Pro-Form PFIVEL81412.0 User Manual page 6

STEP 1
I. Fasten front
(39) with 2 carriage bolts (48)
from the underside of stabilizer.
Secure with 2 curved washers
(13) and 2 cap nuts (47).
II. Fasten rear stabilizer (93)
with 2 Allen bolts (48), 2 spring
washers (15)
STEP 2
I. Carefully lift the Handlebar Post (25) until it
is vertical. Put the front plastic cover (37) into the
Handlebar post (25). Connect the Upper Computer
Cable (28) and the Lower Computer Cable (44).
II. Remove the loosely fitted Allen bolts (14),
spring washers (15) and curved washers (13) from
the Main Frame and lower the Handlebar Post (25)
into position. Loosely re-fit the 6 x M8 Allen Bolt
(14), 6 Spring washer (15) and 6 Curved Washers
(13) and align the Handlebar Post so it is straight
then tighten the Allen bolts fully
stabilizer
92
49
93
48
6
38L
47
13
47
13
25
14
15
13
28
37
44
39
38R
