  • Page 1 ST0524 Snow Thrower OPERATOR’S MANUAL MTF−051055L...

  • Page 2: Responsibility Of The Owner

    INTRODUCTION Congratulations on your purchase of a Frontier Snowthrower. It has been designed, engineered and manufactured to give you the best possible dependability and performance. However, like all mechanical products, your machine will occasionally re- quire adjustment and maintenance. This handbook should be read before operating or performing and adjustments on your machine.

  • Page 3: Hazard Symbols And The Meanings

    RULES FOR SAFE OPERATION Operating Symbols and their meanings This manual contains safety information to make you aware of the hazards and risks associated with snow These symbols are used on your equipment and defined in your operating throwers, and how to avoid them. The snow thrower is designed and manual.

  • Page 4: Rules For Safe Operation

    RULES FOR SAFE OPERATION DANGER DANGER Avoid death or serious injury from rotating auger. Objects can be picked up by auger and thrown from chute. Keep hands, feet and clothing away. Never throw snow toward people or cars, and never allow anyone in front of the snow thrower.
  • Page 5 RULES FOR SAFE OPERATION WARNING WARNING Running engines produce heat. Engine parts, especially muffler, Gasoline and its vapors are extremely flammable and explosive. become extremely hot. Fire or explosion can cause severe burns or death. Severe thermal burns can occur on contact. WHEN ADDING FUEL Combustible debris, such as leaves, grass, brush, etc.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS HAZARD SYMBOLS AND THE MEANINGS ..... . . OPERATING SYMBOLS AND THEIR MEANINGS ....SAFETY DECALS .

  • Page 7: Safety Decals

    SAFETY DECALS the meaning, then thoroughly read all safety and operation WARNING: If safety decals are dam- instructions in this Owner’s Manual or contact your local aged or missing, replace immediately. dealer. If any safety decals become worn or damaged and cannot Look for this symbol to indicate important safe- be read, order replacement decals from your local dealer.

  • Page 8: Warranty

    THREE YEAR LIMITED WARRANTY Murray warrants to the original purchaser of this Frontier Branded Snowthrower that this unit shall be free from defects in material and workmanship under normal use and service for a period of Three (3) Year from the date of purchase; however,...

  • Page 9: Assembly

    ASSEMBLY TOOLS REQUIRED FOR ASSEMBLY CONTENTS OF SHIPPING CARTON 1 − Knife 1− Snowthrower 2 − 1/2” wrenches (or adjustable wrenches) 1− Container of Fuel Stabilizer (Located in Parts Bag) 2 − 9/16” wrenches (or adjustable wrenches) 1− Crank Assembly 2 −...

  • Page 10: Unpacking

    ASSEMBLY Figure 2 shows the snowthrower in the shipping position. Figure 3 shows the snowthrower completely assembled. Reference to right and left hand side of the snowthrower is from the operator’s position at the handle. UNPACKING Figure 2 1. Locate the two tear tabs at the bottom of the carton. Traction Drive Lever Auger Drive 2.

  • Page 11: Upper Handle And Crank Assembly

    ASSEMBLY UPPER HANDLE AND CRANK ASSEMBLY Crank 1. Loosen, but do not remove the screws, flatwashers, lock- washers and hex nuts in the upper holes of the lower han- 5/16−18x2” Bolt dle. 5/16−18” Lockwasher 3/8” Nylon 2. Remove the fasteners and the crank assembly eyebolt 5/16−18”...
  • Page 12 ASSEMBLY CHECK THE TIRES IMPORTANT! BEFORE YOU START OPERATING The tires were over inflated for shipment. Check the tire r Check the fasteners. Make sure all fasteners are pressure in the tires. See the sidewall of the tire for the tight.

  • Page 13: Operation

    OPERATION READ THIS OWNER’S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR SNOWTHROWER. Compare the illustrations with your SNOWTHROWER to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. Traction Drive Clutch Lever Auger Drive Clutch Lever Gas Tank Choke Control Gas Cap...

  • Page 14: Snowthrower Operation

    OPERATION The operation of any snowthrower can result in foreign objects being thrown into the eyes,which can result in severe eye damage. Always wear safety glasses or eye shields before beginning snowthrower Operation. We recommend standard safety glasses or Wide Vision Safety Mask for over spectacles. SNOWTHROWER OPERATION 4.

  • Page 15: Wheel Lock Out Pin

    OPERATION TO THROW SNOW WARNING: Never run engine indoors or in an 1. Push down the auger driver lever (right hand). See enclosed, poor ventilated area. Engine exhaust Figure 9. contains CARBON MONOXIDE, 2. To stop throwing snow, release the auger drive lever. DERLESS and DEADLY GAS.

