Arbor Technology ARTS-2870 User Manual

Marine pc with intel core i5-4402e
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ARTS-2870
Marine PC with Intel® Core™ i5-4402E
User's Manual
Version 1.0
2014.12
P/N: 4012287000100P
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ARTS-2870 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arbor Technology ARTS-2870

Summary of Contents for Arbor Technology ARTS-2870

  • Page 1 ARTS-2870 Marine PC with Intel® Core™ i5-4402E User’s Manual Version 1.0 2014.12 P/N: 4012287000100P...

  • Page 2: Revision History

    Revision History Version Release Time Description Dec 2014 Initial release...

  • Page 3: Table Of Contents

    Contents Preface................... iii Copyright Notice ..................iii Declaration of Conformity .................iii CE ......................iii FCC Class A ..................iii RoHS ....................iv SVHC / REACH .................iv Important Safety Instructions ..............v Warning ....................v Replacing Lithium Battery .................vi Technical Support ..................vi Warranty ....................vii Chapter 1 - Introduction ..............1 1.1.
  • Page 4 Contents Chapter 5 - BIOS ................53 5.1. BIOS ....................56 5.1.1. Main ..................56 5.1.2. Advanced ................57 5.1.3. Chipset ................... 67 5.1.4. Boot..................72 5.1.5. Security .................. 74 5.1.6. Save & Exit ................75 Appendices .................. 77 Appendix A: WiFi-AT2350 Hardware Installation ........78 Appendix B: Install mSATA Storage ............

  • Page 5: Preface

    Preface Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 6: Rohs

    RoHS ARBOR Technology Corp. certifies that all components in its products are in compliance and conform to the European Union’s Restriction of Use of Hazardous Substances in Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC.

  • Page 7: Important Safety Instructions

    Preface Important Safety Instructions Read these safety instructions carefully Read all cautions and warnings on the equipment. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage Make sure the correct voltage is connected to the equipment. For pluggable equipment, the socket outlet should be near the equipment and should be easily accessible.

  • Page 8: Replacing Lithium Battery

    Preface The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: Disconnect your Box PC from the power source when you want to work on the inside. Use a grounded wrist strap when handling computer components.

  • Page 9: Warranty

    Preface Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
  • Page 10 This page is intentionally left blank. - viii -...

  • Page 11: Chapter 1 - Introduction

    Chapter 1 Introduction Chapter 1 - Introduction - 1 -...

  • Page 12: Product Highlights

    Introduction 1.1. Product Highlights • Fanless and rugged design • Isolated NMEA 0183 • Isolated RS-232/485 and DIO • Support power on/off delay control • Compliant with IEC-60945, IACS E10, DNV 2.4 • Support 3 Video outputs • Support RAID 0/1 1.2.

  • Page 13: Specifications

    Introduction 1.3. Specifications System Soldered onboard Intel® Core™ i5-4402E 1.6GHz Chipset Intel® PCH QM87 Graphic Integrated Intel® HD Graphics 4600 1 x 204-pin SO-DIMM sockets, supporting DDR3L Memory 1333/1600 MHz, up to 8GB SDRAM 2 x Serial ATA ports with 300MB/s HDD transfer rate Storage 2 x Serial ATA ports with 600MB/s HDD transfer rate 1x Intel®...
  • Page 14 Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: Fanless Marine PC ARTS-2870 One Driver CD One User’s Manual - 4 -...

  • Page 15: Ordering Information

    Introduction 1.5. Ordering Information Marine Barebone System w/ Intel® Core™ i5-4402E , ARTS-2870 w/o memory and storage 1.5.1. Optional Accessories The following items are normally optional, but some vendors may include them as a standard package, or some vendors may not carry all the items.
  • Page 16 This page is intentionally left blank. - 6 -...

  • Page 17: Chapter 2 - Getting Started

    Chapter 2 Getting Started Chapter 2 - Getting Started - 7 -...

