Concept Pro CVP9314DNIR-AHD User Manual

Vandal resistant ir ip eyeball camera
Hide thumbs
1
2

Advertisement

Quick Links

Download this manual
OSD
OSD Controller
EXPOSURE
UP
RIGHT
LEFT
EXPOSURE, SENS-UP:AUTO
DOWN
MENU / ENTER
EXPOSURE, D-WDR:ON
OSD MAIN MENU
LENS:
MANUAL | DC ˩
EXPOSURE:
˩
BACKLIGHT:
OFF | BLC ˩ | HSBLC ˩
WHITE BAL:
AWB | ATW | AWC SET ˩ <set according to current
scene> | INDOOR | OUTDOOR | MANUAL ˩
EXPOSURE, DEFOG:AUTO
DAY&NIGHT:
COLOR | B / W ˩ | EXT ˩ | AUTO ˩
NR:
˩
SPECIAL:
˩
ADJUST:
˩
EXIT:
SAVE&END ˩ | NOT SAVE ˩ | RESET ˩
LENS:DC
MODE:
INDOOR | OUTDOOR ˩
IRIS SPEED:
0 to 15
RETURN:
RET ˩ | SAVE&END ˩
BACKLIGHT:BLC
LENS:DC, MODE:OUTDOOR
MIN SHU:
1/25
MAX SHU:
1/50 | FLK | 1/200 | 1/400 |
1/1000 | 1/2000 | 1/5000 |
1/10000 | 1/50000
RETURN:
RET ˩ | SAVE&END ˩
BACKLIGHT:HSBLC
SHUTTER:
AUTO | 1/25 | 1/50 | FLK | 1/200 | 1/400 | 1/1000 |
SELECT:
AREA1 | AREA2 | AREA3 | AREA4
1/2000 | 1/5000 | 1/10000 | 1/50000 | x2 | x4 | x6 |
DISPLAY:
OFF | ON ˩ <set onscreen with cursor>
x8 | x10 | x15 | x20 | x25 | x30
BLACK MASK: ON | OFF
AGC:
0 to 15
LEVEL:
0 to 100
SENS-UP:
OFF | AUTO ˩
MODE:
ALL DAY | NIGHT ˩
BRIGHTNESS: 1 to 100
DEFAULT ˩:
<reset to default>
D-WDR:
OFF | AUTO | ON ˩
RETURN:
RET ˩ | SAVE&END ˩
DEFOG:
OFF | AUTO ˩
RETURN:
RET ˩ | SAVE&END ˩
BACKLIGHT:HSBLC, MODE:NIGHT
AGC LEVEL:
0 to 255
RETURN:
RET ˩ | SAVE&END ˩
SENS-UP:
x2 | x4 | x6 | x8 | x10 | x15 | x20 | x25 | x30
RETURN:
RET ˩ | SAVE&END ˩
WHITE BALANCE:MANUAL
LEVEL:
0 to 8
BLUE:
0 to 100
RETURN:
RET ˩ | SAVE&END ˩
RED:
0 to 100
RETURN:
RET ˩ | SAVE&END ˩
POS/SIZE ˩:
<set onscreen with cursor>
DAY&NIGHT:B/W
GRADATION:
0 to 2
DEFAULT ˩:
<reset to default>
BURST:
ON | OFF
RETURN:
RET ˩ | SAVE&END ˩
IR SMART:
ON ˩ | OFF
RETURN:
RET ˩ | SAVE&END ˩
LEVEL:
LOW | MIDDLE | HIGH
DAY&NIGHT:B/W, IR SMART:ON
AREA ˩:
<set onscreen with cursor>
DEFAULT ˩:
<reset to default>
LEVEL:
0 to 15
RETURN:
RET ˩ | SAVE&END ˩
AREA ˩:
<set onscreen with cursor>
RETURN:
RET ˩ | SAVE&END ˩
DAY&NIGHT:EXT
SPECIAL, MOTION:ON
DgN (DELAY): 0 to 60
NgD (DELAY) : 0 to 60
RETURN:
RET ˩ | SAVE&END ˩
DAY&NIGHT:AUTO
DgN (AGC):
0 to 54
DgN (DELAY): 0 to 60
SPECIAL, MOTION:ON, ALARM
NgD (AGC) :
0 to 54
DgN (DELAY): 0 to 60
RETURN:
RET ˩ | SAVE&END ˩
NR
