INSTALLER / CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND USING
APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING PROP-
ERTY DAMAGE, PERSONAL IN-
JURY OR LOSS OF LIFE.
FOR YOUR SAFETY
Improper installation, adjustment, alter-
ation, service or maintenance can cause
injury or property damage. Refer to this
manual for correct installation and opera-
tional procedures. Installation and service
must be performed by a qualified installer,
service agency or the gas suppler.
WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electric switch; do
not use any phone in your building.
•
Immediately call your gas supplier
form your neighbor's phone. Follow
the gas supplier's instructions.
•
If you cannot reach your gas supplier,
call the fire department.
DO NOT STORE OR USE GASO-
LINE OR OTHER FLAMMABLE
VAPORS AND LIQUIDS IN THE
VICINITY OF THIS OR ANY OTHER
APPLIANCE.
This is an unvented gas-fired
heater. It uses air (Oxygen) from
the room in which it is installed.
Provisions for adequate combus-
tion and ventilation air must be
provided.
Vermont Castings Jefferson Vent Free Gas Heater
Jefferson
Vent Free Gas Heater
Models: JUVSR & JUVSM
3095, 3096, 3097, 3100,
3101, 3102, 3105, 3106,
3107, 3110, 3111, 3112
Homeowner's Installation
and Operation Manual
Tested and listed to ANSI Z21.11.2.2000
INSTALLER: DO NOT DISCARD THIS MANUAL -
LEAVE FOR HOMEOWNER
®
20003447b / 0701
1
m
Advertisement
Table of Contents
Related Manuals for Vermont Castings 3095
Summary of Contents for Vermont Castings 3095
-
Page 1: Safety Information
Provisions for adequate combus- tion and ventilation air must be provided. Jefferson Vent Free Gas Heater Models: JUVSR & JUVSM 3095, 3096, 3097, 3100, 3101, 3102, 3105, 3106, 3107, 3110, 3111, 3112 Homeowner’s Installation and Operation Manual Tested and listed to ANSI Z21.11.2.2000... -
Page 2: Table Of Contents
Vermont Castings Jefferson Vent Free Gas Heater ATTENTION CONSUMER: IN ORDER TO ENSURE SAFE AND EFFECTIVE INSTALLATION, THIS UNIT MUST BE INSTALLED ONLY BY A QUALIFIED AGENCY, INDIVIDUAL, FIRM, CORPORATION OR COMPANY THAT IS EXPERIENCED IN THE INSTALLATION, REPAIR AND SERVICING OF THIS TYPE OF APPLIANCE AND IS FAMILIAR WITH THE BUILDING CODES AND INSTALLATION TECHNIQUES APPROPRIATE IN YOUR AREA. -
Page 3: Heater Dimensions
JUVS Specifications Jefferson Vent Free Gas Heater Models JUVSRN, JUVSRP, JUVSMN, JUVSMP Fuel Manifold Pressure Min./Max. Min. Inlet Supply Pressure for adjustment: Max. Inlet Supply Pressure for adjustment: 14.0”w.c. Min. Output, BTU/hr: JUVSR JUVSM Max. Output, BTU/hr: Ignition: Piezo Firebox Weight/shipping: 110 lbs. -
Page 4: Safety Information
Vermont Castings Jefferson Vent Free Gas Heater Safety Information IMPORTANT: READ THIS OWNER’S MANUAL CAREFULLY AND COMPLETELY BEFORE TRYING TO AS- SEMBLE, OPERATE OR SERVICE THIS HEATER. IMPROPER USE OF THIS HEATER CAN CAUSE SERIOUS INJURY OR DEATH FROM BURNS, FIRE, EXPLOSION, ELECTRICAL SHOCK AND CARBON MONOXIDE POISONING. -
Page 5: General Information
General Information Vent Free Features The JUVS Gas Heater is an unvented gas appliance tested and listed to the ANSI standard Z21.11.2.2000. The Vent Free Gas Heater is configured to use Natural Gas, (JUVSRN, JUVSMN ) or Propane (JUVSRP, JUVSMP). Because these heaters are clean-burning and highly energy-efficient, no venting system is required. -
Page 6: Installation Requirements
Vermont Castings Jefferson Vent Free Gas Heater Installation Requirements Fresh Air Requirements for Combustion and Ventilation W A R N I N G This heater must have fresh air for proper opera- tion. If it does not, poor fuel combustion could result. - Page 7 4. Compare the maximum BTU/hour rating the space can support with the total BTU/hour used by the appli- ances. Example: 76,800 BTU/hour the space can support 80,000 BTU/hour used by appliances In this example, the maximum BTU/hour that the space can support is less than the total used by the appli- ances.
