  • Page 1 EPC-CV1 Series...
  • Page 2 E9994 Revised Edition V2 November 2014 Copyright Notice This document is copyrighted, 2014. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of the original manufacturer.

  • Page 3: Table Of Contents

    Contents Chapter 1: Product overview Package contents................. 1-1 Features ..................1-1 Specifications ................1-2 Chapter 2: Motherboard information Before you proceed ..............2-1 Motherboard layout ..............2-2 Screw size ..................2-4 2.3.1 Component side .............. 2-4 2.3.2 Solder side ..............2-5 Central Processing Unit (CPU) ...........
  • Page 4 Contents Monitor menu ................3-9 3.5.1 CPU Temperature / MB Temperature [xxxºC/xxxºF] ..3-9 3.5.2 Chassis Fan Speed [xxxx RPM] or [N/A] ......3-9 3.5.3 Chassis Q-Fan Control [Enabled] ......... 3-10 3.5.4 CPU Voltage, 3.3V Voltage, 5V Voltage, 12V Voltage ..........3-10 Boot menu ..................

  • Page 5: Chapter 1: Product Overview

    Chapter 1 Product overview Package contents Check your industrial motherboard package for the following items. 1 x Industrial Motherboard 1 x Cable Kit 1 x DVD-ROM for manual (in PDF format) and drivers NOTE: If any of the above items are damaged or missing, contact your distributor or sales representative immediately.

  • Page 6: Specifications

    1 x onboard 2-pin power connector Power compliance Compliant with Eup/ErP Operating F~131 F (-10 C~55 temperature Operating humidity 0%~90% relative humidity, non-condensing Form factor EPIC form factor: 4.53 in. x 6.5 in. (11.5 cm x 16.5 cm) CE, FCC (continued on the next page) EPC-CV1 Series...
  • Page 7 Storage 2 x SATA 3Gb/s ports 6 x USB 2.0 ports (2 ports at mid-board, 4 ports on rear I/O) Display I/O 1 x LVDS connector, 1 x VGA connector, 1 x HDMI port Audio I/O Mic-In, Line-Out, S/PDIF onboard headers Amplifier onboard header HDMI support audio LAN I/O...
  • Page 8 7 64-bit (only with AMD graphics) ® Windows 8 32-bit ® Windows 8 64-bit (only with AMD graphics) ® Linux Fedora Accessories 1 x SATA 3Gb/s cable 1 x SATA power cable 1 x Support DVD (Drivers, Manual) NOTE: Specifications are subject to change without notice. EPC-CV1 Series...

  • Page 9: Chapter 2: Motherboard Information

    Chapter 2 Motherboard information Before you proceed Take note of the following precautions before you install motherboard components or change any motherboard settings. CAUTION! • Unplug the power cord from the wall socket before touching any component. • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity. • Hold components by the edges to avoid touching the ICs on them. • Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component.

  • Page 10: Motherboard Layout

    HD7410M ® LAN1 ISD72 GPU (optional) D9MGG 8111F PEX8605 LAN2 R560 Intel ® LVDS1 010S NM10 8111F USB2 USB3 KBMS1 Intel ® Super N2600 BATTERY DDR3 DIMM_A1 EATX_PWR1 CHA_FAN1 Place this side towards the rear of the chassis EPC-CV1 Series...
  • Page 11 Connectors/Jumpers/Slots Page Digital audio connector (4-1 pin SPDIF_OUT1) 2-13 Line-Out / Mic-In audio connector (10-1 pin AAFP1) 2-13 SPI programming connector (8-pin SPI1) 2-18 Audio amplifier connector (4-pin AMP_CON1) 2-20 Serial ATA 3Gb/s connectors (7-pin SATA3G_1/2) 2-17 Internal speaker connector (4-pin SPEAKER) 2-15 LVDS connector (30-pin LVDS1) 2-21 VGA connector (16-pin VGA) 2-20 LCD inverter power setting jumper (3-pin LCD_POWER_SEL1) 2-11 LVDS backlight brightness control jumper (3-pin L_BRIGHTNESS1) 2-10 Backlight inverter power connector (5-pin INV1) 2-19 System panel connector (10-1 pin F_PANEL1) 2-16 Digital I/O connector (10-pin DIO1) 2-22 Serial port connectors (9-pin COM2/3/4) 2-14 Chassis fan connector (4-pin CHA_FAN1) 2-15 Clear RTC RAM (3-pin CLRTC1) LVDS panel VDD setting jumper (3-pin LVDS_VDD_SEL1) 2-10 DDR3 DIMM slot EATX power connector (2-pin EATX_PWR1) 2-14 Lockable DC power port (DC_PWR) 2-12 SATA power connector (4-pin SATA_PWR1) 2-17 COM1 Ring and voltage selection (6-pin J1)

  • Page 12: Screw Size

    Screw size 2.3.1 Component side EPC-CV1 Series...

