- Page 1 Aristo F 300 Instruction manual 0462 255 001 GB 101221 Valid for serial no. 033-xxx-xxxx...
-
Page 2: Declaration Of Conformity
F 300 may be used with different MMC panels in combinations with or without water Manufacturer or his authorised representative established within the EEA Name, address, telephone No, telefax No: ESAB AB, Welding Equipment Esabvägen, SE- -695 81 LAXÅ, Sweden Phone: +46 584 81 000, Fax: +46 584 411 924 The following harmonised standard in force within the EEA has been used in the design: EN 60974- -5, Arc welding equipment –... -
Page 3: Table Of Contents
1 SAFETY ............2 INTRODUCTION . -
Page 4: Safety
SAFETY Users of ESAB equipment have the ultimate responsibility for ensuring that anyone who works on or near the equipment observes all the relevant safety precautions. Safety precautions must meet the requirements that apply to this type of equipment. The following recommendations should be ob- served in addition to the standard regulations that apply to the workplace. - Page 5 WARNING Arc welding and cutting can be injurious to yourself and others. Take precausions when welding and cutting. Ask for your employer's safety practices which should be based on manufacturers' hazard data. ELECTRIC SHOCK - Can kill Install and earth the unit in accordance with applicable standards. Do not touch live electrical parts or electrodes with bare skin, wet gloves or wet clothing.
-
Page 6: Introduction
ESAB can provide you with all necessary welding protection and accessories. INTRODUCTION The wire feed units Aristo F 300 and Aristo F 300w with control panels MA43 and MA44 are designed for MIG/MAG welding together with 300 A, 400 A and 500 A power sources. -
Page 7: Technical Data
TECHNICAL DATA Aristo F 300 Mains voltage 48 V DC Power requirement 150 W Supply current I 3.2 A Wire feed speed 0.8 - 25 m/min Gun connection EURO Max. diameter wire bobbin 300 mm Wire dimension 0.8 - 1.6 mm 0.8 - 1.6 mm (PSF 3m PTFE) -
Page 8: Installation
INSTALLATION The installation must be executed by a professional. WARNING When welding in an environment with increased electrical danger, only power sources intended for this environment may be used. These power sources are marked with the symbol Lifting instructions Order number for lifting eyelet can be found on page 20. NOTE! If another mounting device is used, this must be electrically insulated from the wire feed unit. - Page 9 WARNING To prevent the reel from sliding off the hub: Lock the reel in place by turning the red knob as shown on the warning label attached next to the hub. WARNING Rotating parts can cause injury, take great care. WARNING Risk of crushing! Do not use safety gloves when replacing wire, feed rollers and wire bobbins.
-
Page 10: Connections And Control Devices
Water connection The wire feed unit with water connection is equipped with a detection system ELP (ESAB Logic Pump) which checks that the water hoses are connected. When connecting a water-cooled welding gun, the water pump starts. Detection only works with power sources that are equipped with ELP. -
Page 11: Wire Feed Pressure
Wire feed pressure Start by making sure that the wire moves smoothly through the wire guide. Then set the pressure of the wire feeder's pressure rollers. It is important that the pressure is not too great. Fig 1 Fig 2 To check that the feed pressure is set correctly, you can feed out the wire against an insulated object, e.g. -
Page 12: Connecting To Marathonpac
Connecting to MarathonPac Open the side panel Disconnect the pressure sensor (1) by folding it downwards. Unscrew the inlet nozzle (2). Install the inlet nozzle and quick release connector for MarathonPac (3) Remove the blind plug (4) from the rear of the feed unit and insert the wire guide from MarathonPac. -
Page 13: Changing Nozzles
Changing nozzles Open the side panel Disconnect the pressure sensor by folding it downwards. To remove the inlet nozzle (1), turn it anti-clockwise. Remove the intermediate nozzle (2) using a screwdriver and pull it straight up. To remove the outlet nozzle (3), undo the screw and pull the nozzle out. During installation, repeat the above in reverse order. -
Page 14: Ordering Spare Parts
Repair and electrical work should be performed by an authorized ESAB serviceman. Use only ESAB original spare and wear parts. Aristo F 300 is designed and tested in accordance with the international and European standards EN 60974-5 and EN 60974-10. It is the obligation of the service unit which has carried out the service or repair work to make sure that the product still conforms to the said standard. - Page 15 - 15 -...
-
Page 16: Diagram
Diagram - 16 - Edition 101221 bm52e... - Page 17 - 17 - Edition 101221 bm52e...
-
Page 18: Ordering Number
0462 250 894 Wire feed unit with water Aristo F 300w MA44 0459 839 043 Spare parts list Aristo F 300 0463 010 Instruction manual MA43 MA44 Instruction manuals and the spare parts list are available on the Internet at www.esab.com - 18 - Edition 101221 bm52o... -
Page 19: Wear Parts
Aristo F 300 Wear parts Item 1 Item 2A Item 2B Item 3 Item 4 Wire Ø Wire Ø Wire type Groove Feed roller Inlet nozzle Inlet nozzle Intermediate Outlet inch MarathonPac nozzle nozzle 0460 898 881 0462 037 001... -
Page 20: Accessories
Aristo F 300 Accessories Lifting eye (suspension device) ... 0463 068 880 Connection set, 70 mm With12 pole (8+4) cable plug/socket 2 m ........ - Page 21 Aristo F 300 Remote control unit MTA1 CAN ... 0459 491 880 MIG/MAG: wire feed speed and voltage MMA: current and arc force TIG: current, pulse and background current Remote control unit M1 10Prog CAN ..
