Available settings are explained as follows:
Item
Enable Wireless LAN Check the box to enable wireless function.
Mode
Channel
Extension Channel
Rate
Phy Mode
Security
Description
At present, VigorAP 900 can connect to 11b only, 11g only,
11n only, Mixed (11b+11g), Mixed (11g+11n) and Mixed
(11b+11g+11n) stations simultaneously. Simply choose
Mixed (11b+11g+11n) mode.
Means the channel of frequency of the wireless LAN. The
default channel is 11. You may switch channel if the selected
channel is under serious interference. If you have no idea of
choosing the frequency, please select AutoSelect to let
system determine for you.
With 802.11n, there is one option to double the bandwidth per
channel. The available extension channel options will be
varied according to the Channel selected above.
If you choose 11g Only, 11b Only or 11n Only, such feature
will be available for you to set data transmission rate.
Data will be transmitted via HTMIX mode.
Each access point should be setup to the same Phy mode for
connecting with each other.
Select WEP, TKIP or AES as the encryption algorithm. Type
the key number if required.
55
VigorAP 900 User's Guide