  • Page 16: How To Set The Drift Cutters

    OPERATION HOW TO SET THE DRIFT CUTTERS Drift Cutter (OPTIONAL ACCESSORY ON SOME MODELS) Drift cutters are used to cut a path through snow deeper than the auger housing. 1. Loosen the wingnuts that secure the drift cutters to the auger housing (see Figure 14).

  • Page 17: Before Starting Engine

    OPERATION BEFORE STARTING ENGINE 1. Fill the fuel tank with fresh, clean, unleaded regular, un- leaded premium, or reformulated automotive gasoline Check the oil with a minimum of 85 octane along with a fuel stabilizer (follow instructions on fuel stabilizer package). DO NOT NOTE: The engine was shipped from the factory filled use leaded gasoline.

  • Page 18: Before Stopping The Engine

    OPERATION BEFORE STOPPING THE ENGINE Run the engine for a few minutes to help dry off any moisture on the engine. TO STOP ENGINE CAUTION: To stop the engine, do not move the choke 2. Pull out the safety key. control to CHOKE position.
  • Page 19 6. Push the primer button as specified below. Remove fin- ger from primer button between pushes. If after following the preceding instructions, your engine fails to start, have the engine checked by a John Deere/Frontier dealer. S Push two times if temperature is 15° F (−9° C) or high- S Push four times if temperature is below 15°...

  • Page 20: Frozen Starter

    OPERATION FROZEN STARTER WARNING: Never run engine indoors or in en- closed, poorly ventilated areas. Engine exhaust If the starter is frozen and will not turn engine: contains CARBON MONOXIDE, AN ODORLESS 1. Pull as much rope out of the starter as possible. AND DEADLY GAS.

  • Page 21: Operating Tips

    OPERATION OPERATING TIPS 1. Most efficient snowblowing is accomplished when snow 6. After the snowblowing job has been completed, allow the is removed immediately after it falls. engine to idle for a few minutes, to melt snow and ice ac- cumulated on the engine.

  • Page 22: Service Recommendations

    SERVICE RECOMMENDATIONS SERVICE RECOMMENDATIONS FIRST BEFORE EVERY EVERY EVERY BEGINNING EACH EACH BEFORE PROCEDURE HOUR OFTEN HOURS HOURS HOURS SEASON STORAGE √ √ √ Tighten all screws and nuts Check Traction Clutch √ √ Cable Adjustment (See Cable Adjustment) Check Auger clutch Cable √...

  • Page 23: Maintenance

    MAINTENANCE Some adjustments will need to be made periodically to Remove filler plug (Figure 20), once a year. If grease is properly maintain your snow blower. visible, do not add. If grease is not visible, use a piece of fine wire, like a dipstick to check if there is grease in the gear box.

  • Page 24: Lubrication − Every 25 Hours

    MAINTENANCE LUBRICATION − EVERY 25 HOURS Chute Rotation Gear Chute Rotation Gear Lubricate the chute rotation gear with automotive type oil. (see Figure 21). Figure 21 Chains 4. Lubricate the chains with a chain type lubricant. 5. Wipe the hexshaft and sprockets with 5W30 motor oil. 1.

  • Page 25: Engine

    MAINTENANCE ENGINE TEMPERATURE TYPE OF OIL 0_F (−18_ C) and above S.A.E. 5W30 POWER RATINGS 0_F (−18_ C) and below synthetic 5W30 The power ratings for an individual engine model are initially developed by starting with SAE (Society of Automotive SAE VISCOSITY GRADES Engineers) code J1940 (Small Engine Power &...

  • Page 26: How To Remove The Snow Hood

    MAINTENANCE HOW TO REMOVE THE SNOW HOOD Mounting Screws To access the spark plug, the snow hood must be removed Snow Hood as follows: 1. Remove the choke control knob (see Figure 25). Spark Plug 2. Remove the safety key. 3.

  • Page 27: Auger Housing Height Adjustment

    MAINTENANCE WARNING: Always turn unit off, remove igni- To adjust skids, proceed as follows: tion key and disconnect the spark plug wire be- 1. Place a block (equal to height from ground desired) un- fore making any repairs or adjustments. der scraper bar near but not under skid.

  • Page 28: Belt Adjustment

    MAINTENANCE BELT ADJUSTMENT Traction Drive Belt The traction drive belt has constant spring pressure and does not require an adjustment. If the traction drive belt is slipping, replace the belt. See “How To Replace The Belts” in the Maintenance section. Auger Drive Belt If your snowthrower will not discharge snow, check the control cable adjustment.

