INSTALLER / CONSUMER

SAFETY INFORMATION

PLEASE READ THIS MANUAL
BEFORE INSTALLING AND USING
APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLOSION
MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY
Installation and service must be
performed by a qualified installer,
service agency or the gas suppler.
WHAT TO DO IF YOU SMELL
GAS:
Do not try to light any appliance.
Do not touch any electric switch; do
not use any phone in your building.
Immediately call your gas supplier
from your neighbor's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
DO NOT STORE OR USE
GASOLINE OR OTHER
FLAMMABLE VAPORS AND
LIQUIDS IN THE VICINITY OF THIS
OR ANY OTHER APPLIANCE.
This appliance may be installed in an
after market permanently located
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases unless a certified kit is
used.
Stardance
Natural Vent Gas Heater
Model SNV30: 3980-3996
Homeowner's Installation
and Operating Manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
7067
SDV fully assembled
cover
C E R T I F I E D
12/22/03
20007067 3/08 Rev. 11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3980 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vermont Castings 3980

  • Page 1: Safety Information

    APPLIANCE. Stardance WARNING! Natural Vent Gas Heater IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED Model SNV30: 3980-3996 EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. FOR YOUR SAFETY Installation and service must be performed by a qualified installer,...
  • Page 2: Table Of Contents

    Table of Contents PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a Vermont Castings stove. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty.
  • Page 3: Installation & Operating Instructions

    Stardance Natural Vent Gas Heater General Information The Stardance Natural Vent Room Heater, Model Nos. 3980-3996 This appliance may be installed in an aftermarket* manufactured is a vented gas appliance listed to the ANSI standard Z21.88-2005 (mobile) home, where not prohibited by state or local codes.
  • Page 4: Stove Dimensions

    Stardance Natural Vent Gas Heater Stardance Natural Vent Gas Heater Dimensions See Page 5 for Flue Collar Centerline Dimensions. 9" (229mm) C L Valve Inlet 26���" (680 mm) Valve Inlet 3" (76 mm) 14���" 25���" (355 mm) (648 mm) 4406 Fig.
  • Page 5: Clearance Requirements

    Stardance Natural Vent Gas Heater Ceiling Clearances Clearance Requirements Minimum Clearances to Combustible Materials 45" (1140mm) Measure side clearances as shown in Figures 2 through 5 from the outer edge of the cast iron stove top. Measure rear clearances from the outermost surface of 72"...
  • Page 6: Gas Specifications

    Stardance Natural Vent Gas Heater Venting Requirements and Options Gas Specifications The Stardance must be properly connected to a listed Max. Min. 4” (102 mm) Type B venting system or to an approved Input Input Class A masonry or factory-built chimney system. In Model Fuel Gas Control...
  • Page 7: Passing Through A Combustible Wall Or Ceiling

    Stardance Natural Vent Gas Heater Passing Through a Venting Requirements Combustible Wall or Ceiling An approved pass-through device is always required when a vent passes through a combustible wall or ceil- ing. Check with the maker of the vent system for the correct listed devices that are available.
  • Page 8: Installation

    Stardance Natural Vent Gas Heater Installation Unpack the Stove Snapstat Wire The Stardance is shipped fully assembled on its back. Rheostat Wire Unpack the stove and carefully set it upright. CAUTION Fan Bracket Porcelain enamelled surfaces are fragile. Handle porcelain enamelled castings tenderly. Familiarize yourself with the assembly steps before you begin and proceed with deliberation and care.
  • Page 9: Venting System Assembly

    Stardance Natural Vent Gas Heater Outer Slot Shroud MOTOR Inner Shroud Slot SNAPSTAT ON/OFF RHEOSTAT POWER ST194 ST196 Fig. 10 Position the fan to engage the inner shroud with the Fig. 13 #2767 / FK26 fan wiring diagram. fan bracket slots and secure with sheet metal screws. Venting System Assembly ST194 Snapstat...
  • Page 10: Paint Option For Enamelled Stoves

    Stardance Natural Vent Gas Heater Insert the B-vent adapter into the flue collar and drill Connect the Gas Supply Line 1/8” (3mm) pilot holes through both the stove’s collar and the adapter. Attach the adapter to the flue collar Check the Rating Plate attached by a steel cable to the with sheet metal screws.
  • Page 11: Burner Information

    Stardance Natural Vent Gas Heater Burner Information The appliance must only use the gas specified on the rating plate, unless converted using a Fuel Conversion Kit. Refer to Page 25 for the correct Fuel Conversion Kit for your model. Conversion instructions are provided with each kit and beginning on Page 16 in this manual.
  • Page 12: Install The Front Plate

    Stardance Natural Vent Gas Heater Install the Front Plate Left Log Hold the front plate by the window bars and lift it into Right position, engaging the two steel tabs on the top corners behind the adjacent bosses in the side plates. (Fig. 21) Then seat the Front against the sides so the tabs at the bottom lip engage with the notches in the stove legs.
  • Page 13: Operation

    Stardance Natural Vent Gas Heater Operation ������� � ��� ����� ���� ����� ������ �� ��� ����� ����� ����� ������� ����� ����� �������� �� ����� ������ Pilot As- sembly ST476 The Stardance is operated with the front plate in place Fig. 22 Pilot Assembly location. with the doors open or closed.
  • Page 14: Lighting And Operating Instructions

    Stardance Natural Vent Gas Heater Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- •...
  • Page 15: Troubleshooting

