Summary of Contents for Concept Pro CVP9328DNIR-AHD
- Page 1 CVP9328DNIR-AHD CVP9328DNIR-AHD-G Vandal Resistant IR IP Eyeball Camera Vandal Resistant IR IP Eyeball Camera USER MANUAL...
- Page 2 CAUTION CAUTION Installation should be made by a qualified service person and should adhere to all local codes. In order to prevent electric shock and avoid damage to waterproof seals, do not loosen any screws on the camera body. Adjust the sunshield to avoid exposing the lens to direct sunlight. Do not touch the front glass.
- Page 3 FIXING TO A WALL Important: Ensure all cautionary procedures are observed during installation. It is recommended the camera is tested during the most demanding environmental conditions such as low light or bright sunlight to ensure continuity of effective CCTV monitoring. BASE Remove the camera unit carefully from the box keeping the accessory contents in a safe place.
- Page 4 INSTALLATION CONNECTION Connect the video out port to your video cable To assist in installation when using an analogue running to the monitor / recorder test monitor, the camera can be switched to an Check the power supply is of the correct level analogue output by pushing the joystick fully and connect your power supply into the power left for several seconds.
- Page 5 ON SCREEN DISPLAY (OSD) ON SCREEN DISPLAY (OSD) OSD Controller Shift the button UP for 5 seconds. This will switch to a 960H ready output. Shift the button to the LEFT for 5 seconds. This will switch to the 1080p AHD output.
- Page 6 ON SCREEN DISPLAY (OSD) MAIN MENU ⏎ ⏎ DAY-NIGHT ⏎ VIDEO SETTING ⏎ LANGUAGE: ENGLISH, CHINESE, SPANISH, KOREAN, ITALIAN RESET ⏎ SAVE-EXIT ⏎ EXIT EXPOSURE BRIGHTNESS: 1-20 EXPOSURE MODE: GLOBE, CENTER, BLC, FLC LV (EXPOSURE MODE = BLC): GAIN: RETURN ⏎...
- Page 7 DIMENSIONS...
- Page 8 FEBRUARY 18 Design and specification are subject to change without notice.
