output. There is no need to add a digital graphics adapter. Using the BA72R provides you with a terminal-orientated, ergonomic and customer-friendly cashier’s workplace. -
Page 13: Advantages At A Glance
Controllers and data cables, necessary for operation, can be ordered separately. If damage has occurred during shipping or if the package contents do not match the delivery note, promptly inform your Wincor Nixdorf sales outlet. Transport the device only in its original packaging (to protect it against impact and shock). -
Page 14: Ba72R Components
The TFT LCD flat screen is an SVGA 12.1” that is flicker-free and free of radiation and has only a low heat emission. The BA72R has a native resolution of 800 x 600, but it features high-quality advanced auto-scaling display controllers that allow scaling from VGA to SVGA. -
Page 15: Power Adapter And Power Cord
Canada Germany Japan Taiwan BSMI China For other countries not mentioned in the above list, please check with the local authority. Cables Standard VGA cable, 1.8m Touch Cable, 1.8m (option) BA72R LCD Display – Operating Manual 01750140683 F... -
Page 16: Capacitive Touch Screen (Option)
“recognized” by the change in capacitance. Because this takes place very quickly - 15 milliseconds after being touched - the Touch Screen is optimally equipped for a number of different requirements and applications. 01750140683 F BA72R LCD Display – Operating Manual... -
Page 17: Touch Screen And Sleep Mode
“waking up”. For these reasons it is not recommended to set the sleep mode. For details please read the chapter “BIOS Setup” in the BEETLE User Guide. BA72R LCD Display – Operating Manual 01750140683 F... -
Page 18: How To Operate
9 to 10 are not recommended. Cleaning with water and isopropyl alcohol is as well possible. Do not use solvents containing acetic acid. Use a soft, fine-meshed cloth to clean the surface. Dampen the cloth slightly and then clean the screen. 01750140683 F BA72R LCD Display – Operating Manual... -
Page 19: Resistive Touch Screen (Option)
“X” and “Y” touch coordinates from the stable glass layer, the accuracy and operation of the touch screen is unaffected by damage to the top sheet caused by extended use or neglect. BA72R LCD Display – Operating Manual 01750140683 F... -
Page 20: Construction Of The Resistive Touch Screen
Do not use solvents containing acetic acid or methylene chloride. Use a soft, fine- meshed cloth to clean the surface. Dampen the cloth slightly and then clean the screen. 01750140683 F BA72R LCD Display – Operating Manual... -
Page 21: Installing The Ba72R (Table Top Version)
Installation and Securing the Screen into Place The screens can be installed either with or without attached operating elements, as a table-top terminal or on a tubular stand. Installing the BA72R (Table Top version) Remove the footed stand and screen element from the cardboard packaging. - Page 22 Now fasten the screw on the footed stand into place again using crosstip screw- driver. Ensure that the screw is in the correct position. Ensure that the screw is in the correct position. 01750140683 F BA72R LCD Display – Operating Manual...
-
Page 23: Securing The Screens (Tubular Stand Version)
Insert the joint of the screen element into the mounting stand. Do not remove the connecting part! Tighten the screw using the crosstip screwdriver. BA72R LCD Display – Operating Manual 01750140683 F... -
Page 24: Adjustable Screen Angle
BA72R Components Adjustable Screen Angle The BA72R is fitted with a joint on the rear. You can optimize the angle of the screen depending on the viewing and lighting conditions. Use a screwdriver to set the twisting force of the BA72R on the adjusting nut. -
Page 25: Ergonomic Terminal Workplace
Avoid reflective glaring caused by electric light sources. Position the screen within a preferred and permitted range of vision, so that you can look vertically into the screen. BA72R LCD Display – Operating Manual 01750140683 F... -
Page 26: Installation
VGA cable to the connector. Secure tightening the thumb-screw. Connect the other end of the VGA cable to the similar VGA connector on BA72R. VGA connector Touch Connector DC Input 01750140683 F BA72R LCD Display – Operating Manual... -
Page 27: Connecting The Touch Cable (Option)
Connect the 9-pin DSUB of the touch cable to the selected COM port of the Beetle system. Secure it by tightening the 2 screws on the DSUB connector. Connect the mini-DIN connector of the touch cable to the BA72R. BA72R LCD Display – Operating Manual... -
Page 28: Cable Routing
Replace the cable cover in the guide rail. Pay attention to the openings. Slide the cable cover back into place. When you hear a click, the cover is locked into place. 01750140683 F BA72R LCD Display – Operating Manual... -
Page 29: Software Installation
Then you can allocate the resources and set the corresponding jumper configuration on the COM board. Though the BA72R generally offers good display performance, the types and quality of the display adapter used in the host system can affect the display quality. -
Page 30: On-Screen Display (Osd)
Installation On-Screen Display (OSD) Located on the bottom left side of the BA72R are a set of 4 buttons. Pressing the “Menu” button will activate the OSD. The function of the OSD can be selected by first using the Left or Right button. - Page 31 Left, Right or Select buttons. There are a number of parameters that can set via the OSD menu. The following shows all the selectable parameters that can be set via the various OSD sub- menus. BA72R LCD Display – Operating Manual 01750140683 F...