  • Page 13: Solder Side

    2.3.2 Solder side Chapter 2: Motherboard information...

  • Page 14: Central Processing Unit (Cpu)

    Central Processing Unit (CPU) The motherboard comes with an integrated Intel Atom™ processor N2600 / ® N2800 (optional). Integrated Intel ® Atom™ processor EPC-CV1 Series Integrated Intel Atom™ processor ® System memory This motherboard comes with one Double Data Rate 3 (DDR3) Small Outline Dual Inline Memory Modules (SO-DIMM) socket. The figure illustrates the location of the DDR3 DIMM socket: DIMM_A1 EPC-CV1 Series DDR3 DIMM socket To install a DIMM EPC-CV1 Series...
  • Page 15 To remove a DIMM Chapter 2: Motherboard information...

  • Page 16: Jumpers

    Clear RTC RAM (3-pin CLRTC1) This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords. CLRTC1 Normal Clear (Default) EPC-CV1 Series Clear CMOS RAM To erase the RTC RAM: 1. Turn OFF the computer and unplug the power cord. 2. Move the jumper cap from pins 1-2 (default) to pins 2-3. Keep the cap on pins 2-3 for about 5~10 seconds, then move the cap back to pins 1-2. 3. Plug the power cord and turn ON the computer. 4. Hold down the <Del> key during the boot process and enter BIOS setup to reenter data. CAUTION! Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot...
  • Page 17 COM1 Ring and voltage selection (6-pin J1) +12V Ring (Default) EPC-CV1 Series COM1 Ring and voltage selection Pins +12V Ring (Default) AT Mode selection (2-pin J2) PIN1 AT MODE EPC-CV1 Series AT Mode selection Pins AT Mode Chapter 2: Motherboard information...
  • Page 18 LVDS backlight brightness control jumper (3-pin L_BRIGHTNESS1) L_BRIGHTNESS1 DC MODE PWM MODE (Default) EPC-CV1 Series LVDS backlight brightness control jumper Pins DC Mode (Default) PWM Mode LVDS panel VDD setting jumper (3-pin LVDS_VDD_SEL1) LVDS_VDD_SEL1 (Default) EPC-CV1 Series LVDS panel VDD setting jumper Pins...
  • Page 19 LCD inverter power setting jumper (3-pin LCD_POWER_SEL1) LCD_POWER_SEL1 +12V (Default) EPC-CV1 Series LCD inverter power setting jumper Pins +12V (Default) Chapter 2: Motherboard information 2-11...

  • Page 20: Connectors

    SPEED LED Link LED Status Description Status Description No link 10 Mbps connection ORANGE Linked ORANGE 100 Mbps connection BLINKING Data activity GREEN 1 Gbps connection LAN port USB 2.0 ports. These two 12-pin Universal Serial Bus (USB) ports are available for connecting USB 2.0/1.1 devices. COM port. This 9-pin COM1 port is for pointing devices or other serial devices. Lockable DC power port (+12V). This port connects to a DC power adapter. To select the correct power adapter, refer to the inner and outer dimensions of this power port. EPC-CV1 Series 2-12...