  • Page 18: Dimensions

    Getting Started 2.1. Dimensions The following illustration shows the dimensions of the computer, with the measurements in width, depth, and height called out. 110.00 50.00 50.00 116.00 80.00 80.00 27.50 92.50 92.50 27.50 Unit:mm - 8 -...

  • Page 19: Take A Tour

    Getting Started 2.2. Take A Tour The computer has some I/O ports, status LED light and controls on the front and rear panel. The following illustrations show all the components called out . Front View ⑤ Antenna holes stopped up by plugs ⑧...

  • Page 20: Getting Started

    Getting Started This LED lights green when LAN3 port is connected to 100M Green bit/s network equipment. ➌ This LED lights orange when LAN3 port is connected to Orange 1000M bit/s network equipment. This LED lights green when LAN4 port is connected to 100M Green bit/s network equipment.

  • Page 21: Driver Installation Notes

    2.3. Driver Installation Notes The computer supports the operating systems of Windows 7. Find the necessary device drivers on the CD that comes with your purchase. DO follow the sequence below to install the drivers to prevent errors: Chipset→VGA→Audio→Ethernet→ME Paths to find device drivers on CD: Windows 7 Device Driver Path...
  • Page 22 This page is intentionally left blank. - 12 -...

  • Page 23: Chapter 3 - System Configuration

    Chapter 3 System Configuration Chapter 3 - System Configuration - 13 -...

  • Page 24: Board Layout

    CPU boards and carrier board of the computers. 3.1.1. CPU Boards The CPU board for ARTS-2870 is EmETXe-i87M0-i5-4402E. The CPU board for ARTS-2870 is EmETXe-i87M0-i5-4402E, with Intel® Core™ i5-4402E. Top View BE BD 9 8 7 6...

  • Page 25: Bottom View

    BE BD System Configuration 9 8 7 6 5 4 3 2 1 Bottom View COM Express® AB Connector COM Express® CD Connector COM Express CD Connector COM Express AB Connector - 15 -...

  • Page 26: Carrier Board

    System Configuration 3.1.2. Carrier Board PBC-1917 is the carrier board. PBC-1917: Board Top - 16 -...
  • Page 27 System Configuration PBC-1917: Board Bottom SCBD-147U: Board Top - 17 -...

  • Page 28: Jumpers And Connectors

    System Configuration 3.2. Jumpers and Connectors The carrier board PBC-1917 comes with some connectors to join devices and some jumpers to alter the computer's hardware configuration. The following in this chapter will explicate each of these components. 3.2.1. Jumpers JRTC1 Function: CMOS Setting Jumper Type: Onboard 2.54mm-pitch 1x3-pin header Setting:...