-
Page 8: Clearance Requirements
Vermont Castings Jefferson Vent Free Gas Heater Clearance Requirements Minimum Clearances to Combustible Materials Maintain clearance, (empty space), between combus- tible materials and the heater as specified. Alcove Clearances ST103 A: Ceiling ... 27 ” C: Rear Wall ... 4” B: Side Wall ... -
Page 9: Assembly Procedures
Assembly Procedures Optional Fan Kit Installation (2960/FK28) 1. Attach the fan to the rear shroud by engaging the upper flange of the fan skirt under the lower edge of the shroud and secure the skirt with the four screws and one star washer provided. - Page 10 Vermont Castings Jefferson Vent Free Gas Heater MOTOR ON/OFF RHEOSTAT Fig. 13 Fan wiring diagram. Connect the Gas Supply Line Check the Rating Plate attached by a steel cable to the firebox, to confirm that you have the appropriate firebox for the type of fuel to be used.
- Page 11 Lava Rock Fig. 15 Install lava rock and upper logs. Fig. 16 Completed log installation. Vermont Castings Jefferson Vent Free Gas Heater The switch assembly parts are found in the parts bag. 1. Attach switch assembly to left rear side of stove shroud using two screws and existing holes in shroud.
-
Page 12: Operation
Vermont Castings Jefferson Vent Free Gas Heater Your First Fire Read these instructions carefully and familiarize yourself with the burner controls of this heater. The JUVSR uses a Honeywell control valve that allows thermostatic, on/off switch regulation and has a sepa- rate Piezo ignition button. - Page 13 Fig. 22 Pilot Assembly Location Fig. 23 Proper flame pattern with Regulator in HIGH position. Vermont Castings Jefferson Vent Free Gas Heater Pilot Orifice Pilot Assembly ST115a Fig. 24 Correct Pilot Flame. (*JUVSM pilots do not have Thermopile) Lifting Flame ST116 Weak Flame Fig.
-
Page 14: For Your Safety Read Before Lighting
Vermont Castings Jefferson Vent Free Gas Heater Lighting And Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. -
Page 15: Maintenance
The following procedures will help ensure that your stove continues to perform safely and efficiently. Firebox Cleaning and Inspection Cleanliness is critical to correct operation of the heater. The log set, burner, valve controls and air circulation areas must all be kept free of dust and unobstructed by debris. -
Page 16: Troubleshooting
Vermont Castings Jefferson Vent Free Gas Heater Follow these procedures in the order presented. CONDITION No spark at pilot when Ignitor is operated. The Ignitor Electrode sparks, but Pilot does not light. Pilot/Main Con- trol Fig. 27 JUVS Honeywell Control Valve Assembly. Troubleshooting W A R N I N G TURN OFF HEATER AND ALLOW TO COOL... - Page 17 Troubleshooting cont’d. CONDITION Pilot lights but flame goes out when Control Knob is released. Fig. 29 Pilot flame is lifting. Thermopile Thermo- couple Fig. 30 Pilot flame is weak - does not touch Thermocouple. Fig. 31 Correct LP Pilot Flame. Pilot lights but Main Burner does not.
- Page 18 Vermont Castings Jefferson Vent Free Gas Heater W A R N I N G If you smell gas: • Shut off gas supply • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building.
-
Page 19: Replacement Parts
The Vermont Castings Majestic Products Company reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. Jefferson Vent Free Gas Heater Item/Model Number 1. Log Set Complete 1a. Back Log 1b. - Page 20 Vermont Castings Jefferson Vent Free Gas Heater JUVS (continued) Item/Model Number 10. Wire Harness 11. Handle Damper - Maplewood 12. Front Handle Assembly (Brass) 13. Right Log Bracket 14. Left Log Bracket 15a. OP Pilot (R Models) - Natural 15b. OP Pilot (R Models) - LP 15c.
-
Page 21: Warranty
Warranty Limited Three Year Warranty The Vermont Castings, Majestic Products Company (Manufac- turer) warrants that this Vent Free Gas Heater, Model JUV, will be free of defects in material and workmanship for a period of three years from the date you receive it, except that the ceramic logs shall be warranted for one year as described below. - Page 22 Vermont Castings Jefferson Vent Free Gas Heater The Vermont Castings Majestic Products Company 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7885 www.majesticproducts.com • www.vermontcastings.com © The Vermont Castings Majestic Products Company...