  • Page 21: Internal Connectors

    Internal connectors Line-Out / Mic-In audio connector (10-1 pin AAFP1) This connector is for Line-Out / Mic-In audio connection. AAFP1 PIN 1 EPC-CV1 Series Line-Out / Mic-In audio connector Digital audio connector (4-1 pin SPDIF_OUT1) This connector is for an additional Sony/Philips Digital Interface (S/PDIF) port. Connect the S/PDIF Out module cable to this connector, then install the module to a slot opening at the back of the system chassis.
  • Page 22 EATX power connector (2-pin EATX_PWR1) This connector is for EATX power supply plug. The power supply plug is designed to fit this connector in only one orientation. Find the proper orientation and push down firmly until the connector completely fit. EATX_PWR1 EPC-CV1 Series EATX power connector Serial port connectors [WtoB CON 9P, 1.25mm, S/T, SMT / ACES / 50273- 00971-001] (9-pin COM2/3/4) These connectors are for serial (COM) ports. Connect the serial port module cable to this connector, then install the module to a slot opening at the back of the system chassis. COM4 PIN 1 COM3...
  • Page 23 Chassis fan connector (4-pin CHA_FAN1) Connect the fan cable to the fan connector on the motherboard, ensuring that the black wire of the cable matches the ground pin of the connector. CHA_FAN1 EPC-CV1 Series Chassis fan connector Do not forget to connect the fan cable to the fan connector. CAUTION: Insufficient air flow inside the system may damage the motherboard components. This is not a jumper! Do not place jumper caps on the fan...
  • Page 24 System panel connector (10-1 pin F_PANEL1) This connector supports several chassis-mounted functions. F_PANEL1 PIN 1 HD_LED+ PLED+ HD_LED- PLED- PANSWH# HWRST# (NC) EPC-CV1 Series System panel connector • System power LED (2-pin PWR LED) This 2-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. • Hard disk drive activity LED (2-pin +HD_LED) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The IDE LED lights up or flashes when data is read from or written to the HDD. • ATX power button/soft-off button (2-pin PWR BTN) This 2-pin connector is for the system power button.
  • Page 25 Serial ATA 3Gb/s connectors (7-pin SATA3G_1/2]) These connectors connect to Serial ATA 3Gb/s hard disk drives and optical drives via Serial ATA 3Gb/s signal cables. EPC-CV1 Series SATA 3.0Gb/s connectors NOTES: • These connectors are set to [IDE] by default. In IDE mode, you can connect Serial ATA boot/data hard disk drives to these connectors. • You must install Windows XP Service Pack 3 or later version before using ® Serial ATA hard disk drives. • When using hot-plug and NCQ, set the Configure SATA as item in the BIOS to [AHCI]. See section 3.4.2 IDE Configuration for details. SATA power connector (4-pin SATA_PWR1) This connector is for the SATA power cable. The power cable plug is...
  • Page 26 10. USB 2.0 connector (10-pin USB1) This connector is for USB 2.0 ports. Connect the USB module cable to this connector, then install the module to a slot opening at the back of the system chassis. This USB connector complies with USB 2.0 specification that supports up to 480 Mbps connection speed. USB1 PIN 1 USB4-_R USB5+_R USB4+_R USB5-_R EPC-CV1 Series USB 2.0 connector CAUTION! Never connect a 1394 cable to the USB connector. Doing so will damage the motherboard! NOTE: The USB module cable is purchased separately. 11. SPI programming connector (8-pin SPI1) Use this connector to flash BIOS SPI ROM. SPI1 PIN 1 EPC-CV1 Series SPI programming connector EPC-CV1 Series 2-18...
  • Page 27 PIN 1 EPC-CV1 Series PS/2 keyboard/mouse connector Backlight inverter power connector [WAFER HD 5P S/T 2.0mm WHITE / PINREX / 721-81-05TW00] (5-pin INV1) Connect the backlight inverter power cable to this connector. INV1 +VCC_LVDS1_BKLT L_BRIGHTNESS1 BKLT_EN EPC-CV1 Series Backlight inverter power connector NOTE: The backlight inverter power cable is purchased separately. Chapter 2: Motherboard information 2-19...
  • Page 28 PIN 1 DAC_R DAC_G DAC_B RDDCA_DATA_R R_HSYNC R_VSYNC RDDCA_CLK_R EPC-CV1 Series VGA connector 15. Audio amplifier connector [WtoB CON 4P, 1.25mm, S/T, SMT // ACES / 85025-04701] (4-pin AMP_CON1) This connector is for an external audio amplifier. AMP_CON1 PIN 1 EPC-CV1 Series Speaker out connector EPC-CV1 Series 2-20...
  • Page 29 LVDS_DP1 LVDSB_L1P_GPU +VDD_LVDS1 LVDS_DN2 LVDSB_L2N_GPU LVDS_DP2 LVDSB_L2P_GPU LDDC_DATA LDDC_CLK LVDS_DN3 LVDSB_L3N_GPU LVDS_DP3 LVDSB_L3P_GPU +VDD_LVDS1 LVDS_CLKN LVDSB_LCLKN_GPU LVDS_CLKP LVDSB_LCLKP_GPU EPC-CV1 Series LVDS connector 17. Battery connector (2-pin BATTERY) This connector is for the lithium CMOS battery. BATTERY PIN 1 EPC-CV1 Series Battery connector Chapter 2: Motherboard information 2-21...
  • Page 30 18. Digital I/O connector (10-pin DIO1) This connector includes 8 I/O lines. All of the Digital I/O lines are programmable and each I/O pin can be individually programmed to support various devices. DIO1 PIN 1 EPC-CV1 Series Digital I/O connector NOTE: To configure the I/O pins in BIOS, go to the Advanced tab > DIO Function > GPIO 1~8. See section 3.4.6 DIO Function for details. EPC-CV1 Series 2-22...

