Camera description

1. Video cable
2. Power cable
3. Mounting base

Installation

To install the camera:
1. Using the template, place it level against the
mounting surface and mark the position of the
mounting holes.
4
3
4
2
5
6
4. Sun shield
5. Lens
6. IR LED
Installation Guide
1
