Astria Devonshire36TEN Installation And Operation Instructions Manual

Direct-vent gas fireplace
Hide thumbs Also See for Devonshire36TEN:

Advertisement

P/N 126730-01 Rev. A 1/2014
.
P126730-01
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
A barrier designed to reduce the risk of burns
from the hot viewing glass is provided with this
appliance and shall be installed.
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile
home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used.
WARNING AVERTISSEMENT AVISO
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or death.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
Installation and Operation Instructions
Astria
TM
PFS
Models
®
C
US
Devonshire36TEN
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour consultation ultérieure.
Une barrière conçue pour réduire le risque de brûlure
par le hublot chaude est fournie avec l'appareil et doit
être installé.
UNE SURFACE VITRÉE CHAUDE PEUT
CAUSER DES BRÛLURES.
LAISSER REFROIDIR LA SURFACE VITRÉE
AVANT D'Y TOUCHER.
NE PERMETTEZ JAMAIS À UN ENFANT DE
TOUCHER LA SURFACE VITRÉE.
AVERTISSEMENT : Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire au
minimum le risque d'incindie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou la mort.
— Ne pas entreposer ni utilizer d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ :
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucan interrupteur. Ne pas vous
servir des téléphones se trouvant dans le bâtiment
où vous trouvez.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incindies.
— L'installation et l'entretien doivent être assurés par un
installateur ou un service d'entretien qualifié ou par le
fournisseur de gaz.
Direct-Vent Gas Fireplace
Devonshire36TEP
Devonshire42TEN
Devonshire42TEP
EL VIDRIO CALIENTE
CAUSARÁ QUEMADURAS.
USTED DEBE NUNCA TOCAR
EL VIDRIO CALIENTE.
LOS NIÑOS DEBEN NUNCA
TOCAR EL VIDRIO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Devonshire36TEN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Astria Devonshire36TEN

  • Page 1 Installation and Operation Instructions Astria Direct-Vent Gas Fireplace P/N 126730-01 Rev. A 1/2014 Models ® Devonshire36TEN Devonshire36TEP Devonshire42TEN Devonshire42TEP P126730-01 INSTALLER: Leave this manual with the appliance. Installateur : Laissez cette notice avec l’appareil. CONSUMER: Retain this manual for future reference.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety ..............2 Gas Control Module System......26 Local Codes............5 Inspecting Burners..........27 Product Identification ........... 5 Cleaning and Maintenance ........ 28 Product Features ..........5 Troubleshooting ..........29 Pre-installation ............. 6 Specifications ............ 32 Location of Termination Cap ........ 8 Wiring Diagram ..........
  • Page 3 SAFETY Continued Carbon Monoxide Poisoning: Early signs of carbon monoxide poisoning resemble the flu, with headaches, dizziness or nausea. If you have these signs, the fireplace may not be work- ing properly. Get fresh air at once! Have fireplace serviced. Some people are more affected by carbon monoxide than others.
  • Page 4: With Fireplace

    10. Do not operate fireplace if any log is other combustible (flammable) objects can broken. make contact with the fireplace front 11. Do not operate fireplace with glass door • in high traffic areas removed, cracked or broken. 12. Provide adequate clearances around air openings. www.Astria.US.com 126730-01A...
  • Page 5: Local Codes

    • Your direct vent gas fireplace system very carefully for either vertical or horizontal (fireplace and venting) is a balanced and applications. sealed gas operating unit. It requires ap- proximately 10-20 minutes of operating time before the flame pattern stabilizes. www.Astria.US.com 126730-01A...
  • Page 6: Pre-Installation

    (36" MODEL) 10.75" bushes, garden sheds, fences, decks or (42" MODEL) 11.50" utility buildings within 24" from the front of the termination cap and the front of outside Figure 4 - Electrical Outlet and Gas air vent. Knockout Locations www.Astria.US.com 126730-01A...
  • Page 7 Note: Noncombustible mantels may discolor! Mantel Mantel from Ref. Depth Ref. Top of Opening 14" 16" 12" 14" 10" 12" 8" 10" 6" 8" 4" 6" 2" 4" Figure 7 - Clearances for Combustible Mantels www.Astria.US.com 126730-01A...
  • Page 8: Location Of Termination Cap

    Noncombustible Combustible - 6" (15.2 cm) H = 24" (61 cm) G = 12" (30.5 cm) minimum clearance Noncombustible - 2" (5.1 cm) J = 20" (50.8 cm) Figure 8 - Minimum Clearances for Termination Cap www.Astria.US.com 126730-01A...
  • Page 9: Requirements For The Commonwealth Of Massachusetts

    1/2" in shall remain with the appliance or equipment size, "GAS VENT DIRECTLY BELOW. KEEP at the completion of the installation. CLEAR OF ALL OBSTRUCTIONS". www.Astria.US.com 126730-01A...
  • Page 10: Venting Installation

