Install the Seat Rail onto the Mainframe.
Attach Sensor Lead from Seat Rail to the
Mainframe, then align the front Seat Rail
holes with Mainframe and install, using
1x M10x95mm Bolt[8], 2x M10 Springs
Washer [9] and 1xM10 Nylock Nut[6].
Sensor Lead
Install the M10x180mm[4] Vertical
Frame Tensioning Bolt with the Plastic
Dome Cap[5] through the top of the
Seat Rail and secure from underneath
with 11x21x2T Washer[7] and Nylock
Nut[6].
Note: Do not tighten the Vertical
Frame Tensioning Bolt. See the
"Fine Tuning Your Rower" page for
details once assembly is complete
Install the Footplate[10] onto the Rower.
Footplate assembly left side. For ease
of assembly, leave the left side of the
Footplate and Seat Rail Spacer in place
as shown.
Tip: When mounting the Footplate as-
sembly onto the rower, it is only neces-
sary to remove one side, and leave the
other intact as shown here.
Note: 2 Allen keys of the same size are
provided for this portion of the assembly.
