Astria Ladera-BK Installation And Operation Instructions Manual

Advertisement

SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
A French manual is available upon request. Order P/N 900114-00.
Ce manuel d'installation est disponible en francais, simplement en faire
la demande. Numéro de la pièce 900114-00.
• Hot! Do not touch! The glass and
surfaces of this appliance will be hot
during operation and will retain heat
for a while after shutting off the appli-
ance. Severe burns may result.
• Carefully supervise children in the
same room as appliance.
• If small children are present in the home, it is
recommended that this appliance be fitted with
an adjustable safety gate or barrier screen.
C
US
WARNING
Listed to standards:
ULC-S610 and UL-127
Report # 14-181
EPA Cert. No. 706
P900113-00
INSTALLATION AND

OPERATION INSTRUCTIONS

Ladera™
EPA Wood-Burning Fireplace
P/N 900113-00 REV. B 03/2015
MODELS
Ladera-BK
This installation manual will enable you to obtain a safe, efficient
and dependable installation of your fireplace system. Please read
and understand these instructions before beginning your installation.
Do not alter or modify the fireplace or its components under any cir-
cumstances. Any modification or alteration of the fireplace system,
including but not limited to the fireplace, chimney components and
accessories, may void the warranty, listings and approvals of this system
and could result in an unsafe and potentially dangerous installation.
IHP wood-burning fireplaces are designed for use as a supplemental
heater. They are not intended for continuous use as a primary heat
source.
WARNING
• The fireplace cannot be operated without a door
or firescreen. Consult your dealer to select the
correct replacement door or firescreen.
• The fireplace is equipped with a blower, electri-
cal connection must be made prior to fireplace
installation
• Important! To assure proper alignment of glass
doors: Install this fireplace in a square and
plumb condition, using shims as necessary at
sides and/or bottom.
• Install the fireplace only as described in these
instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ladera-BK and is the answer not in the manual?

Questions and answers

Summary of Contents for Astria Ladera-BK

  • Page 1: Operation Instructions

    Ladera™ EPA Wood-Burning Fireplace P/N 900113-00 REV. B 03/2015 MODELS Ladera-BK This installation manual will enable you to obtain a safe, efficient and dependable installation of your fireplace system. Please read and understand these instructions before beginning your installation. Do not alter or modify the fireplace or its components under any cir- cumstances.
  • Page 2: Safety Rules

    IMPORTANT! GENERAL SAFETY WARNING WARNING PRECAUTIONS. READ AND UNDERSTAND THESE SAFETY Be careful adding wood fuel to Use care when selecting window RULES BEFORE YOUR FIRST FIRE. treatments for windows located the fire or handling fireplace tools near the fireplace. Avoid using such as shovels, tongs or pokers.
  • Page 3: Table Of Contents

    CONGRATULATIONS! OPTIONAL EqUIPMENT Order Separately - See Pages 22 through 25 When you purchased your new fireplace, you joined the ranks of thousands of individuals whose answer to their home heating needs reflects their concern for aesthetics, efficiency • Additional Equipment (optional) and our environment.
  • Page 4: Starting And Maintaining A Fire

    First Fires the firebox can be diminished by moving the For instance, a long chimney will necessitate air combustion control from left to right. The closing the damper more. To obtain the proper Before using the fireplace make sure to remove primary air is fully opened when the air control combustion, close the damper completely, then the plastic wrapping and EPA label on door.
  • Page 5: Important Cautions

    A. Negative pressure in the house Smoke Detectors Chimney Maintenance As the fire burns, air goes up the chimney. Regular chimney inspection and maintenance This air must be replaced through leakage combined with proper operation will prevent Since there are always several potential sources into the house or through the outside air duct chimney fires.
  • Page 6: Top Baffle Removal

    Top Baffle Removal Prior to Cleaning The Chimney Before starting to clean your chimney, we recommend that you remove the top baffle to avoid creosote dust collection at the top of the baffle. Follow these steps to set the top baffle out of the way: 1.
  • Page 7: Disposing Of Ashes

