Summary of Contents for Concept Pro AIR701/IRH
- Page 1 AIR701/IRH Weatherproof Zoom Colour/Mono IR Camera USER MANUAL P o w e r e d T ECH NO LOGY AD V A N C E D IN F R A RE D...
-
Page 2: Packing Contents
The Concept Pro AIR701/IRH is a weatherproof IR camera, suitable for monitoring areas in hostile conditions and in low light. Fixing Bolt for Sunvisor Mounting Bracket Photo Sensor Bracket Adjustment IR LED Service Video Outputt Sunvisor PACKING CONTENTS EASY FIT BNC CONNECTOR... - Page 3 CAUTION This installation should be made by a qualified service person and should abide to all local codes. In order to prevent electronic shock and/or destroy waterproof seals, do not loosen any screws on the camera body. Adjust the sunshield cover to avoid exposure of direct sunlight on the lens. Do not touch the front glass directly.
-
Page 4: Installation
INSTALLATION Important: Ensure all cautionary procedures are observed during installation. It is recommended the camera is tested during the most demanding environmental conditions such as low light or bright sunlight to ensure continuity of effective CCTV monitoring. You may find the use of an ND filter helpful. Remove the camera unit carefully from the box, reserving the accessory contents in a safe place. -
Page 5: Bnc Connector
CONNECTION RS485 CONNECTOR BNC CONNECTOR POWER CONNECTOR Connect the video out port to your video cable running to the monitoring recorder. Check the power supply is of the correct level and connect your power supply into the power port on the Camera. -
Page 6: On-Screen Display (Osd)
ON SCREEN DISPLAY (OSD) The Service Video Out panel contains a power indicator and test monitor connection for ease of adjusting the camera settings during installation. 1 2 3 4 5 6 7 8 OSD OUTPUT CABLE TEST MONITOR The power indicator LEDs display the power supply being fed into the camera and whether it is too high, low or correct. - Page 7 FOCUS FOCUS FOCUS MODE AUTO MANUAL PUSH [PRESS ENT] FOCUS DIST 1CM ~ 3M ZOOM START x001 ~ x027 ZOOM END x001 ~ x270 ZOOM SPEED 1 ~ 3 REFRESH MODE ON / OFF REFRESH TIME [SET TIME] INITIAL OFF / ON EXPOSURE EXPOSURE AE MODE...
-
Page 8: White Balance
NORMAL / C1 / C2 / L1 / L2 / U1 / U2 / D1 / D2 / R1 / R2 WHITE BALANCE WHITE BAL MANUAL RED CONT 0 ~ 255 BLUE CONT 0 ~ 255 INDOOR OUTDOOR PUSH [PRESS ENT] 3D-DNR 3D-DNR OFF / LOW / MIDDLE / HIGH... - Page 9 SPECIAL SPECIAL D-EFFECT OFF / V-FLIP / ROTATE / MIRROR SHARPNESS 1 ~ 16 FREEZE OFF / ON COLOUR ON / OFF MOTION ZONE SELECT CENTRE / WHOLE / UPPER / OUT ZONE STATE OFF / ON SENSITIVITY 1 ~ 15 INITIAL OFF / ON PRIVACY...
- Page 10 DIMENSIONS 302.2mm(11.89”) 40mm(1.57”)
- Page 11 300mm(11.81”) 319mm(12.56”)
- Page 12 AIR701/IRH ITEM Twin IR Zoom Colour/Monochrome (Removable IR Cut Filter) Type Signal System 1/4 inch SONY Exview CCD Image Sensor 795(H)x596(V) 470K Total Pixels 752(H)x582(V) 440K Effective Pixels 27x. F1.6(W) ~ 3.7(T) ( ± 7 %), f = 3.6 ~ 97.2 mm ( ± 7 %)
- Page 13 AIR CAMERA RANGE AIR15 Range 18 IR LEDs 420 TVL / 520 TVL Options 3.6mm / 6mm Fixed Lens Options 182 x 70 x 81mm (WxHxD) AIR30 Range 42 IR LEDs Varifocal Lens Options Service Video Output Option On Screen Display Option External Lens / Zoom Adjustments 202 x 85 x 118mm (WxHxD) AIR45 / 50 Range...
