User Guide
DP480-01
DMR Two Way Radio
We are very grateful for your purchasing Kirisun brand DMR Two Way Radio produced by Shenzhen
Kirisun Communications Co., Ltd.
We believe Kirisun DMR Two Way Radio, which always incorporates the latest technology, can bring
great convenience to your life and work. We also believe that the quality and function of Kirisun DMR
Two Way Radio can meet your demands for reliable communication.
Advertisement
Table of Contents
Related Manuals for Kirisun DP480-01
Summary of Contents for Kirisun DP480-01
- Page 1 We believe Kirisun DMR Two Way Radio, which always incorporates the latest technology, can bring great convenience to your life and work. We also believe that the quality and function of Kirisun DMR Two Way Radio can meet your demands for reliable communication.
- Page 3 (including accessories). Any design and materials may not be modified, copied, extracted or translated without authorization of Kirisun or its authorized parities. ◆This product may involve update or modification in future, and Kirisun owns the right to change the specifications of software and hardware described in this manual without further notice. Specifications and information contained in this manual are for reference only.
- Page 4 DP480-01 DMR Two Way Radio Safety Precaution ◆The radio can only be repaired or maintained by professional technicians. The user must not disassemble the radio at liberty. ◆In order to avoid problems caused by electromagnetic interference or electromagnetic incompatibility, please turn off the radio in the place such as hospital, plane and other health care centers where there is a sign such as “Turn off Your...
- Page 5 User Guide Battery ◆If the conductive substance on human body makes contact with the exposed battery terminal, it may damage your belongings, and/or do harm, such as burning, to human body. Conductive material includes jewelry, keys or bead-like necklace. They can form a loop (it causes short circuit) with battery and cause skin burn after the rapid temperature rise.
- Page 6 DP480-01 DMR Two Way Radio DP480-01 Quick Reference...
- Page 7 User Guide Brief Introduction ．Attaching the antenna: Put the antenna into the antenna interface, and rotate the antenna clockwise to fix it. 2．Powering on: Rotate the power/volume knob to power on the radio. 3．Channel Selection: Rotate the channel selection knob to select channel. 4．Powering off: Rotate the power/volume knob clockwise to power off the radio...
-
Page 8: Table Of Contents
DP480-01 DMR Two Way Radio Contents UNPACKING AND CHECKING ..................... 8 ....................... 8 1.1 S UPPLIED CCESSORIES BATTERY INFORMATION ....................9 ................11 3.1 A TTACHING ETACHING THE ATTERY ................13 3.2 A TTACHING ETACHING THE NTENNA ....................14 3.4A... - Page 9 User Guide ........................19 5.2 LED I NDICATION BASIC OPERATION ......................21 ................... 21 OWERING ON OFF THE ADIO ....................21 ELECTING THE HANNEL ..................... 21 DJUSTING THE OLUME 6.4 I ........................22 NITIATING A 6.5 R ..........................22 ECEIVING ......................
- Page 10 DP480-01 DMR Two Way Radio ........................24 RIORITY ......................... 25 TUN AND EVIVE ............................25 ..........................25 MERGENCY ................27 OLOR ELECTION IN IGITAL ........................27 ADIO ETTING ) GPS( ) ........................27 OPTIONAL ........................28 ORKER ) ....................... 28 OPTIONAL ) ......................
-
Page 11: Unpacking And Checking
User Guide Unpacking and Checking Please carefully open the box, and check if the accessories listed below are contained in the package. For any missing or damaged item, please contact your local dealer for solution. 1.1 Supplied Accessories Material Quantity Main Unit Charger Power Adaptor... -
Page 12: Battery Information
DP480-01 DMR Two Way Radio Battery Information 2.1 Notice The battery is not charged before delivery, so please charge the battery for your first use. If the battery is not used for a long time or the battery is used up, please charge it before use. Charge/discharge for twice or three times alternately to achieve its optimal performance. - Page 13 User Guide ◆In temperature higher than 35℃ or below -10℃, the dischargeable power of the battery may decrease due to the physical property of lithium battery. 2.2 Battery Charging Plug the power adaptor in the proper socket of AC power.
-
Page 14: Attaching/Detaching The Battery
The battery is not charged before delivery from the factory, so please charge the battery before your first use. Kirisun KB-75A lithium-ion can be used for this radio. If the battery which is stored for over 2 months or a new battery is charged for the first time, it should be charged repeatedly to gain full battery capacity. - Page 15 User Guide (2) Align the battery with the battery installation base at the back and insert the battery as shown in ②. (3) Slide the battery along the direction as shown in ③ until the battery is fit into the right position. (4) Slightly press the battery top as shown in ④...
-
Page 16: Attaching/Detaching The Antenna
DP480-01 DMR Two Way Radio 3.2 Attaching/Detaching the Antenna For attaching the antenna, put the antenna’s end with screw thread into the antenna port. Turn the antenna clockwise until it is fixed. For detaching the antenna, turn it counter-clockwise. Antenna Type:... -
Page 17: Attaching The Microphone
User Guide 3.4Attaching the Microphone Open the earphone cover plate on the right and connect the earphone cable to the port. -
Page 18: Overview
DP480-01 DMR Two Way Radio Overview... - Page 19 User Guide Part Name Part Name Power/Volume Knob Turn it clockwise to turn on the radio and turn it counter-clockwise until a click is Antenna heard to turn off the radio. When the radio is on, turn the knob to adjust volume.