    Stardance Natural Vent Gas Heater Troubleshooting / Honeywell #8420 Gas Control System NOTE: Before troubleshooting the gas control system, be sure the external gas shutoff is in the “ON” position. WARNING: REMOVE THE GLASS PANEL BEFORE PERFORMING ANY GAS CONTROL SERVICE WORK. SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION...
  • Page 16: Fuel Conversion Instructions

    Stardance Natural Vent Gas Heater 6. Remove the right and left log bracket assembly by Fuel Conversion Instructions unfastening the two screws which hold the burner in place. (Fig. 26) WARNING! This conversion kit shall be installed 7. Hold the burner at the right hand side and lift to clear by a qualified service agency in accordance with the right burner leg.
  • Page 17 Stardance Natural Vent Gas Heater Pilot Hood Pilot Bracket CO105a Fig. 30 Remove pilot hood. Index Tab Allen Wrench CO105a FC107 gas conversion Fig. 28 Remove mounting screws, pressure regulator tower and spring and diaphragm assembly. Pilot Snap Ring 1/28/00 djt FC107 CO106a SIT820...
  • Page 18 Stardance Natural Vent Gas Heater 17. Replace burner. Slide the burner in at an angle Left Burner Leg with left side lower than the right side. Slide the left side onto the injectors, making sure the burner leg remains at a 90° angle to the base. Lower the right Injector Orifices hand side down in to place.
  • Page 19: Maintenance

    Stardance Natural Vent Gas Heater Maintenance Your Stardance Gas Heater will provide years of service Cleaning the Glass with minimal upkeep. The following procedures will help ensure that your stove continues to function properly. WARNING: Let the glass cool completely before at- tempting to clean.
  • Page 20: Gasket Replacement

    Do not use your stove if the flame pattern differs from to seal between the glass panel and the frame. In time, that shown here. Contact your Vermont Castings dealer this gasket can become brittle and compressed and or a qualified technician for help.
  • Page 21: Wiring Diagrams

    Stardance Natural Vent Gas Heater Wiring Diagrams POWER CORD On/Off Switch Wiring TP/TH Chassis Ground Black ST124b Thermostat (Optional) Thermostat (Optional) Optional Thermostat Millivolt Gas Valve Wiring FAN JUNCTION BO X St124b on/off/switch wiring Strain Relief 1/11/00 djt TP/TH ON / OFF Rheostat Black Snapstat...
  • Page 22: Replacement Parts

    16a,b a,b,c,d 42a,b CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. Stardance Natural Vent Gas Heater (SNV30) Models 3980-3996 7067 Stardance NV Ref. Description SNV30...
  • Page 23 Stardance Natural Vent Gas Heater Stardance Natural Vent Gas Heater (SNV30) (continued) Models 3980-3996 Ref. Description SNV30 Manifold Tube Assembly - Double Bead 20003739 Lava Rock - Burner 57897 Gasket, Glass Med. Knit - RDV40 1203702 Glass, DV25 1601691 Glass Frame Assembly SDV30 30000127 Valve RN Honeywell VS8420E 2038 (Serial #’s up to 6361)*...
  • Page 24 Stardance Natural Vent Gas Heater Stardance Natural Vent Gas Heater (SNV30) (continued) Models 3980-3996 Ref. Description SNV30 42a. Valve Nova SIT820.662 RN (Serial #’s starting with 6362) 20010563 42b. Valve Nova SIT820.653 RP (Serial #’s starting with 6362) 20010645 Ignitor Piezo w/Nut SIT...
  • Page 25: Optional Accessories

    Stardance Natural Vent Gas Heater Optional Accessories Available 2. With the doors open, hold the screen at an angle Fan Kits with the bottom hanger toward the inside. (Fig. 42) FK26 Fan 3. Place the hangers on the bottom rib of the front cast The FK26 fan kit helps distribute heated air from within iron frame.
  • Page 26 Stardance Natural Vent Gas Heater Warming Shelf Decorative Rings Warming shelves add versatility to your stove and can 4” brass or black rings are available to add a decorative be used to keep foods warm at mealtime. touch to the exposed stove pipe. Model Color Model...
  • Page 27 Stardance Natural Vent Gas Heater 20007067...
  • Page 28 Stardance Natural Vent Gas Heater 2828 20007067...
  • Page 29 Stardance Natural Vent Gas Heater 20007067...
  • Page 30: Warranty

    Stardance Natural Vent Gas Heater LIMITED LIFETIME WARRANTY PRODUCT COVERED BY THIS WARRANTY All Vermont Castings gas stoves, gas inserts, and gas fireplaces, and all Majestic or brand gas fireplaces equipped with an Insta-Flame Ceramic Burner, or standard steel tube burner. BASIC WARRANTY CFM Corporation (hereinafter referred to collectively as the Company) •...
  • Page 31 PRODUIT COUVERT PAR LA PRÉSENTE GARANTIE L’ensemble des cuisinières à gaz, des poêles encastrables et des foyers à gaz Vermont Castings, ainsi que l’ensemble des foyers à gaz de marque Majestic équipés d’un brûleur en céramique Insta-Flame ou d’un brûleur en acier standard.
  • Page 32: Energuide

    Efficiency Ratings Model EnerGuide Ratings Fireplace Efficiency (%) SNV30RN 51.1 SNV30RP 51.1 CFM Corporation 2695 Meadowvale Blvd. • Mississauga, Ontario, Canada L5N 8A3 800-668-5323 • www.cfmcorp.com...