    DISPOSING OF ASHES Remove ashes only when the fire is out and the ashes are cold (24 to 48 hours after the fire is out). Do not leave the ashes in the house as they give off carbon monoxide and other toxic gases. WARNING Disposal of Ashes: Ashes should 1.
  • Page 8: Glass Care - Replacement

    GLASS CARE Gasket Replacement If possible, you should choose a location where Remove the door from the unit (see Page 7) the chimney will pass through the house without Glass Replacement cutting floor or roof joists (see fireplace dimen- and lay it on a clean unabrasive surface. To The glass used for the Ladera™...
  • Page 9: Optional Cast Facade Installation

    Optional Cast Facade installation WARNING: THE HEARTH EXTEN- Install the Facade per instructions provided in Fireplace SION IS TO BE INSTALLED ONLY Facade Kit (ordered separately - see Page 22). AS ILLUSTRATED. Framing, Facing And Mantel The crack between the fireplace The construction of the framing, facing, and and the hearth extension must be Safety Metal Strip...
  • Page 10: Framing Dimensions

    Back Wall of Chase/Enclosure OUTSIDE CHASE Including Finishing Materials, if any Corner Installation FRAMING DIMENSIONS 20-5/8” 35-7/8 911 mm 37-5/8” 956 mm * Zero Clearance 29-1/8” 740 mm From Back Spacer to Wall 12-1/2” 318 mm 70” 1778 mm 35” 889 mm Rough Framing Face (Unfinished Shown) 18-5/8”...
  • Page 11: Nailing Flanges

    Insulate Joists Same As Ceiling Insulated Chase Construction Storm Collar Roof Support Flashing Draft Stops Attic Radiation Shield NOTE: It is recommend- Floor ed that the chase walls Ceiling Firestop and floor be insulated in Wall the same manner, using the same insulation, as CTDT Termination...
  • Page 12: Fireplace Blower

    Once the repair is done, it is mandatory to apply a new high temperature black cement Only non-combustible mate- Frame (Mill-Pack, available from your retailer) rial should be superposed or projecting over the front of sealing the access plate and all screw holes. Grill the fireplace.
  • Page 13: Central Forced Air Kit

    Central Forced Air Kit Rain Cap NOTE: Not tested under EPA certification. If installed, this appliance no longer qualifies for EPA certification. Flashing Collar Flashing The knock-outs provided on the back and on the sides of the Ladera™ fireplace allow the Roof Support connection of insulated flexible pipe which Attic Radiation Shield...
  • Page 14: Outside Air Kit

    Adaptor Insulated Flex Pipe Figure 17 Insulation Blower Flex 5” Diameter Tightening Collar Aluminum Tape Figure 18 OUTSIDE AIR KIT The outside air kit is included with the Ladera™ fireplace, however installation is only mandatory if AC chimney is installed. During opera- tion, the fireplace requires fresh air for combustion and draws air out of the house.
  • Page 15: Chimney System

    Outside Air Installation THE CHIMNEY SYSTEM The outside air assembly may be installed according to the following Chimney Installation Notes requirements: 1. If possible, install an interior chimney as it will provide better perfor- A) Duct length should be kept to a minimum. The maximum length of a mance.
  • Page 16: Chimney Installation Instructions

    CHIMNEY INSTALLATION Attic Radiation Shield INSTRUCTIONS Attic Radiation ASHT / S2100 Air Cooled Pipe * Shield HT6103+ / HT6000+ 1. Cut and frame the holes in the ceiling, floor Solid Packed Pipe * and roof where the chimney will pass (see Figure 23).
  • Page 17: Offset Chimney Installation

    After reaching the location requiring the elbow, proceed as follows: Air Cooled Chimney * Chimney ASHT+ / HT6103+ / S-2100+ / HT6000+ Collar Chimneys Spacer (built 1. Install the first elbow; turn it in the required into flashing) direction. Fasten it to the chimney with the three (3) 1/2”...
  • Page 18 Offset Dimensions Total Height Horizontal Offset Chimney Elbow Offset & One Length Between Elbows Two Lengths Between Elbows Height 6” 8” 12” 18” 24” 36” 48” 8” & 48” 12” & 48” 18” & 48” 24” & 48” 36” & 48” 48”...
  • Page 19: Angled Wall Radiation Shield

