Page 6
Kunststoffabdeckung Cover e-motion M15 Bei allen Arbeiten an elektronischen Teilen ESD-Schutzmaßnahmen beachten When working at electronic components, the ESD-protective measures must be observed Mit Kunststoff-Reifenheber abnehmen Remove with tire lever Fett (Vaseline) Grease (Vaseline)
Schaltring Switch ring e-motion M15 Bei allen Arbeiten an elektronischen Teilen ESD-Schutzmaßnahmen beachten When working at electronic components, the ESD-protective measures must be observed Zum Entnehmen Verriegelung nach außen drücken To remove push outwards...
Off-Set Prüfung Offset checkup e-motion M15 Offset test (self deactivation) Off-Set Prüfung (Selbstabschaltung) · Remove the e-motion wheel from the wheelchair. · Nehmen Sie das e-motion Rad vom Rollstuhl ab. · Hold the wheel firmly on edge and switch it on.
Page 12
Fernbedienung Remote-Control e-motion M15 Bei allen Arbeiten an elektronischen Teilen ESD-Schutzmaßnahmen beachten When working at electronic components, the ESD-protective measures must be observed Anzugsmoment: 0,75 Nm Torque: 0,75 Nm CR 123A...
Page 13
Fernbedienung Remote-Control e-motion M15 Schwarz Black Lasche zurückziehen Pull back cover Schwarz Black Vor Einbau der Platine rotes und schwarzes Kabel in den Schlitz auf der Platine einlegen Before mounting the pc-board, insert red and black cable into the slot Lasche über Kabel legen...