  • Page 29: System Configuration

    System Configuration 3.2.2. Connectors JPH2 Function: Power/Reset pin-header Connector Type: Onboard 2.54mm-pitch 2x2-pin header Description SYS_RESET# PIC_PWSIN# Board Top - 19 -...
  • Page 30 System Configuration JVOUT1 Description: Power connector Connector Type: Onboard 3.96mm-pitch 4-pin wafer connector Description ADPIN ADPIN ADP-GND ADP-GND Board Top - 20 -...
  • Page 31 System Configuration JVOUT2 Description: Power connector Connector Type: Onboard 3.96mm-pitch 4-pin wafer connector Description DCIN_VCC DCIN_VCC P-GND P-GND Board Top - 21 -...
  • Page 32 System Configuration JPWRIN2 Description: Power connector Connector Type: Onboard 3.96mm-pitch 4-pin wafer connector Description DCIN DCIN P-GND P-GND Board Top - 22 -...
  • Page 33 System Configuration JPWRIN3 Description: Power connector Connector Type: Onboard 3.96mm-pitch 4-pin wafer connector Description 12VSB 12VSB Board Top - 23 -...
  • Page 34 System Configuration SATA1 & SATA2 Description: Serial ATA connectors for storage devices Connector Type: 7-pin serial ATA connector Description Board Bottom - 24 -...
  • Page 35 System Configuration JSPWR1 & JSPWR2 Description: SATA1 And SATA2 Power connector Connector Type: Onboard 3.96mm-pitch 4-pin wafer connector Description VCC5 VCC12 Board Bottom - 25 -...
  • Page 36 System Configuration Description: PCI Express Mini-card socket Connector Type: Onboard 0.8mm-pitch 52-pin edge card connector The pin assignments conform to the industry standard. Board Top - 26 -...
  • Page 37 System Configuration MSATA1 Description: mSATA socket Connector Type: Onboard 0.8mm pitch 52-pin edge card connector The pin assignments conform to the industry standard. 16 18 15 17 Board Top - 27 -...
  • Page 38 System Configuration Function: Double-stacked USB 2.0/3.0 ports Connector Type: USB 2.0/3.0 Type-A connectors The pin assignments conform to the industry standard. Board Top - 28 -...
  • Page 39 System Configuration JKM1 Function: Keyboard/Mouse PS/2 Port KB/MS Connector Type: 6-pin Mini-DIN The pin assignments conform to the industry standard. Board Top - 29 -...
  • Page 40 System Configuration MIC1 Description: Mic-in Port Connector Type: Pink 3.5mm audio jack Front Panel JLOUT11 Description: Line-out Port Connector Type: Green 3.5mm audio jack Front Panel - 30 -...
  • Page 41 System Configuration CN4 & CN5 Function: 2 x Ethernet 10/100/1000 Mbps Connectors Connector type: RJ-45 stacked connector with LED Description Description LAN4 LAN1 MDI0+ MDI2+ MDI0- MDI2- MDI1+ MDI3+ MDI10- MDI3- LAN3 LAN2 Board Top - 31 -...
  • Page 42 System Configuration Function: Analog RGB & DVI-D Connector Connector type: Analog RGB (D-Sub 15-pin female type) + DVI-D (DVI-D female connector) Analog RGB DVI-D Analog RGB Connector The pin assignments conform to the industry standard. DVI-D Connector The pin assignments conform to the industry standard. Board Top - 32 -...
  • Page 43 System Configuration Function: DVI-D Connector Connector type: DVI-D (DVI-D female connector) The pin assignments conform to the industry standard. Board Top - 33 -...
  • Page 44 System Configuration CN6 & CN7 Function: Double-stacked USB ports Connector Type: USB 2.0 Type-A connectors The pin assignments conform to the industry standard. Board Top - 34 -...
  • Page 45 System Configuration JPWRIN4 Function: Power Input Connector Connector Type: 5.0mm pitch 2-pin terminal block Description DC IN ADPIN 24V ADP-GND Board Top - 35 -...
  • Page 46 System Configuration Function: Double-stacked RS-232/422/485 COM Port for COM1 COM1 (A) & COM2 (B) Connector Type: External 9-pin D-sub male connector COM2 COM1 RS232 Mode COM2 RS232 Mode Pin Description Pin Description Pin Description Description DCD1# RXD1 DCD2# RXD2 TXD1 DTR1# TXD2 DTR2#...
  • Page 47 System Configuration Description: NMEA0183 connector for COM3 (A) & COM4 (B) Connector Type: Description Description Rear Panel - 37 -...
  • Page 48 System Configuration Description: NMEA0183 connector for COM5 (A) & COM6 (B) Connector Type: Description Description Rear Panel - 38 -...
  • Page 49 System Configuration Description: NMEA0183 connector for COM7 (A) & COM8 (B) Connector Type: 5x2 Terminal block Description Description Rear Panel - 39 -...
  • Page 50 System Configuration Description: NMEA0183 connector for COM9 (A) & COM10 (B) Connector Type: 5x2 Terminal block Description Description Rear Panel - 40 -...
  • Page 51 System Configuration JDIO1 Description: DIGITAL SINGAL INPUT AND OUTPUT Connector Type: 5x2 Terminal block (4-in, 4-out) Description Description DIO_IN1 DIO_OUT1 DIO_IN2 DIO_OUT2 DIO_IN3 DIO_OUT3 DIO_IN4 DIO_OUT4 Rear Panel - 41 -...
  • Page 52 System Configuration SCBD-147U: JVIN3 Description: Power connector Connector Type: Onboard 3.96mm-pitch 4-pin wafer connector Description DCIN_VCC DCIN_VCC P-GND P-GND Board Top - 42 -...
  • Page 53 System Configuration JPWRIN3 Description: Power connector Connector Type: Onboard 3.96mm-pitch 4-pin wafer connector Description 12VSB 12VSB Board Top - 43 -...
  • Page 54 This page is intentionally left blank. - 44 -...