    2" clearances Failure to do so could result in from the top of the pipe. Where serious injury, property damage the termination cap penetrates or loss of life. a combustible wall, 1" air space clearance is required. www.Astria.US.com 126730-01A...
  • Page 11 Mark wall for an 11 " x 11 " square hole. Cut and frame square hole in exterior wall where vent will be terminated. If wall being pen- Figure 10 - Vent Opening Requirements www.Astria.US.com 126730-01A...
  • Page 12 Four Sides Interior Wall Surface Vent Cap Wood Wall Screw Firestop Vent Cap (Horizontal Figure 11 - Installing Horizontal Vent Cap Termination) (Noncombustible Exterior) Horizontal Screw Vent Pipe Figure 13 - Connecting Vent Cap with Horizontal Vent Pipe www.Astria.US.com 126730-01A...
  • Page 13 Framed Opening Standoff improperly installed and main- Exterior Wall with Vinyl Siding tained venting system could Figure 14 - Typical Horizontal result in serious injury, property Termination Cap Mounting with damage or loss of life. Additional Siding Standoff Installed www.Astria.US.com 126730-01A...
  • Page 14 Figure 15 - Horizontal Termination Using One 90° Elbow Venting with Two 90° Elbows Horizontal (H Vertical (V) Horizontal (H 6' min. 8' max. 7' min. 10' max. 8' min. 15' max. 20' max. 20' max. Figure 16 - Horizontal Termination Using Two 90° Elbows www.Astria.US.com 126730-01A...
  • Page 15 Over 10/12 to 11/12 3.25 Figure 17 - Offset with Wall Strap and 45° Over 11/12 to 12/12 Elbows Over 12/12 to 14/12 Over 14/12 to 16/12 Over 16/12 to 18/12 Over 18/12 to 20/12 Over 20/12 to 21/12 www.Astria.US.com 126730-01A...
  • Page 16 RF-58-12 Roof Flashing - 6/12 to 12/12 Pitch, Galvanized VR-58 Vertical Restrictor, Galvanized S-58 Vinyl Siding Standoff, Galvanized WS-58 Wall Strap CS-58 Cathedral Ceiling Support FP-58 Firestop Plate SF-58 Stucco Flashing - For use with HTS-58 RF-58 Flat Roof Flashing www.Astria.US.com 126730-01A...
  • Page 17 Venting with Two 90° Elbows Vertical (V Horizontal (H) 6' min. 12' max. 7' min. 18' max. 8' min. 20' max. 20' max. 20' max. V1 + V2 = 40' max. Figure 20 - Vertical Venting Configuration Using Two 90° Elbows www.Astria.US.com 126730-01A...
  • Page 18: Fireplace Installation

    (if allowed by local codes) * An equipment shutoff valve with 1/8" NPT tap is an acceptable alternative to test gauge connection. Purchase the equipment shutoff Figure 21 - External Regulator with Vent valve from your retailer. Pointing Down (Propane/LP Only) www.Astria.US.com 126730-01A...
  • Page 19 Do NOT Valve Kink 1/2" NPT Incoming Note: Gas Line Outlet Pressure Tap 1) Wire connections not Set Screw shown for clarity 2) * 1/8" NPT Plugged Tapping Figure 23 - Connecting Incoming Gas Line to Flex Gas Line www.Astria.US.com 126730-01A...
  • Page 20 2. Open propane/LP supply tank valve for meter for natural gas fireplace or using propane/LP fireplace or main gas valve compressed air. located on or near gas meter for natural gas fireplace. www.Astria.US.com 126730-01A...
  • Page 21 2. Hook top flange of door frame over top of Do not remove if glass is hot. firebox frame. Keep children and pets away 3. Secure 2 bottom door latches. from glass. WARNING: If fireplace has been running, turn off fireplace. Let cool before removing glass doors. www.Astria.US.com 126730-01A...
  • Page 22 Do not block burner ports or pilot ports by overlapping ember flakes in one Figure 28a - Installing Loose Log #1 area. It is not necessary to use all ember material provided. www.Astria.US.com 126730-01A...
  • Page 23 (see Figure 32). Control 2. After connecting gas line to control valve, Valve To External always test for leaks. Regulator (Propane/LP) Flexible Gas Line, Do NOT Kink Figure 32 - Connecting/Disconnecting Gas Line to Millivolt Valve www.Astria.US.com 126730-01A...
  • Page 24: Operation

    2. Turn off all electric power to fireplace. 3. Turn safety shutoff switch to the OFF position. 4. Remove center brick/control cover. 5. Turn equipment shutoff valve clockwise to the OFF position (see Figure 34). Do not force. www.Astria.US.com 126730-01A...
  • Page 25 (See Figure 35). White Wires Exhaust Port Ring Connectors Ground Wires Spade Air Flow Connectors Direction Magnet Black Wires Wire Nut Connectors Speed Control Power Cord Magnet Figure 35 - Blower Assembly www.Astria.US.com 126730-01A...
  • Page 26: Gas Control Module System

    OFF position, the burner will operate ON when the main burner shuts OFF. from the rocker switch or wall switch The continuous pilot mode can also be connected to the two BROWN wires activated by the Remote Control. on the module. www.Astria.US.com 126730-01A...
  • Page 27: Inspecting Burners