    ANGLED WALL RADIATION SHIELD (RSM+ and RSMI30) OFFSET CHIMNEY INSTALLATION When traversing a combustible wall with the chimney at a 30º or 45º Chimney AC angle, an angled firestop or wall radiation shield must be installed. Only one is required. RSMI45 NOTE: 45º...
  • Page 20: Chimney Support Installation

    CHIMNEY SUPPORT INSTALLATION Universal Roof Support When installing a support, slightly lift the chimney system so the weight 18” (460 mm) will lie on the support, not on the fireplace to reduce expansion noises. 18” (460 mm) This support has three possible uses: 1.
  • Page 21: Masonry Application Instructions

    INSTALLATION INSTRUCTIONS FOR MASONRY APPLICATION Follow these steps: WARNING: Before starting the installation, the masonry chimney must 1. Position the fireplace in its location. Temporarily install the ASHT+ be inspected by a qualified chimney sweep. elbow on the top of the fireplace and, using a level, mark with an oval the location where the flue liner will enter the masonry chimney.
  • Page 22: Installation Accessories

    OPTIONAL INSTALLATION ACCESSORIES Central Forced Air Kit Accessories Central Forced Air Kit, Central forced air kit including: blower (BISZY), flex adaptor (BISAF), 2 clamps, variable Installation Accessories speed control (VRUW), thermo-disk (VTU), fan to flexible BISFWK-1 pipe adapter (BISAVF), back draft damper (BISBD), aluminium Description Cat./ Part No.
  • Page 23: Replacement Parts

    REPLACEMENT PARTS LIST SPECIFICATIONS Ladera™ Replacement Parts Cat. No. Model Description H7162 Ladera-BK Ladera EPA Wood-Burning Fireplace Description Part/Cat. No. Andiron (2 pieces) PR-SR2897 Bottom refractory PR-SR2825 Product Reference Information Back refractory PR-SR2826 Weight 215 lbs Left side refractory PR-SR2828 Height 37-5/8”...
  • Page 24: Chimney Components Lists

    SECURITY CHIMNEYS™ - PARTS AND COMPONENTS LISTS The components listed below must be ordered from Security Chimneys International™. Contact your Security Chimneys Distributor or Dealer for ordering information. Security Chimneys International Limited 450-973-9999 2125 Monterey, Laval, quebec 1-800-361-4909 (USA) Canada, H7L 3T6 1-800-667-3387 (Canada) securitychimneys.com Secure Temp...
  • Page 25 SECURITY CHIMNEYS™ - PARTS AND COMPONENTS LISTS The components listed below must be ordered from Security Chimneys International™. Contact your Security Chimneys Distributor or Dealer for ordering information. Security Chimneys International Limited 450-973-9999 2125 Monterey, Laval, quebec 1-800-361-4909 (USA) Canada, H7L 3T6 1-800-667-3387 (Canada) securitychimneys.com Tubinox®...
  • Page 26 NOTES...
  • Page 27: Warranty

    THE WARRANTY Innovative Hearth Products ("IHP") Limited Lifetime Warranty warrants your Astria™ Brand EPA Wood Burning Fireplace ("Product") to be free from defects in materials and workmanship at the time of manufacture. The Product body, firebox and ceramic glass carry the Limited Lifetime Warranty. Ceramic glass carries the Limited Lifetime Warranty against thermal breakage only.
  • Page 28: Product Reference Information

    See Page 23 for a complete replacement parts list. Use only parts sup- 1508 Elm Hill Pike, Suite 108 plied from the manufacturer. Nashville, TN 37210 Visit us at Astria.us.com Model Number _____________________________________________________ Serial Number _____________________________________________________ Date Installed ______________________________________________________ Dealer’s Name _____________________________________________________ Dealer’s Phone Number ______________________________________________...