-
Page 20: Programmable Keys
DP480-01 DMR Two Way Radio Speaker Belt Clip Output audio. Channel Knob Battery Latch Turn it to select channel 1-16. Programmable Keys 5.1 Programmable Keys To suit the operation habits of customer, programmable keys (side keys) are available and can be set by dealer as shortcut key. - Page 21 User Guide Programmable Application Feature High/Low Power Switch to high and low power If the current analogue channel has CTCSS, press this key and Monitor switch to carrier squelch mode to cancel CTCSS; press it again to go back to the original state. Starts the emergency feature.
-
Page 22: Led Indication
DP480-01 DMR Two Way Radio Programmable Application Feature Alert Tone on/off Enable/disable all the alert tones. Press this key to switch among different zones. The zones are Zone Selection programmed by programming software. Repeater/Talk Enable/disable Repeater feature. around Nuisance Delete Deletes the channel which is useless from the scan list. - Page 23 User Guide Glows green Receiving Flashes red Low battery Flashes green Channels are being scanned Flashes orange Digital call hang time and it will exit when the hang time is up Glows orange Blank channel which is not available. Switch to other channel to exit. Flashes red quickly The programming software is reading the parameters available for configuration Flashes...
-
Page 24: Basic Operation
DP480-01 DMR Two Way Radio 6. Basic Operation Powering on/off the Radio When the radio is off, rotate the power/volume knob clockwise until a click is heard to power on the radio. When the radio is on, rotate the power/volume knob counter-clockwise until a click is heard to turn off the radio. -
Page 25: Initiating A Call
User Guide counter-clockwise to decrease the volume. 6.4 Initiating a Call Press PTT button to initiate a call to the default contact on the current channel when it is digital channel. The default contact on the current channel can be programmed by dealer. 6.5 Receiving When the radio receives RF signal on the current channel and reaches squelch start level, the green LED glows to indicate that carrier is received. -
Page 26: Replying To The Call
DP480-01 DMR Two Way Radio 6.6Replying to the Call When the current channel is digital channel and after a call is received, press PTT button within the call hang time to reply. If the call hang time is up, you need to initiate a call to reply. The call hang time can be set by dealer. -
Page 27: B) Channel Scan
User Guide (interval set by dealer). If the dealer set pre-alarm feature, pre-alarm will sound before TOT time is up. Channel Scan Channel scan searches channels with signals. When the channel scanned has signals, the radio will stay on this channel for communication. Scan method is carrier control scan. By pressing the Scan shortcut key, the radio can scan the scan list related to the current channel. -
Page 28: E) Stun And Revive
DP480-01 DMR Two Way Radio radio starts the scan feature. The priority scan mode is cycle scan, and it scans priority channel every time when it scans a conventional channel. For example, if there are channel 1, 2, 3, 4 in the scan list and channel 2 is priority channel, the scan cycle will be 1->2->3->2->4->2->1. - Page 29 User Guide In state of emergency, press the Emergency shortcut key to send emergency alarm. Emergency alarm consists of two parts: alarm type and alarm mode. Alarm mode is used to specify the contents sent to other members in emergency. You can ask your dealer to set these parameters based on your requirements.
-
Page 30: H)Color Code Selection In Digital Mode
Description: only 1~14 can be selected when DMR feature is enabled. Radio Setting This radio has no LCD or keypad, so please use programming software for more radio settings. j) GPS(optional) Use programming software to activate GPS feature. After GPS feature is enabled, use Kirisun dispatch... -
Page 31: K) Lone Worker
User Guide system to report terminal GPS information to dispatcher. You can also manually check the portable location at dispatcher. k) Lone Worker This feature is intended for lone worker and if the worker does not operate the radio within a certain pre-defined time, the radio will automatically ask for help from control center or other radios. -
Page 32: Troubleshooting
DP480-01 DMR Two Way Radio Troubleshooting Problem Cause and Solution A. The battery is used up –charge the battery or change to a new Failed to power battery; B. Volume switch is faulty – get it repaired at the specified service station;... - Page 33 User Guide A. wrong channel parameters – reset the parameters and try again; Failed to transmit B. the group identity for default contact is wrong – select a right group; or receive C. Beyond the communication scope.
-
Page 35: Fcc Statement
DP480-01 DMR Two Way Radio FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 36 DP480-01 DMR Two Way Radio -Consult the dealer or an experienced radio/TV technician for help. NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 37 DP480-01 DMR Two Way Radio Technical Parameters PMR: Operation Frequency Range: 136 to 174MHz Rated Output Power: High Power: 5W, Low Power: 1W Modulation Type: Analog: FM, Digital: 4FSK Channel Separation: Analog: 12.5kHz, Digital: 12.5kHz GPS: Modulation: MSK Operation Frequency: 1575.42MHz...