2DNR:
OFF | LOW | MIDDLE | HIGH
SPECIAL, PRIVACY:ON
3DNR:
OFF | LOW | MIDDLE | HIGH
RETURN:
RET ˩ | SAVE&END ˩
SPECIAL
CAM TITLE:
OFF | ON ˩ <set onscreen with cursor>
D-EFFECT:
˩
MOTION:
OFF | ON ˩
PRIVACY:
OFF | ON ˩
LANGUAGE:
ENG ˩ | CHN1 ˩ | CHN2 ˩ | GER ˩ | FRA ˩ | ITA ˩ |
SPECIAL, DEFECT
SPA ˩ | POL ˩ | RUS ˩ | POR ˩ | NED ˩ | TUR ˩
<immediate effect>
DEFECT:
˩
RS485:
˩
RETURN:
RET ˩ | SAVE&END ˩
SPECIAL, D-EFFECT
SPECIAL, DEFECT, LIVE DPC:ON
FREEZE:
ON | OFF
MIRROR:
OFF | MIRROR | V-FLIP | ROTATE
NEG.IMAGE:
ON | OFF
SPECIAL, DEFECT, WHITE DPC:ON
SELECT:
AREA1 | AREA2 | AREA3 | AREA4
POS/SIZE:
˩ <set onscreen with cursor>
DISPLAY:
OFF | ON ˩ <set onscreen with cursor>
START:
˩ <onscreen instruction>
SENSITIVITY:
0 to 100
DPC VIEW:
ON | OFF
COLOR:
RED | GREEN | BLUE | WHITE
LEVEL:
0 to 100
TRANS:
0.00 | 0.25 | 0.50 | 0.75 | 1.00
AGC:
0 to 15
ALARM:
˩
SENS-UP:
x2 | x4 | x6 | x8 | x10 | x15 | x20 | x25 | x30
DEFAULT:
˩<reset to default>
RETURN:
RET ˩ | SAVE&END ˩
RETURN:
RET ˩ | SAVE&END ˩
SPECIAL, DEFECT, WHITE DPC:ON
VIEW TYPE:
OFF | BLOCK | OUTLINE | ALL
POS/SIZE:
˩ <set onscreen with cursor>
SPECIAL, DEFECT,BLACK DPC:ON
OSD VIEW:
ON | OFF
START:
˩ <onscreen instruction>
ALARM OUT:
ON | OFF
DPC VIEW:
ON | OFF
TIME:
0 to 15
LEVEL:
0 to 100
RETURN:
RET ˩ | SAVE&END ˩
RETURN:
RET ˩ | SAVE&END ˩
ADJUST
SELECT:
AREA1 | AREA2 | AREA3 | AREA4
SHARPNESS:
OFF | AUTO ˩
DISPLAY:
OFF | MOSAIC ˩| INV. ˩| COLOR ˩
MONITOR:
LCD ˩ | CRT ˩
<set onscreen with cursor>
LSC:
ON | OFF
COLOR:
BLACK | RED | BLUE | YELLOW | GREEN | CYAN |
VIDEO OUT:
PAL | NTSC
USER | WHITE
RETURN:
RET ˩ | SAVE&END ˩
TRANS:
0.25 | 0.50 | 0.75 | 1.00
DEFAULT ˩:
<reset to default>
RETURN:
RET ˩ | SAVE&END ˩
ADJUST, MONITOR:LCD
GAMMA:
USER | 0.45 | 0.50 | 0.55 | 0.60 | 0.65 | 0.70 |
LIVE DPC:
OFF | ON ˩
0.75 | 0.80 | 0.85 | 0.90 | 0.95 | 1.00
WHITE DPC:
OFF | ON ˩
BLUE GAIN:
0 to 100
BLACK DPC:
OFF | ON ˩
RED GAIN:
0 to 100
RETURN:
RET ˩ | SAVE&END ˩
RETURN:
RET ˩ | SAVE&END ˩
ADJUST, MONITOR:CRT
BLUE GAIN:
0 to 100
AGC LEVEL:
0 to 255
RED GAIN:
0 to 100
LEVEL:
0 to 100
RETURN:
RET ˩ | SAVE&END ˩
RETURN:
RET ˩ | SAVE&END ˩
CVP9314DNIR-AHD
CVP9314DNIR-AHD
Vandal Resistant IR IP Eyeball Camera
Vandal Resistant IR IP Eyeball Camera
USER MANUAL
