Installation instructions.

Important Installation Recommendations
Read entire manual. Failure to follow all guides and rules could cause personal injury or property
damage.
• BE SURE TO FOLLOW ALL APPLICABLE STATE AND LOCAL CODES.
• Use a qualified installer.
• Do not install the Reverse Osmosis system outside or in extreme hot or cold temperatures.
DO NOT INSTALL ON HOT WATER.
• Recommended installation is under the sink. However, the unit can be installed in a remote
location, up to 30 feet away from the sink. Additional installation materials may be required.
• If Reverse Osmosis system is connected to a refrigerator icemaker, a special icemaker connection
kit is required (RVKIT). Do not use copper tubing for the connection between the Reverse
Osmosis system and the refrigerator.
• Be sure the water supply conforms to the specifications, see the Specifications Guidelines section. If
water supply conditions are unknown, contact your municipal water company or your local health
department for a list of contaminants in your area and a list of laboratories certified by your state to
analyze drinking water.
Tools and Materials Required for Installation
• Battery Powered Cordless Drill
• 1 ⁄ 4 " Drill Bit
• 1-1 ⁄ 4 " Carbide Hole Saw (if needed—see Faucet Installation section)
• Adjustable Open-End Wrenches
• Phillips and Straight Screw Drivers
• Utility Knife
• Teflon Tape
• Contents Included with the Product:
— Reverse Osmosis Assembly
— Product Literature (Owner's Manual and Installation, Use and Care Video, Performance Data
— Water Supply Valve Parts Bag
— Drain Line Adapter
— 27" Length of 3 ⁄ 8 " Tubing
— Storage Tank
— Filter Replacement Reminder Label
INSTALLER RESPONSIBILITY: The water supply valve (see the Feed Water Supply section) is
included for use in areas where codes permit. Installer must comply with state and/or local codes.
If not, the installer must provide fittings to tap the cold water pipe for a feed water source to the
Reverse Osmosis system (must adapt to 1/4" OD tubing).
WARNING: Do not use with water that is microbiologically unsafe or of unknown quality without
adequate disinfection before or after the system. Systems certified for cyst reduction may be
used on disinfected water that may contain filterable cysts. This Reverse Osmosis system
contains a replaceable treatment membrane cartridge critical for effective reduction of Total
Dissolved Solids. The water should be tested periodically to verify that the system is performing
satisfactorily. This system is acceptable for treatment of influent concentrations of no more
than 27 mg/L nitrate and 3 mg/L nitrite in combination measured as N and is certified for
nitrate/nitrite reduction only for water supplies with a pressure of 280kPa (40 psig) or greater.
Small parts remaining after the installation could be a choke hazard. Discard safely.
TM
Sheet, and Owner Registration Card)
9
