- Page 1 FP560 Digital Two-way Radio Instruction Manual...
- Page 3 Kirisun Communications Co., Ltd. We believe KIRISUN two-way radio, which always incorporates the latest technology, can bring great convenience to your life and work. We also believe that the quality and function of KIRISUN two-way radio can meet your demands for reliable communication.
- Page 4 FP560 Digital Two-way Radio Instruction Manual...
-
Page 5: Safety Information
Kirisun or its authorized parities. Due to the update or modification of the product, Kirisun owns the right to change the specifications of software and hardware described in this manual without further notice. Specifications and information contained in this manual are for reference only. - Page 6 4. Do not transmit when the radio is not equipped with an antenna. Transmitting without an antenna may damage the product and result RF discomfort. ◆ Using the Designated Accessories Use the antenna, battery, adapter or charger supplied or sold by Kirisun only, otherwise it will causes damage to...
- Page 7 FP560 Digital Two-way Radio Instruction Manual the product. If you want to purchase or replace the accessories, please contact your local dealer or Kirisun. ◆ Area Restrictions 1. To avoid of the problems caused by electromagnetic interference or electromagnetic compatibility, turn off the radio in any facilities where posted notices instruct you to do so, such as hospital and other health care facilities.
- Page 8 FP560 Digital Two-way Radio Instruction Manual Batteries All batteries can cause property damage and/or bodily injury, such as burns, if a conductive material such as jewelry, keys, or beaded chains touches exposed terminals. The conductive material may complete an electrical circuit (short circuit) and become quite hot.
-
Page 9: Table Of Contents
FP560 Digital Two-way Radio Instruction Manual Contents ◆Copyright.......................... II ◆ Safety Information ......................II 1 Unpacking and Checking ....................1 2 Preparing Your Radio for Use ..................2 2.1 Charging the Battery...................... 2 2.2 Installing/Removing the Battery ..................4 2.3 Installing/Removing the Antenna ................... 5 2.4 Installing the External Speaker/Microphone.............. -
Page 10: Unpacking And Checking
FP560 Digital Two-way Radio Instruction Manual Unpacking and Checking Unpack the radio carefully. We recommend that you check the radio and the supplied accessories listed in the following table before discarding the packing material. If any damage or loss has occurred during shipment, please contact the deliveryman or the dealer without delay. -
Page 11: Preparing Your Radio For Use
FP560 Digital Two-way Radio Instruction Manual Preparing Your Radio for Use 2.1 Charging the Battery Plug the power adapter into the suitable AC socket and connect the power adapter to the charger base. Three LED lights flash about one second. And then green LED will light on while charging normally. - Page 12 The battery is not fully charged in the factory. Please ensure complete fill before initial use KB-515L Li-ion battery of Kirisun is applicable to this radio. When charging the battery for the first time after purchase or long-time storage (over 2 months), please repeat charging several times for the battery to achieve normal capacity.
-
Page 13: Installing/Removing The Battery
FP560 Digital Two-way Radio Instruction Manual 2.2 Installing/Removing the Battery Installing the Battery If the radio have a belt clip, press down the belt clip first as figure① shows; match the two bumps of the battery to the two slots of the radio and put inside as figure② shows. Then press down the bottom of the battery as figure③... -
Page 14: Installing/Removing The Antenna
FP560 Digital Two-way Radio Instruction Manual 2.3 Installing/Removing the Antenna Set the antenna in its receptacle and turn clockwise to fasten it. To remove it, please rotate itcounter-clockwise. 2.4 Installing the External Speaker/Microphone Open the cover for external speaker/MIC jacks, and then insert the external speaker/MIC plug into the jacks on the radio. -
Page 15: Product Overview
FP560 Digital Two-way Radio Instruction Manual 3 Product Overview 3.1 Radio Controls 1. Side button 1 (programmable button) 2. PTT (push to talk) button 3. Side button 2 (programmable button) 4. Menu Button... -
Page 16: Icon Indicator
FP560 Digital Two-way Radio Instruction Manual 5. Antenna 6. LED indicator 7. Channel knob 8. Top button (programmable button) 9. On/Off/ Volume Control Knob 10. Speaker 11. MIC 12. LCD Display 13. Up Key 14. Down Key 15. Cancel Key 16. - Page 17 FP560 Digital Two-way Radio Instruction Manual Battery Indicator. The more number of bars, the more power it has. Low power is used on the current channel. Middle power is used on the current channel. High power is used on the current channel.
-
Page 18: Led Indicator
FP560 Digital Two-way Radio Instruction Manual Digital Channel Analog Channel This option has been selected. 3.3 LED Indicator Indicator State Radio State Red LED lights on The radio is transmitting. The radio is receiving(voice or message) or there is a Green LED lights on activity on the current channel. -
Page 19: Basic Operation
FP560 Digital Two-way Radio Instruction Manual 4 Basic Operation 4.1 Powering On Clockwise rotate the volume control knob until a click is heard to turn on the radio. The radio will make a sound of “Di…” if programmed, and the current channel number will be annunciated. - Page 20 FP560 Digital Two-way Radio Instruction Manual 4.4 Adjusting the Volume Rotate the power/volume button to adjust the volume. 4.5 Selecting a Channel Rotate the channel knob to select a channel. The icon“ ” will be displayed when the current channel is digital channel.
- Page 21 FP560 Digital Two-way Radio Instruction Manual You can also make a call via contacts. Enter contact list menu and select one specific contact, then press PTT to initiate a call. 4.6.3 Manual Dial and Initiate a Call You can also make a call by "Manual Dial". Enter the "Contacts" menu and then enter "Manual Dial"...
-
Page 22: Advanced Functions
FP560 Digital Two-way Radio Instruction Manual (3) Press the “menu” button to enter to “contacts” and select the contact to send the message. (4) The “successful” will be shown when sent successfully, or “failed” will be shown. 4.9 Receiving a Message When a message is received, the LCD will display “a new message”... -
Page 23: Radio Kill/Revive
FP560 Digital Two-way Radio Instruction Manual personnel. During scanning, the radio checks every channel in the scan list and stops on the channel which a signal is detected. Scan revert channel While scanning, press the PTT Button to make the radio transmit on a default channel. This channel can be programmed by your dealer. - Page 24 FP560 Digital Two-way Radio Instruction Manual To turn off the Emergency Alarm, press the programmed Emergency Alarm Off shortcut key. Alarm Type: ◆None: No alarm function (Default setting); you cannot send an emergency alarm; ◆Siren Only: The radio only emits siren locally;...
-
Page 25: Troubleshooting
FP560 Digital Two-way Radio Instruction Manual emergency condition. Troubleshooting Problem Causes and Solutions A．The battery may be used up. Recharge it or change the The radio cannot be battery to try again. powered on. B．The power switch is in failure. Please change it. - Page 26 FP560 Digital Two-way Radio Instruction Manual A ． The antenna may get looser or may be improperly installed. Re-install the antenna. radio cannot B．The frequency settings may be different from others. Set receive signals your TX/RX frequencies to be the same as others.
- Page 27 - 2 -...