  • Page 29: How To Replace The Belts

    MAINTENANCE HOW TO REPLACE THE BELTS The drive belts are of special construction and must be 16. Install the belt cover. Tighten screw (See Figure 30). replaced with original factory replacement belts available 17. Check the adjustment of the cables. See “How To Check from your nearest authorized service center.
  • Page 30 MAINTENANCE Traction Drive Belt Engine Pulley Belt Guide Auger Drive Pulley Traction Drive Idler Pulley Auger Drive Belt Idler Pulley Traction Drive Spring Traction Drive Belt E−Ring Traction Drive Pulley Swing Plate Axle Rod Engine Pulley Figure 34 MTF−051055L...
  • Page 31 MAINTENANCE How To Remove the Traction Drive Belt If the snow thrower will not move forward, check the traction 11. Install and adjust the auger drive belt. See “How To Re- drive belt for wear or damage. If the traction drive belt is worn move The Auger Drive Belt”...

  • Page 32: Belt Guide Adjustment

    MAINTENANCE BELT GUIDE ADJUSTMENT 1. Remove spark plug wire. 2. Have someone engage auger drive. Belt Guide 1/8 Inch (3.175 mm) 3. Measure the distance between the belt guide and belt. The distance should be 1/8 inch (3.175 mm) for guide. Auger Idler Pulley Engaged See Figure 36.

  • Page 33: Traction Drive Cable Adjustment

    MAINTENANCE Traction Drive Cable Adjustment Bolt WARNING: Drain the gasoline outdoors, away Bottom Panel from fire or flame. 1. Remove the gas from the gas tank. Stand the snow Auger Housing thrower up on the front end of the auger housing. 2.

  • Page 34: How To Adjust Or Replace The Friction Wheel

    MAINTENANCE HOW TO ADJUST OR REPLACE 5. Install the bottom panel (see Figure 42). THE FRICTION WHEEL 6. Tighten the bolts on each side of the bottom panel. How To Check The Friction Wheel If the snow thrower will not move forward, check the traction Bolt Bottom Panel drive belt, the traction drive cable or the friction wheel.
  • Page 35 MAINTENANCE How To Replace The Friction Wheel If the friction wheel is worn or damaged, the snow thrower will not move forward. The friction wheel must be replaced as follows. Drive Sprocket Axle 1. Remove the gas from the gas tank. Stand the snow thrower up on the front end of the auger housing (4).
  • Page 36 MAINTENANCE 10. Remove the three fasteners that hold the friction wheel to the hub (see Figure 48). 11. Remove the friction wheel from the hub. Slip the fric- tion wheel off the hex shaft. Washer 12. Assemble the new friction wheel onto hub with the fas- teners removed earlier.

  • Page 37: Auger Shear Bolt Replacement

    MAINTENANCE AUGER SHEAR BOLT REPLACEMENT The augers are secured to the auger shaft with special bolts that are designed to break if an object becomes lodged in the auger housing. Use of a harder bolt will reduce the protection provided by the shear bolt. To replace a broken shear bolt, Shear Pin proceed as follows: WARNING: To insure safety and performance...

  • Page 38: Storage

    STORAGE OFF SEASON STORAGE 4. Thoroughly clean the snowthrower. 5. Lubricate all lubrication points (see “Lubrication“ in the WARNING: Never store the engine, with fuel in the tank, indoors or in a poor ventilated enclo- Maintenance section). sure where fuel fumes could reach an open 6.

  • Page 39: Trouble Shooting Chart

    If you have any questions concerning parts, service, or technical data, contact your nearest John Deere/Frontier dealer. For complete warranty information refer to the warranty in the Owner’s Information section of this manual.

  • Page 40: Replacement Parts

    REPLACEMENT PARTS WE RECOMMEND JOHN DEERE/FRONTIER quality parts and lubricants available at your John Deere/Frontier dealer. PART NUMBERS MAY CHANGE. When you order re- placement parts, use the part numbers listed below and on the following pages. If a part number changes, your John Deere/Frontier dealer will have the latest part number.

  • Page 41: Parts Schematics

    FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A ENGINE 25−2 Á Á 25−1 Á 25−3 25−4 25−2 Ref.Drive Page Ref. Auger Housing Page Key No. Part No. Description Key No. Part No. Description MT6219 CORD, STARTER MT53704 SPRING, IDLER TRACTION DRIVE − − − − −...

