Summary of Contents for Frontier SB2164
- Page 1 SNOWBLOWER SB2164 SB2176 Serial # XFSB21X100058 and up OM0393SB2176-A 10/10...
-
Page 2: Table Of Contents
DECALS ..............................12 ASSEMBLY ..............................13-40 Snowblower Assembly ........................13 Installation of the Chute for SB2176 ................. 13-14 for SB2164 ................. 15-16 Installation of the Snowblower ....................16 Installation of the Hydraulic Hoses ..................17 Installation of the Electrical Wiring –... - Page 3 TABLE CONTENT OPERATION ..............................41-42 Optimum Performances ........................41 General Preparation ........................41 Operating Controls .......................... 41 Manual Deflector Adjustment ..................41 Hydraulic Deflector Adjustment ..................41 Hydraulic Rotation Adjustment ..................41 Ground Speed ........................ 42 Skid Shoe Adjustment ..................... 42 Snow Removal Methods .........................
-
Page 4: Spécifications
SPECIFICATIONS Working Width 64" 76" Transport Width 70" 88" Working Height 27" 27" Length 39" 39" Single/Dual Auger Single Single Auger Diameter 15" 15" Auger Flighting Thickness 5/16" 5/16" Impeller Diameter 24" 24" Impeller Width 7" 8 1/2" Impeller Shaft Diameter 1 1/4"... -
Page 5: Introduction - To The Purchaser
See the "Operation" section for more details. The Frontier loader mounted hydraulic snowblowers is designed to blow snow and not to push snow. Any use resembling a snow pusher will automatically void the snowblower warranty... -
Page 6: Safety Precautions
SAFETY PRECAUTIONS SAFETY FIRST This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury. Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use this unit. -
Page 7: Notice
SAFETY PRECAUTIONS - continued OTICE A safe operator is the best assurance against accidents. All operators, no matter how experienced they may be, should read this operator's manual and all other related manuals before attempting to operate the equipment. Please read the following section and pay particular attention to all safety recommendations contained in this manual and those labeled on the equipment and on the tractor. -
Page 8: Snowblower Operation
SAFETY PRECAUTIONS - continued Snowblower Operation 1. Before leaving the tractor unattended, 10. If the snowblower starts to vibrate take all possible precautions. Park the abnormally, disengage the equipment tractor/snowblower on level ground, place drive, stop the engine immediately and the transmission in neutral, set the parking check for cause. -
Page 9: The Tractor
SAFETY PRECAUTIONS - continued RACTOR General Information 1. Read the operator's manual carefully before using tractor. Lack of operating knowledge can lead to accidents. 2. Do not permit anyone but the operator to ride on the tractor. There is no safe place for passengers. -
Page 10: During Operation
SAFETY PRECAUTIONS - continued During Operation Roll-Over Protective Structure (ROPS) (If so equipped) 1. Do allow passengers tractor/snowblower at any time. There is no 1. DO NOT weld, drill or alter the ROPS. safe place passengers this Damaged ROPS must not be straightened equipment. -
Page 11: Maintenance
SAFETY PRECAUTIONS - continued AINTENANCE ALWAYS USE GENUINE PARTS WHEN 10. Do not modify or alter this equipment or REPLACEMENT PARTS ARE REQUIRED components operating functions. If you have questions concerning 1. Keep the tractor and snowblower properly modifications, consult with your dealer. maintained. -
Page 12: Transport
SAFETY PRECAUTIONS - continued RANSPORT TORAGE 1. When driving the tractor and equipment on Before storing the snowblower, certain the road or highway under 25 mph, at night precautions should be taken to protect it or during the day, use flashing amber from deterioration. -
Page 13: Decals
DECALS Replace immediately if damaged Switches Rotation Deflector 5RD2500616 5RD2500784 5RD2500787 5RD2500788 5RD2500782 5RD2500833 5RD2500608 5RD2500815 5RD2500789 5RD2500783 5RD2500783 5RD2500790 5RD2500786 5RD2500791 5RD2500785 OM 0393SB-A... -
Page 14: Assembly
