Available settings are explained as follows:
Item
LAN-A IP Network
Configuration
LAN-B IP Network
VigorAP 900 User's Guide
Description
Enable DHCP Client – When it is enabled, VigorAP 900 will
be treated as a client and can be managed / controlled by AP
Management server offered by Vigor router (e.g., Vigor2860).
IP Address – Type in private IP address for connecting to a local
private network (Default: 192.168.1.2).
Subnet Mask – Type in an address code that determines the size
of the network. (Default: 255.255.255.0/ 24)
Default Gateway – In general, it is not really necessary to
specify a gateway for VigorAP 900. However, if it is required,
simply type an IP address as the gateway for VigorAP 900. It
will be convenient for the access point acquiring more service
(e.g., accessing NTP server) from Vigor router.
Enable Management VLAN – VigorAP 900 supports tag-based
VLAN for wireless clients accessing Vigor device. Only the
clients with the specified VLAN ID can access into VigorAP
900.
VLAN ID – Type the number as VLAN ID tagged on the
transmitted packet. "0" means no VALN tag.
IP Address – Type in private IP address for connecting to a local