    • see Troubleshooting, page 29 Figure 34, page 25). Do not remove the adjustment screw. • see Troubleshooting, page 29 Sensing Pilot Ignitor/ Burner Sensor Figure 40 - Typical Flame Pattern Figure 39 - Correct Pilot Flame Pattern www.Astria.US.com 126730-01A...
  • Page 28: Cleaning And Maintenance

    • Use a vacuum cleaner to remove any present. Refer to Removing/Replacing Glass carbon buildup on logs. Door, page 21 of this manual when removing • Replace material periodically as needed. glass door for cleaning. See Replacement Parts, page 33. www.Astria.US.com 126730-01A...
  • Page 29: Troubleshooting

    Replacement Parts, 7. No power to unit or ignition page 33) module 7. Check that main power is on and that all wire connec- tions are made correctly to ignition model (see Wiring Diagram, page 32). www.Astria.US.com 126730-01A...
  • Page 30 If noise is ex- is lit or shut off cooling cessive, contact qualified service person Slight smoke or odor during 1. Residues from manufac- 1. Problem will stop after a few initial operation turing processes and logs hours of operation curing www.Astria.US.com 126730-01A...
  • Page 31 3. Have vent system inspect- sive blockage ed, including termination cap. Remove any restric- tions or obstruction 4. Excessive amounts of em- 4. Clear excess embers until bers and pan material a minimum gap of 1/2" remains under grate www.Astria.US.com 126730-01A...
  • Page 32: Specifications

    SPECIFICATIONS DEVONSHIRE36TEN DEVONSHIRE36TEP • Rating: 49,000/30,000 Btu/hr • Rating: 47,000/28,000 Btu/hr • Gas Type: Natural Gas Only • Gas Type: Propane/LP Gas Only • Ignition: Electronic • Ignition: Electronic • Manifold Pressure: 3.5" w.c. • Manifold Pressure: 10" w.c. • Minimum Inlet Supply Pressure: 5" w.c.
  • Page 33: Replacement Parts

    Brick Perimeter Trim Kit Standard ON/OFF electronic remote control PBS36D - Ivory Tan kit. PBS42D - Ivory Tan Ledgestone Refractory Liner Kit PBS36 - Warm Red BLY36STL PBS42 - Warm Red BLY42STL Magnetic attachment, Matching refractory brick facing surround kit. www.Astria.US.com 126730-01A...
  • Page 34: Parts

    PARTS MODELS DEVONSHIRE36TEN, DEVONSHIRE36TEP, DEVONSHIRE42TEN AND DEVONSHIRE42TEP 33(36") 32(42") www.Astria.US.com 126730-01A...
  • Page 35 • • 125104-01 Draft Shield 36" • • 125104-02 Draft Shield 42'' • • 109720-03 Spacer Clearance • • • • PARTS AVAILABLE NOT SHOWN 126469-01 Dual, Blower Assembly • • • • **Not a field replaceable part. www.Astria.US.com 126730-01A...
  • Page 36 PARTS MODELS DEVONSHIRE36TEN, DEVONSHIRE36TEP, DEVONSHIRE42TEN AND DEVONSHIRE42TEP www.Astria.US.com 126730-01A...
  • Page 37: Burner Assembly

    • • 125069-01 Remote Control • • • • 14253 30" Flex Line • • • • 125065-01 Wire Harness • • • • 125066-01 AC Adapter (Power Cord) • • • • **Not a field replaceable part. www.Astria.US.com 126730-01A...
  • Page 38 • • 125131-03 Center Front Refractory 42" Ivory Tan • • 125095-03 Center Front Refractory 36" Ivory Tan • • 125130-03 Right Front Refractory 42" Ivory Tan • • 125094-03 Right Front Refractory 36" Ivory Tan • • www.Astria.US.com 126730-01A...
  • Page 39 125093-04 Left Front Refractory 36" Ledgestone • • 125131-04 Center Front Refractory 42" Ledgestone • • 125095-04 Center Front Refractory 36" Ledgestone • • 125130-04 Right Front Refractory 42" Ledgestone • • 125094-04 Right Front Refractory 36" Ledgestone • • www.Astria.US.com 126730-01A...
  • Page 40 THE WARRANTY Innovative Hearth Products ("IHP") Limited Lifetime Warranty warrants your Astria™ brand gas fireplace ("Product") to be free from defects in materials and workmanship at the time of manufacture. The Product body and firebox carry the Limited Lifetime Warranty. Ceramic glass carries the Limited Lifetime Warranty against thermal breakage only.
  • Page 41: Warranty

    KEEP THIS WARRANTY Model (located on product or identification tag) _____________________________ Serial No. (located on product or identification tag) __________________________ Date Purchased __________________________ Keep receipt for warranty verification. www.Astria.US.com 126730-01A...
  • Page 42 NOTES...
  • Page 43 NOTES www.Astria.US.com 126730-01A...
  • Page 44 1508 Elm Hill Pike, Suite 108 Nashville, TN 37210 126730-01 1-800-655-2008 Rev. A www.IHP.US.com 1/14 P126730-01...