  • Page 55: Chapter 4 - Installation And Maintenance

    Chapter 4 Installation and Maintenance Chapter 4 - Installation and Maintenance - 45 -...

  • Page 56: Install Hardware

    Installation & Maintenance 4.1. Install Hardware The computer is constructed based on modular design to make it easy for users to add hardware or to maintain the computer. The following sections will guide you to the simple hardware installations for the computer. 4.1.1.

  • Page 57: Install Sata Ssd

    Installation & Maintenance 4.1.2. Install SATA SSD The ARTS-2870 supports two 2.5-inch SSD storage devices. To install a 2.5" SSD to the computer, follow through the guide below: On the front panel of the computer, find the two drawer-like brackets, each has two screws to fix it.
  • Page 58 Installation & Maintenance Slide a 2.5-inch SSD into the bracket. Fix the assemblage with four flush head screws. Two screws on one side. The other two screws on the other side. Plug the bracket (with the SSD) back to the computer, and fasten screws. - 48 -...

  • Page 59: Install Memory Module On Cpu Module

    Installation & Maintenance 4.1.3. Install Memory Module on CPU Module 1. Open the computer as 4.1.1. Open the Computer 2. Loose the 6 screws on the heat sink and remove the heat sink. Caution: Screws are under the heat spreading gel. Remove the spreading gel to unfasten the screws. 3.

  • Page 60: Mount The Computer

    Installation & Maintenance 4.2. Mount the Computer Integrate the computer to where it works by mounting it to a wall in the surroundings. Such integration relies on a wall-mount kit, which comes with the computer. Follow through the guide below to assemble the kit to the computer: Place the computer on a flat surface, with the bottom facing up.
  • Page 61 Installation & Maintenance Use the other screw holes and cutouts on both wall-mount brackets to mount the computer to a wall. (See the green circles in the illustration below). - 51 -...

  • Page 62: Wire Dc-In Power Source

    Installation & Maintenance 4.3. Wire DC-in Power Source Warning Only trained and qualified personnel are allowed to install or replace this equipment. Follow the instructions below for connecting the computer to a DC-input power source. DC power Input wiring pin definition is as follow, Before wiring, make sure the power source is disconnected.

  • Page 63: Chapter 5 - Bios

    Chapter 5 BIOS Chapter 5 - BIOS - 53 -...
  • Page 64 Data elements. BIOS Vendor American Megatrends Core Version 4.6.5.4 Compliancy UEFI 2.3.1; PI 1.2 Project Version ARTS-2870 1.02 Build Date and Time 02/26/2014 17:46:30 System Date [Fri 04/11/2014] System Time [14:04:38] →←: Select Screen : Select Item...

  • Page 65: Key Commands

    BIOS Key Commands The BIOS Setup utility relies on a keyboard to receive user’s instructions. Hit the following keys to navigate within the utility and configure the utility. Keystroke Function ← → Moves left/right between the top menus. ↓ ↑ Moves up/down between highlight items.

  • Page 66: Bios

    Data elements. BIOS Vendor American Megatrends Core Version 4.6.5.4 Compliancy UEFI 2.3.1; PI 1.2 Project Version ARTS-2870 1.02 Build Date and Time 02/26/2014 17:46:30 System Date [Fri 04/11/2014] System Time [14:04:38] →←: Select Screen : Select Item...