  • Page 31: Chapter 3: Bios Setup

    Chapter 3 BIOS setup BIOS setup program Use the BIOS Setup program to update the BIOS or configure its parameters. The BIOS screens include navigation keys and brief online help to guide you in using the BIOS Setup program. Entering BIOS Setup at startup To enter BIOS Setup at startup: •...

  • Page 32: Bios Menu Screen

    For changing the advanced system settings. For displaying the system temperature, power status, and Monitor changing the fan settings Boot For changing the system boot configuration. For configuring options for special functions. Tool Exit For selecting the exit options and loading default settings. EPC-CV1 Series...
  • Page 33 Menu items The highlighted item on the menu bar displays the specific items for that menu. For example, selecting Main shows the Main menu items. The other items (Ai Tweaker, Advanced, Monitor, Boot, Tool, and Exit) on the menu bar have their respective menu items. Back button This button appears when entering a submenu.

  • Page 34: Main Menu

    Clock (RTC) RAM to clear the BIOS password. See section 2.6 Jumpers for information on how to erase the RTC RAM. • The Administrator or User Password items on top of the screen show the default Not Installed. After you set a password, these items show Installed. EPC-CV1 Series...
  • Page 35 Administrator Password If you have set an administrator password, we recommend that you enter the administrator password for accessing the system. Otherwise, you might be able to see or change only selected fields in the BIOS setup program. To set an administrator password: Select the Administrator Password item and press <Enter>.

  • Page 36: Advanced Menu

    Two threads per activated core are enabled. [Disabled] Only one thread per activated core is enabled. Limit CPUID Maximum [Disabled] [Enabled] Allows legacy operating systems to boot even without support for CPUs with extended CPUID functions. [Disabled] Disables this function. EPC-CV1 Series...

  • Page 37: Ide Configuration

    3.4.2 IDE Configuration While entering Setup, the BIOS automatically detects the presence of SATA devices. The SATA Port items show Not Present if no SATA device is installed to the corresponding SATA port. SATA Controller(s) [Enabled] [Disabled] Disables the onboard SATA controllers. [Enabled] Enables the onboard SATA controllers.

  • Page 38: Panel Controller (Amd ® Gpu Only)

    [Disabled] Disables the controller. RS Mode [RS232] Allows you to configure the serial communications standard of serial port (COM) 1. Configuration options: [RS232] [RS422] [RS485] Onboard LAN [Enabled] [Enabled] Enables the Realtek LAN controller. [Disabled] Disables the controller. EPC-CV1 Series...

  • Page 39: Monitor Menu

    Onboard LAN Boot ROM [Disabled] This item appears only when you set the Onboard LAN item to [Enabled] and allows you to enable or disable the Boot ROM of the onboard LAN controller. Configuration options: [Enabled] [Disabled] Monitor menu The Monitor menu displays the system temperature/power status, and allows you to change the fan settings.

  • Page 40: Chassis Q-Fan Control [Enabled]

    The Boot menu items allow you to change the system boot options. 3.6.1 Bootup NumLock State [On] [On] Sets the power-on state of the NumLock to [On]. [Off] Sets the power-on state of the NumLock to [Off]. EPC-CV1 Series 3-10...

  • Page 41: Full Screen Logo [Disabled]

    3.6.2 Full Screen Logo [Disabled] [Enabled] Enables the full screen logo display feature. [Disabled] Disables the full screen logo display feature. 3.6.3 Wait for ‘F1’ If Error [Enabled] When this item is set to [Enabled], the system waits for the F1 key to be pressed when error occurs.

  • Page 42: Exit Menu

    Discard Changes & Exit This option allows you to exit the Setup program without saving your changes. When you select this option or if you press <Esc>, a confirmation window appears. Select Yes to discard changes and exit. EPC-CV1 Series 3-12...

  • Page 43: Appendix

    Appendix Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference. • This device must accept any interference received including interference that may cause undesired operation.
  • Page 44 電子信息產品污染控制標示：圖中之數字為產品之環保使用期限。僅 指電子信息產品中含有的有毒有害物質或元素不致發生外洩或突變從 而對環境造成污染或對人身、財產造成嚴重損害的期限。 有毒有害物質或元素的名 稱 及含 量 說明 標 示 ： 有害物質或元素 部件名稱 六 價 鉻 多 溴 聯 苯 多 溴 二 苯 醚 鉛 (Pb) 汞 (Hg) 鎘 (Cd) (Cr(VI)) (PBB) (PBDE) 印 刷 電 路 板 及 其 ×...
