Concept Pro AIR3026-HD User Manual

ON SCREEN DISPLAY (OSD)

The Service Video Out panel contains a power indicator and test monitor connection for
ease of adjusting the camera settings during installation. EXPOSURE
*Please note: The Service Video Out is standard definition
This is an analogue Video Output only, used for setting up via a test monitor.
1 2 3
5
PO PN PL
VIDEO
OSD OUTPUT CABLE TEST MONITOR
AIR3026-HD 4
The power indicator LEDs display the power supply being fed into the camera and whether it
is too high, low or correct.
1. "PO": Red LED - Voltage is too high
2. "PN": Green LED - Voltage is correct
3. "PL": Yellow LED - Voltage is too low
4. Extra video out and OSD control connector - Attach your Video test monitor with the
service video cable enclosed in your camera box. The camera footage will appear on your
test monitor and zoom/focus adjustments can be carried out as the installation requires.
5. Analogue Output (4:3 Video Format)
WHITE BALANCE
OSD Controller
1) Press "U" to navigate upwards
U
2) Press "D" to navigate downwards
L 3) Press "L" to navigate left
R
ENT
4) Press "R" to navigate right
D
5) Press "ENT" to open menu/sub-menu
Please note: depending on which "Model" is selected, varies the
options in the sub menus.
IMAGE SHARPNESS 0 ~ 10
EXPOSURE BRIGHTNESS 0 ~ 20 IMAGE OFF / H / V / H&V
LENS DC / MANUAL FREEZE OFF / ON
IR CDS SHUT SPEED AUTO E. ZOOM X1 ~ X32
D&N/ Colour MANUAL 1/30 ~ 1/60000 HLC OFF
ON LEVEL
(Red text) DSS OFF / X2 / X3 / X4
IR SMART AGC ON / OFF COLOUR
(Blue Text) WDR / BLC OFF ACE OFF / ON
WDR 0 ~ 3 OFF / ON DNR AUTO OFF / LOW / MIDDLE / HIGH
BLC BLC OSD 0 ~ 20
BLC POS-X 0 ~ 20
BLC POS-Y 0 ~ 20
BLC SIZ-X 0 ~ 20 INTELLIGENCE
BLC SIZ-Y
DAY & NIGHT MODE AUTO / DAY / NIGHT / EXT
INTELLIGENCE
DELAY 0 ~ 255s
PRIVACY OFF
BURST ON / OFF
ON MASK 0 ~ 31
THRS LOW / MIDDLE / HIGH
MODE OFF / ON
GAP LOW / MIDDLE / HIGH
X-POS ADJUST
SMART IR LED OSD OFF / ON
Y-POS ADJUST
LED POS-X 0 ~ 20
X-SIZ ADJUST
LED POS-Y 0 ~ 20
Y-SIZ ADJUST
LED SIZ-X 0 ~ 20
COLOUR SELECT COLOUR
LED SIZ-Y 0 ~ 20
TRANS 0 ~ 4
MOTION OFF
ON RESOLUTION 0 ~ 4
0 ~ 20
SENSITIVITY
AREA WHOLE
EACH
AWB AUTO
PRESET PUSH TO APPLY
MANUAL RED GAIN 0 ~ 20
BLUE GAIN 0 ~ 20
SMART ZOOM OFF
INDOOR ON
OUTDOOR
CHROMA 0 ~ 20
0 ~ 255S
INTERVAL
0 ~ 255S
DWELL
MODEL
SPECIAL FUNCTIONS
IMAGE SENSOR
TOTAL PIXELS
SPECIAL FUNC SHADING DET OFF / ON
ACTIVE PIXELS
SHADING OFF / ON
DEFECT DET OFF / ON
LENS
DEFOG OFF
ON LEVEL SCANNING SYSTEM
SYSTEM NTSC 30fps
RESOLUTION
0 ~ 20
PAL 25fps
SELECT COLOUR
HD FORMAT 1080P / 720P
PG OFF / ON
MIN. ILLUMINATION
CVBS OFF / ON
COMM ID 1 ~ 255
BAUDRATE 2400 ~ 115200
IR DISTANCE
PROTOCOL PELCO-D / PELCO-P /
VIDEO OUTPUT
UPDATE
S/N RATIO
DISPLAY ELECTRICAL
POWER SOURCE
DISPLAY DISP SEL ID OFF / ON
POWER CONSUMPTION
TITLE OFF / ON
EZOOM OFF / ON GENERAL
SET TITLE OPENS KEYBOARD
OPERATING TEMPERATURE
STORAGE TEMPERATURE
DIMENSION
WEIGHT
AREA 0 ~ 2 FUNCTION
MODE OFF / ON
MENU
X-POS
ADJUST
Y-POS
ADJUST EXPOSURE
X-SIZ ADJUST
BRIGHTNESS
Y-SIZ ADJUST
LENS
IN / OUT 0 ~ 8S
SHUT SPEED
DWELL 0 ~ 8S
WAIT 0 ~ 8S
DSS
AGC
WDR/BLC
DAY&NIGHT
SMART IR
WHITE BAL
Design and specification are subject to change without notice.
AIR3026-HD
1/3" CMOS 0 ~ 10 steps
SHARPNESS
2010(H) x 1108(V) = 2,227,080 (pixel) Off / H / V / H&V
MIRROR
1944(H) x 1092(V) = 2,122,848 (pixel) Off / On
FREEZE
2.8~10mm Varifocal
x1 ~ x32
E.ZOOM
Progressive
Off / On
HLC
Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps)
Off / On
ACE
Analogue : 700TVL
Off / On
DEFOG
0.0 Lux (IR LED On) (27 Pieces IR LED)
Off / Low / Middle / High / Auto
DNR
Color DSS : 0.002 lux , BW DSS : 0.001 lux
INTELLIGENCE
15~20m (49.2~65.6ft)
Off / On (32 points)
PRIVACY
HD-SDI
Off / On (4 points)
MOTION
Analog : NTSC, PAL(without WDR)
SPECIAL FUNC
more than 50dB (AGC off)
Off / On
SHADING DET
Off / On
SHADING
DC12V±10%
Off / On
DEFECT DET
DC: 380mA (Max)
NTSC / PAL
SYSTEM
1080P / 720P
-10ºC ~ +50ºC (Humidity : 0%RH ~ 80%RH) HD FORMAT
Off / On
-20ºC ~ +60ºC (Humidity : 0%RH ~ 90%RH) PG
202 x 85 x 118mm(7.95" x 3.35" x 4.65") CVBS Off / On
1300g (45.86oz) COMM ID (1 ~ 255)
BAUDRATE ( 2400 / 4800 / 9600 / 19200 / 38400 / 57600/115200 )
D&N / COLOUR / IR SMART / IR CDS
PROTOCOL (PELCO-P / PELCO-D / UPDATE)
RESET On ( Default )
0 ~ 20 steps
LANGUAGE English
DC / Manual
OSD TEXT 0 ~ 9 , A ~ Z , a ~ z
Auto / Manual ( 1/30(1/25) ~ 1/60000 )
Off / x2 / x3 / x4
Off / On
Off / WDR / BLC
Auto / Day / Night / Ext
Off / On
Auto / Preset / Manual / Indoor / Outdoor
Design and specification are subject to change without notice.
AIR3026-HD
Weatherproof Colour/Mono IR Camera
USER MANUAL
T E C H N O L O G Y
ADVA NCED INFR ARED