-
Page 32: Input Source
Installation Input source Analog input Digital input (not applicable for BA72R) Exit sub-menu 01750140683 F BA72R LCD Display – Operating Manual... -
Page 33: Display Setting
Installation Display setting Brightness Contrast Exit sub-menu BA72R LCD Display – Operating Manual 01750140683 F... -
Page 34: Color Setting
Installation Color setting Auto colour sRGB Colour temperature Exit sub-menu 01750140683 F BA72R LCD Display – Operating Manual... - Page 35 Installation Selecting colour temperature When the ‘colour temperature’ option is selected, the following sub-menu options will be available for selection: RGB setting 4200K 5000K 6500K 7500K 9300K Exit sub-menu BA72R LCD Display – Operating Manual 01750140683 F...
-
Page 36: Image Setting
Installation Image setting Auto-adjust Width Phase Horizontal position Vertical position Exit sub-menu 01750140683 F BA72R LCD Display – Operating Manual... -
Page 37: Tools Menu
Installation Tools menu Factory reset Colour reset Position reset Sharpness Overlapped mode Exit sub-menu BA72R LCD Display – Operating Manual 01750140683 F... - Page 38 OSD Vertical Position OSD Direction Exit sub-menu Selecting OSD Direction When the ‘OSD Direction’ is selected, it will prompt for the following sub-menu options for selection: Normal Mirror Left Right Up Down Exit sub-menu 01750140683 F BA72R LCD Display – Operating Manual...
-
Page 39: Audio Setting
Installation Audio setting Volume Volume setting: Buzzer ON Buzzer OFF Exit sub-menu BA72R LCD Display – Operating Manual 01750140683 F... -
Page 40: Exit Osd Menu
Installation Exit OSD Menu Exit sub-menu 01750140683 F BA72R LCD Display – Operating Manual... -
Page 41: Technical Data
Technical Data Technical Data Models The BA72R family of display is available in a several configurations. BA72R-Y /X Where: Y: blank, 1 to n (where n is an incremental number) /X: Blank – with protective glass (no touch) /n – without touch and protective glass... -
Page 42: Operating Conditions
Technical Data Operating Conditions The following operating conditions are valid for a BA72R that is fitted with all the available modules (LCD flat screen, touch screen): Climate class IEC 721 3/3 Class 3K3 Operating Temperature C to +40 5% - 85% Humidity Absolute humidity 1g/m³... -
Page 43: Display Specification
Type § Dual-lamp, CCFL Lifetime 50,000 hrs § The backlight is not part of the warranty or part of a possible service agreement. Only trained technical personnel is authorized to replace the backlight. BA72R LCD Display – Operating Manual 01750140683 F... - Page 44 DDC2B (VESA standard) Accessories optional AC Power Adapter Input AC 100~240V, Output DC 12V, 3.33A VGA Cable 15-Dsub to 15-Dsub, shielded, 1.8 metre Touch cable 9-Dsub to 6pin mini-DIN, shielded, 1.8 metre 01750140683 F BA72R LCD Display – Operating Manual...
-
Page 45: Display Mode
Technical Data Display Mode Display Mode Vertical Pixel Sync Horizontal Frequency Clock Polarity Frequency (Hz) (MHz) (H/V) (KHz) VESA, 640 x 480 31.469 59.940 25.175 VESA, 800 x 600 37.879 60.317 40.000 BA72R LCD Display – Operating Manual 01750140683 F... -
Page 46: Interface Definition
Interface Definition Interface Definition VGA interface Signal GREEN BLUE GND (Red) GND (Green) GND (Blue) DDC +5V Supply (fused) GND (Sync) HYSNC VSYNC 01750140683 F BA72R LCD Display – Operating Manual... -
Page 47: Touch Interface
Interface Definition Touch Interface Signal (Reference to Touch Controller) Chassis GND RXD (in) TXD (out) BA72R LCD Display – Operating Manual 01750140683 F... - Page 48 Published by Wincor Nixdorf Pte Ltd 2, Kallang Sector Singapore 349277 Part No.: 01750140683 F...