  • Page 67: Advanced

    BIOS The featured settings are: Setting Description System Time Sets system time. System Date Sets system date. 5.1.2. Advanced Access the Advanced menu to manage the computer’s system configuration including the Super IO chip. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save &...
  • Page 68 BIOS 5.1.2.1. ACPI Settings Access this submenu to configure the system’s ACPI (Advanced Configuration and Power Interface). The featured settings are: The featured settings are: Setting Description Enables/disables the system to/from hibernation (OS/S4 Sleep State). Enable Hibernation This option is fixed. Enabled is the default.

  • Page 69: Cpu Configuration

    BIOS 5.1.2.3. CPU Configuration Select CPU Configuration to run a report of the CPU's details including the hardware version, software version, model name, processor speed, microcode revision, max./min. processor speeds, the amount of processor core(s), and CPU caches. See the depiction below: Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
  • Page 70 BIOS 5.1.2.4. SATA Configuration SATA Configuration delivers SATA device(s) information and configures SATA device(s). The featured settings are: Setting Description Enables/disables SATA device(s). SATA Controller(s) Enabled is the default. Configures how SATA controller(s) operate. SATA Mode Selection Options available are IDE (default), AHCI and RAID. SATA Controller Configures Maximum Speed of SATA Speed...

  • Page 71: Amt Configuration

    BIOS 5.1.2.5. AMT Configuration Intel® Active Management Technology (Intel® AMT) is a hardware-based solution that uses out-of-band communication for basic management of client systems, which allows a system administrator to monitor and manage the computers and other network equipment by remote control even if the hard drive is crashed, the system is turned off or the operating system is locked.
  • Page 72 BIOS Enables/disables Hide Un-Configure ME without Hide Un-Configure ME password Confirmation Configuration Prompt function. Disabled is the default. MEBx Debug Message Enables/disables MEBx Debug Message Output function. Output Disabled is the default. Enables/disables Un-Configure ME without password Un-Configure ME function. Disabled is the default.

  • Page 73: Usb Configuration

    BIOS 5.1.2.6. USB Configuration Access this submenu to view the USB device(s) enabled in the system. It also configures USB-related features. The featured settings are: Setting Description / Available Options Enables/disables legacy USB support including USB flash drives and USB hard drives. Options available are Legacy USB Support Enabled: To enable legacy USB support.
  • Page 74 BIOS 5.1.2.7. F71869E Super IO Configuration This submenu opens in context with the system’s serial ports, COM1 and COM2, to configure the Super IO chipset. The featured settings are: Submenu/Setting Description Configures the system’s serial port (COM port). The featured settings are: Setting Description Serial Port 1...
  • Page 75 BIOS 5.1.2.8. F81866 H/W Monitor H/W Monitor monitors the computer's hardware status. Select this submenu to run a report of the info including CPU/system temperatures, CPU speed and other voltage info. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save &...
  • Page 76 BIOS 5.1.2.9. F81216 Second Super IO Configuration Use this submenu to enable/disable the computer’s serial ports 7~10. The featured submenus are: Submenu Description Configures the computer’s Serial Port 7 (COMA). The featured settings are: Serial Port 7 Setting Description Configuration Enables/disables the serial port.

