Billy Goat CR550H Owner's Manual

Compact power rake
Hide thumbs Also See for CR550H:

Advertisement

Quick Links

Download this manual See also: Owner's/operator's Manual
COMPACT POWER RAKE Owner's Manual
Accessories
SLICING REEL
SLICING BLADES
A complete verti-
A full set of twenty
slicing reel for your
blades for
CR. 20" wide reel
replacement.
for use in grasses
Includes 40 new
that require vertical
capscrews, and lock
cutting, and for
nuts for replacement
assisting in lawn
installation.
overseeding
projects.
P/N 350252
Part No 350245
CR POWER RAKE Owner's Manual
CR550HC, CR550H, CR550HCEU

Replacement Parts

BUMPERS
A complete
replacement set.
44 of 1/2" spacer
bumpers and 4
of 1/4" spacer
bumpers
P/N 350258
P/N 350187
DRIVE
SPACER
BELT
Original
Equipment drive
belt for your CR.
P/N 350207
1
FLAIL SHAFTS
FLAIL BLADES
A full set of four
A complete
shafts for
replacement set.
replacement.
60 of our high
Includes 8 new lock
quality flail
clips for
blades for your
replacement
CR. Includes 8
installation.
new lock clips for
NOTE: We
replacement
recommend
installation.
replacing the shafts
when you replace
flails.
P/N 350251
P/N 350185
Form No F030515D

Advertisement

loading
Need help?

Need help?

Do you have a question about the CR550H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Billy Goat CR550H

Summary of Contents for Billy Goat CR550H

  • Page 1: Replacement Parts

    CR POWER RAKE Owner’s Manual COMPACT POWER RAKE Owner's Manual CR550HC, CR550H, CR550HCEU Accessories Replacement Parts DRIVE SPACER FLAIL SHAFTS SLICING REEL SLICING BLADES FLAIL BLADES BUMPERS BELT A full set of four A complete verti- A full set of twenty...

  • Page 2: Table Of Contents

    CR POWER RAKE Owner’s Manual ABOUT THIS MANUAL ® THANK YOU for purchasing a BILLY GOAT CR Power Rake. Your new machine has been carefully designed and manufactured to provide years of reliable and productive service. This manual provides complete operating and maintenance instructions that will help to maintain your machine in top running order.

  • Page 3: Specifications/Sound And Vibration

    CR POWER RAKE Owner’s Manual SPECIFICATIONS CR550H CR550HC CR550HCEU Engine: HP 5.4 (4.0kW) 5.0 (3.73 kW) 5.0 (3.73 kW) Engine: Model X160TQX2 GC160AQHA GC160AQHL Engine: Type HONDA OHC HONDA OHC HONDA OHC Engine: Fuel Capacity 3.8 qt (3.6L) 2.1 qt (2.0 L) 2.1 qt (2.0 L)

  • Page 4: Intended Use & Instruction Labels

    INSTRUCTION LABELS ® The labels shown below were installed on your BILLY GOAT CR Power Rake. If any labels are damaged or missing, replace them before operating this equipment. Item numbers from the Illustrated Parts List and part numbers are provided for convenience in ordering replacement labels.

  • Page 5: Packing Checklist & Assembly

    NOTE: Items in ( ) can be referenced in the Parts Illustration and Parts List on pages 10-11. Your Billy Goat Power Rake is shipped from the factory in one carton, completely assembled. READ all safety instructions before assembling unit.

  • Page 6: Operation

    CR POWER RAKE Owner’s Manual OPERATION STARTING ENGINE See engine manufacturer’s instructions for type and amount of oil and gasoline used. Engine must be level when checking and filling oil and gasoline. FUEL VALVE: Move fuel valve to "ON" position (when provided on engine). STOP SWITCH: Located on the engine.
  • Page 7 CR POWER RAKE Owner’s Manual VERTI-CUTTING OPERATION SET DEPTH: With engine off, set the raking depth so that the blades just touch on a flat surface (i.e. driveway, or sidewalk). ENGAGE BLADES: Pull back on the bail on the operator’s handle. NOTE: When engaging the blades in heavy load conditions (i.e. heavy thatch, or very uneven turf), push down on the operator’s handle lifting the front wheels slightly.

  • Page 8: Maintenance

    CR POWER RAKE Owner’s Manual MAINTENANCE PERIODIC MAINTENANCE NOTE: Items in ( ) can be referenced in the Parts Illustration and Parts List on pages 10-11. Periodic maintenance should be performed at the following intervals: Maintenance Operation Every Use (daily) Every 25 Hours ...

  • Page 9: Troubleshooting And Warranty Procedure

    CR POWER RAKE Owner’s Manual DRIVE BELT REPLACEMENT NOTE: Takes approx. 10 min. and requires 3/8" socket wrench with extension. 1. Wait for engine to cool and disconnect spark plug. 2. Remove six self-tapping screws (item 65) holding the belt guard (item 21 & 22) in place. Remove the guard. 3.

  • Page 10: Part Illustration & Parts List

    CR POWER RAKE Owner’s Manual CR PARTS DRAWING Part No 350245 Form No F030515D...
  • Page 11 350181 Spring Extension 350300 350300 350300 Bolt Shoulder 1/2" X 1" 500114 500114 500114 ENGINE HONDA 5.0 HP (CR550HC), HONDA 5.5 (CR550H) 430272 430272 600115 ENGINE HONDA 5.5 HP (CR550H) 600115 600115 ENGINE HONDA 5HP (CR550HCEU 350426EU KEY 3/16" X 1"...
  • Page 12 CR POWER RAKE Owner’s Manual FLAIL REEL ASSY 350241-S item PARTS LIST Part No. SHAFT FLAIL BLADE 350141 BLADE FLAIL 350205 SPACER BUMPER 5/8" x 1/2" 350144 SHAFT WA FLAIL REEL 350145 CLIP LOCK 1/2" 350146 WASHER 1/2 SAE 8172011 FLAIL SHAFT KIT 350185 FLAIL BLADE KIT 350251 item...
  • Page 13 CR POWER RAKE Owner’s Manual SLICING BLADE KIT 350187 SPACER BUMPER KIT 350258 item PARTS item PARTS PR500 LIST LIST Part No. Part No. BLADE SLICING REEL 350147 SPACER BUMPER 5/8" x 1/2" 350144 SCREWCAP 1/4-20 X 3/4 HCS ZP 8041004 NUT LOCK 1/4-20 8142004...