  • Page 42: Gear Case

    FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A GEAR CASE Key No. Part No. Description MT10577 CASE, GEAR, RH MT10576 CASE, GEAR, LH MT710025 SCREW,1/4−20X.75 MT15X143 NUT,1/4−20 MT9344 SCREW, 3/8−16X.50 MT9566 SEAL, OIL MT50304 BEARING, FL MT48275 WASHER, FLAT MT340286 SHAFT, AUGER OUTPUT...
  • Page 43 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A FRAME Ref. Engine Page Ref. Auger Housing Page Ref. Drive Page MTF−051055L...
  • Page 44 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A FRAME Key No. Part No. Description MT1501055E701 COVER, BOTTOM MT310169 SCREW, 1/4−20X .63 MT1501111 YZ IDLER ASSEMBLY, AUGER MT711682 PIN, HAIR .38DIAX1.64LG MT761761 PIN, CLEVIS 3/16” DIA MT165x160 SPRING, TENSION MT761675 YZ ASSY., SPRING ATTACH MT585781 BOLT, 3/8−16X1.25 CARR.
  • Page 45 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A DRIVE Ref. Shift Yoke Page Ref. Frame Page Ref. Wheel Page Ref. Wheel Page Ref. Wheel Page Ref. Wheel Page MTF−051055L...
  • Page 46 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A DRIVE Key No. Part No. Description MT1501092 YZ LF AXLE, SWING PLATE YZ MT579851 CHAIN, ROLLER #420x19.00 MT334163 BEARING AND RETAINER, ASSY MT579858 WASHER MT25x020 SCREW, TAP 5/16−18x0.5 MT1501100 ASSY, HEX SHAFT MT579868 CHAIN, ROLLER #420x18.00 LG...
  • Page 47 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A AUGER HOUSING Ref. Gear Case Page MTF−051055L...
  • Page 48 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A AUGER HOUSING Key No. Part No. Description MT762146 PULLEY, 4L 6.12X .67 MT577400 SCREW, 5/16−18X.63 MT2001022 KEY, SQUARE 3/16 X 3/4 MT1501158 SPACER, FRICTION PULLEY MT582957 YZ RETAINER, BALL BRNG MT1501389 BEARING, BALL MT001x92 BOLT, HEX 5/16−18X .50...
  • Page 49 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A HANDLE ASSEMBLY MTF−051055L...
  • Page 50 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A HANDLE ASSEMBLY Key No. Part No. Description MT321838E701 HANDLE MT11234 SCREW MT71071 WASHER, FLAT MT71060 WASHER, SPLIT MT15x144 MT11261 PLASTIC−STOP MT302557 CLUTCH, LEFT HANDLE CONTROL MT302558 CLUTCH, RIGHT HANDLE CONTROL MT12621 YZ ROD, PIVOT HANDLE...
  • Page 51 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A SHIFT YOKE Key No. Part No. Description MT762299E701 ROD, SHIFT MT302628 SCREW, 1/4−20X.75 MT73826 NUT, 1/4−20 MT331624 GRIP MT760564 LEVER, SPRING MT302628 SCREW, 1/4−20X.75 MT73826 NUT, 1/4−20 MT579944 BEARING, FLANGED MT1501085 YZ ROD ASSY., SPEED SELECT...
  • Page 52 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A DISCHARGE CHUTE Ref. Auger Housing Page Key No. Part No. Description MT2x100 SCREW, 5/16−18 X 1.00 MT71071 WASHER, FLAT MT71038 NUT, 5/16−18 MT71071 WASHER MT1501260 KNOB, T 3.00 MT15x144 NUT, 5/16−18 MT002x97 BOLT, 5/16−18 X1.50...
  • Page 53 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A CHUTE ROD Ref. Handle Assy 852−9 852−5 852−8 852−13 852−10 Ref. Auger Housing Assy 852−11 852−1 852−2 852−6 869 852−4 852−7 852−3 Key No. Part No. Description Key No. Part No. Description 852−1 MT1501533 YZ ASSEMBLY, YOKE &...
  • Page 54 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A WHEELS Ref. Drive Page Key No. Part No. Description MT1501562 SHAFT, AXLE MT1501089 SPRKT & HUB MT01x193 SCREW, 1/4−20 x 1.75 MT15x145 NUT, 1/4−20 HEX NYLOCK MT1501114 BEARING, AXLE MT017x83 FLATWASHER MT1501139 BUSHING, WHEEL MT1501822 TIRE &...
  • Page 55 FRONTIER MODEL ST0524 FACTORY MODEL 624554x16A DECALS Key No. Part No. Description MT48x5283 DECAL, AUGER CONTROL MT7390 DECAL, V−BELTS MT7859 DECAL, OVER ADJUSTMENT MT48x5967 DECAL, ROTATING AUGER MT48x5578 DECAL, THROWN OBJECTS MT48x5965 DECAL, UNCLOGGING CHUTE MT48x5284 DECAL, SPEED CONTROL MT760983...

  • Page 56: Specifications

    SPECIFICATIONS ST0524 Engine Briggs & Stratton Horsepower 5.5 hp Starter Electric / Recoil Fuel Capacity 3 quarts Drive System Friction Disc Speeds 6 Forward / 2 Reverse 13” Tire Diameter Traction Control Pin Lock Clearing Width 24” Housing Height 17.5”...
