Installation Guide
XX258-10-00
Roughneck V920D Series
Analog Camera Domes
Vicon Industries Inc., 89 Arkay Drive, Hauppauge, New York 11788
Tel: 631-952-2288 Fax: 631-951-2288 Toll Free: 800-645-9116
24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300
Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the
operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed
to be used in life-critical situations and must not be used for this purpose.
www.vicon-security.com
Document Number: 8009-8258-10-00
Issued: 1012
Copyright © 2012 Vicon Industries Inc. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XX258-10-00 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vicon XX258-10-00

Summary of Contents for Vicon XX258-10-00

  • Page 1 24-Hour Technical Support: 800-34-VICON (800-348-4266) UK: 44/(0) 1489-566300 Vicon Industries Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
  • Page 2 LIMITATION OF LIABILITY THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL RESPECTS, HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE SUCH CHANGES...
  • Page 3 WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”...
  • Page 4 FCC COMPIANCE STATEMENT This equipment has been tested and found FCC INFORMATION: to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 6 PRECAUTIONS Before installation, carefully read the manual to ensure correct operation and setup, heeding all warnings and instructions. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Ensure manual is kept in good condition for future use. Do not install the device near any heat sources such as radiators, heat registers, stoves, or other equipment (including amplifiers) that produce heat.

  • Page 7: Table Of Contents

    TABLE OF CONTENTS CONTENTS OF PACKAGE ------------------------------------------------------------------------- 1 INTRODUCTION --------------------------------------------------------------------------------------- 2 CAMERA CONNECTIONS -------------------------------------------------------------------------- 3 INSTALLATION ----------------------------------------------------------------------------------------- 4 LENS ADJUSTMENT --------------------------------------------------------------------------------- 5 OPERATING CAMERA ------------------------------------------------------------------------------- 6 CAMERA ADJUSTMENT ---------------------------------------------------------------------------- 7 EXTERNAL DIMENSION ---------------------------------------------------------------------------- 16 SPECIFICATIONS ------------------------------------------------------------------------------------- 17 CONTENTS OF PACKAGE Installation of the camera must be performed by qualified service personnel in accordance with all local and national electrical and mechanical codes.

  • Page 8: Introduction

    INTRODUCTION The Roughneck® V920D camera provides high-quality images using Sony 1/3” CCD and digital signal processing LSIs. Features: 1/3" Super-HAD CCD Super High-Resolution (700 TVL) Day & Night (Auto, Manual, External, Filter delay, Change level adjust) 0.1Lux (Color), 0.01 Lux (BW) @ F/1.2, 50IRE Auto Electronic Shutter [1/50 (60) ~ 1/100,000] and manual electronic shutter modes [1/50 (60) ~ 1/10,000] Sens-Up (~x256)

  • Page 9: Camera Connections

    CAMERA CONNECTIONS Connection Cable Description COLOR Description AC24V/DC12V WHITE AC24V/DC12V BLUE RS485(-) GREEN RS485(+) YELLOW ALARM OUT GRAY DN EXT-IN BLACK&WHITE DN EXT-OUT BLACK SKY BLUE UTP+(Option) PINK UTP- (Option) 1) External Day/Night Control Select Day/Night (D/N) mode using external equipment by connecting control lines to the appropriate terminals.

  • Page 10: Installation

    INSTALLATION 1. Loosen the four Torx screws located midway up the front of the housing; leave the screws intact in the front portion. (Fig. 1) 2. Drill the mounting location, using the drilling guide label. (Fig. 2) 3. Attach the housing to the ceiling using suitable fasteners; M6x35 tapping screws are supplied for use if suitable.

  • Page 11: Lens Adjustment

    LENS ADJUSTMENT Field of view: Adjust setting from Telephoto (T) to wide (W) field of View. Focus: Adjust lens focus from near (N) to infinity. DC AUTO IRIS LENS 2.8~12mm 1/3" CCD Image Size 2.8-12mm Focal Length 1 : 1.4 Ape.

  • Page 12: Operating Camera

    OPERATING CAMERA Right Down Left Enter Test Video Output < Navigating the Menu System > 1) Menu: Represents the present menu subject on top of screen. When using Multi-Camset, CAM ID and “camset” name included. Common Headers: : Currently active menu item is displayed. Move with Up/Down keys. There is sub-menu.