  • Page 77: Chipset

    BIOS 5.1.3. Chipset The Chipset menu controls the system’s chipset, including the north bridge and the south bridge. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit PCH-IO Configuration PCH Parameters System Agent (SA) Configuration →←: Select Screen : Select Item...
  • Page 78 BIOS 5.1.3.1. PCH IO Configuration Access this submenu to configure PCH parameters. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Intel PCH RC Version 1.6.2.0 PCI Express Configuration Intel PCH SKU Name QM87 Settings.
  • Page 79 BIOS 5.1.3.1.1. PCI Express Configuration Access this submenu for the following settings: Setting Description Enables/disables PCI Express Root Port 5,6,7,8. Enabled is the default. ASPM Support Options are: Disable : disables ASPM PCI Express Root L0s : force all links to L0s state Port 5,6,7,8 L1 : force all links to L1 state L0sL1 : force all links to L0s+L1 state...
  • Page 80 BIOS 5.1.3.2. System Agent (SA) Configuration Access this submenu to configure the system agent. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit System Agent Bridge Name Haswell Enable or disable CPU SA Audio System Agent RC Version 1.6.2.0 Device.
  • Page 81 BIOS 5.1.3.2.1. Graphics Configuration Access this submenu to configure the system’s Graphics. Select Graphics Configuration to view graphics info and accesses graphics settings. The featured settings are: Setting Description Select which of IGFX/PEG/PCI graphic device to be the Primary Display Primary Display or SG for Switch Gfx.

  • Page 82: Boot

    BIOS 5.1.4. Boot Access this Boot menu to configure how to boot up the system such as boot device priority. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Configuration Select the keyboard NumLock Setup Prompt Timeout State...
  • Page 83 BIOS Configures power delay function by the following settings: Setting Description Enables/disables power delay function: Power Delay Enable is the default. Function Select Disabled to manually Power Delay Function power on/off.. Configures how much time should be delayed for the system to power Power on Options available are delay...

  • Page 84: Security

    BIOS 5.1.5. Security The Security menu sets up the password for the system’s administrator account. Once the administrator password is set up, this BIOS Setup utility is limited to access and will ask for the password each time any access is attempted. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.

  • Page 85: Save & Exit

    BIOS 5.1.6. Save & Exit The Save & Exit menu features a handful of commands to launch actions from the BIOS Setup utility regarding saving changes, quitting the utility and recovering defaults. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save &...
  • Page 86 This page is intentionally left blank. - 76 -...

  • Page 87: Appendices

    Appendices Appendices - 77 -...

  • Page 88: Appendix A: Wifi-At2350 Hardware Installation

    Appendices Appendix A: WiFi-AT2350 Hardware Installation To use Wi-Fi, hardware-wise the computer needs a Wi-Fi module installed. This appendix will guide you to install the Wi-Fi module WiFi-AT2350. Remove the computer’s top cover as described in on page 4.1.1. Open the Computer The inside of the computer comes to view.
  • Page 89 Appendices Prepare the WiFi-AT2350 Wi-Fi module kit. The module is a half-size module of PCI Express Mini-card form factor, with two U.FL connectors, one is “MAIN“, and the other is “AUX“. Two U.FL connectors, one is “MAIN”, the other is “AUX”. Plug the Wi-Fi module to the socket’s connector by a slanted angle.
  • Page 90 Appendices Remove one plastic plug from the computer's front panel to make an antenna hole. Keep the plastic plug for any possible restoration in the future. An antenna hole w/o Antenna holes stopped up by plugs the plug the removed plug a view from the inside of the computer a view outside the computer Have the RF antenna.
  • Page 91 Appendices From the other end of the RF antenna, which is an SMA connector, remove the washer and the nut. Save the washer and nut for later use. Note the SMA connector has the form of a threaded bolt, with one flat side. Among the screw Remove thread, there is a...
  • Page 92 Appendices 12. Have an external antenna. Screw and tightly fasten the antenna to the SMA connector. - 82 -...

  • Page 93: Appendix B: Install Msata Storage

    Appendices Appendix B: Install mSATA Storage To install an mSATA storage module to the computer: Remove the top cover from the computer as described in 4.1.1. Open the Computer on page 46. See the illustration below and find the PCI Express Mini-card socket for an mSATA storage.
  • Page 94 Appendices Fully plug the module until it cannot be plugged any more. Connector break Fully plug the module. Press down the module and fix the module in place using two screws. Restore the top cover to the computer. - 84 -...