  • Page 13: Camera Adjustment

    CAMERA ADJUSTMENT <White Balance> 1) ATW/Wide Mode: No limits in the range of color temperature. 2) ATW/Indoor Mode: Suitable for low color temperature. - CRS (Color Rolling Suppression) Mode supported. NOTE: * When the CRS is selected, it will be processed in the following order: Checking Condition: Checking current environment within the range.
  • Page 14 3) Low Light: If using UDF function, this function must be disabled. - AGC: Boosts the signal and adjusts the brightness (Off/Low/Mid/High). - Sens-Up: By summing multiple fields, adjusts the proper brightness in low light conditions (2X~ 256X). - Apert: In low light conditions, reduce noise by lowering the sharpness value. - Color: In low light conditions, reduce noise by lowering the color value.
  • Page 15 - Output Select: Specify the outputs for each function to be enabled; press [ENTER] key to select output of each detection zone. Alarm: Trigger alarm to output port. Communication: Event string sends on RS-485. Screen: Display on screen. Back: return to previous menu. - Detections Motion: General motion detection.
  • Page 16 Line: Line: Select Start/End Point. If you select one of start/end, the active point is displayed. Move the point with 4-arrow keys; press [ENTER] key to finish editing point. Posi: Adjust area position with 4-arrow keys. - MD Event NOTE: * The MD event detection can be inaccurate.
  • Page 17 *) Not supported in Simple mode. Detect object moving. From top to enter of Rect In & Out area, detecting direction of moving out. Direction *) Don’t use as a signal for starting video recording. *) Not supported in Simple mode. Detect object moving.
  • Page 18 Rst Time (sec): Time to release if windy object stays with no motion 3) Display Setup: Configuration for information on screen. NOTE: * Priority: Abandon/Absent > Loiter > Moving Object > Windy * Same priority: large object size order Alarm: Represent alarm icon on right-top side of screen. Counter: Represent counting on left-bottom.

  • Page 19: System Setup

    - No Motion(s): Adjust Interval while no motion. - Motion (0.1s): Adjust Interval while motion exists. <System Setup> 1) General - Cam Info: Display camera basic information. NOTE: * Cam ID/Baud rate/Protocol/Lens Type/CCD Type/Video System/Firmware Version - System Lock: System locking by 4-character PID (Lock/Unlock). - Change PID: Change PID used in the system lock.
  • Page 20 Accept: Store WPC result and return to precious menu. Dynamic Automated white pixel compensation for non-compensated pixel using static method; no limits of compensation pixel number. Select level (Low/Mid/High). Higher value setting compensates more pixels. NOTE: * If the scene contains high frequency components, this can cause a loss. Static/Manual: Manual white pixel compensation by appointment method.
  • Page 21 NOTE: * If iris speed is too high, AE hunting can occur. * If iris speed is too low, IRIS adjustment can operate too slowly. 4) LLC (Line Lock Control) Active only when AC power is used. Select Int (Internal)/Ext (External) mode. If mode is set to Ext, Sync Phase can be adjusted.

  • Page 22: External Dimension

    EXTERNAL DIMENSIONS unit: mm 0.1 in. (2.5mm) thick Window Size 3.9 in. (99mm) diameter 1.66 lb (760g) Weight – Unit: 2.11 lb (960g) Shipping: - 16 -...

  • Page 23: Specifications

    SPECIFICATIONS ITEM V920D-N311 V920D-N311-P ELECTRICAL Input Voltage Dual (12 VDC, 24 VAC ±10%) Power Consumption 3.5 Watts (300mA) Power Connector 2-Pin Terminal Block VIDEO Image Device 1/3" Sony EXview 960H CCD II Total Pixels 1020 (H) x 508 (V) 1020 (H) x 596 (V) Effective Pixels 976 (H) x 494 (V) 976 (H) x 582 (V)
  • Page 24 MEMO...
  • Page 25 MEMO...

  • Page 26: Shipping Instructions

    Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write Vicon for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the Vicon employee who issued the R.A.

  • Page 27: Vicon Standard Equipment Warranty

    “autopan” or “tour” modes of operation. Such continuous operation is outside the scope of this warranty. Any product sold as “special” or not listed in Vicon’s commercial price list: One year from date of original retail purchase.
  • Page 28 Vicon Industries Inc. Corporate Headquarters 89 Arkay Drive Hauppauge, New York 11788 631-952-2288 800-645-9116 Fax: 631-951-2288 Vicon Europe Headquarters Brunel Way Fareham, PO15 5TX United Kingdom +44 (0) 1489 566300 Fax: +44 (0) 1489 566322 Vicon Germany Kornstieg 3 D-24537 Neumuenster...

This manual is also suitable for:

V920d series
