Summary of Contents for Zycoo COOFONE-D60

Page 2: Safety Notices
Safety Notices Please read the following safety notices before installing or using this phone. They are crucial for the safe and reliable operation of the device.  Please use the external power supply that is included in the package. Other power supplies may cause damage to the phone, affect the behavior or induce noise.
Page 3: Table Of Contents
Table of Content Chapter 1 Brief Introduction to D60 ................ 1 Thank You for Purchasing D60 ......................1 Delivery Content ..........................1 Specification Hardware ........................2 Features ............................2 Key Descriptions ..........................4 Port for Connecting ...........................5 Icon Introduction ..........................6 LED Status Introduction ........................7 Chapter 2 Initial Connection and Login..............
Page 4 Dial Plan ............................20 Dial Peer ............................20 Auto Redial ............................ 20 Call Completion ..........................21 Ring from Headset ......................... 21 Power Light ............................ 21 Hide DTMF ............................. 21 5.10 Ban Outgoing ..........................21 5.11 Password Dial ..........................21 5.12 Pre Dial ............................
Page 5: Chapter 1 Brief Introduction To D60
Quick Installation Guide Attentions: The D60 may cause damage if you use other power adapter which is not provided by ZYCOO. If the supplied power adapter cannot be used locally due to area or other reasons, please consult your local dealer.
Page 6: Specification Hardware
Copyright ©ZYCOO All rights reserved. V1.0 1.3 Specification Hardware Item D60 VoIP Phone Adapter (Input / Output) Input: 100-240V, Output: 5V 1A 10/100Base- T RJ-45 1 Port Port 10/100Base- T RJ-45 1 Port Power Consumption Idle: 2.5W/Active: 2.8W LCD Size 128x64pixels, 75.49 x 37.73mm...
Page 7 Copyright ©ZYCOO All rights reserved. V1.0  Advanced Features 8 DSS keys Support headset RJ9 Support 5 extension console with each consisting of 26 keys Soft keys programmable, function keys programmable Customizable multi-language version, the default is English Flexible call control functions...
Page 8: Key Descriptions
Copyright ©ZYCOO All rights reserved. V1.0 1.5 Key Descriptions Key name Function Description Default SIP line key. The user can select SIP line to call, the call can also be defined as a line key, the call for a different way selector.
Page 9: Port For Connecting
Copyright ©ZYCOO All rights reserved. V1.0 Digital Inputting the phone number or DTMF keyboard You can configure them in the web page, the configuration of each key to a DSS Keys different function keys it would more convenient to you.
Page 10: Icon Introduction
Copyright ©ZYCOO All rights reserved. V1.0 1.7 Icon Introduction Icon Description Call out Call in Call hold Auto answer Call mute Contact DND(Do not Disturb) In hand-free mode In hook mode In headset mode Missed call Call forward...
Page 11: Led Status Introduction
Copyright ©ZYCOO All rights reserved. V1.0 1.8 LED Status Introduction Table 1 Programmable key for BLF LED Status Description Solid green The monitored user is idle. Slow blinking red The monitored user receives an incoming call. Solid red The monitored user is active...
Page 12: Chapter 2 Initial Connection And Login
Copyright ©ZYCOO All rights reserved. V1.0 Chapter 2 Initial Connection and Login 2.1 Connection Step 1 Handset Connection Plug one end of the handset cord into the handset and the other end into the handset jack. Step 2 Power system Connection The D60 can be powered either by external AC/DC adapter or by connecting to an IEEE802.3af/at PSE device such...
Page 13 Copyright ©ZYCOO All rights reserved. V1.0 Step 3 Network Connection Internet Ethernet Switch IP PBX Step 4 Computer Network Connection Set your computer’s IP address to 192.168.0.x, where x is the number between 2 to 254 (except 1 where is used for the phone by default).
Page 14: Network Settings
Copyright ©ZYCOO All rights reserved. V1.0 2.2 Network Settings Please make sure the network is connected already. D60 uses DHCP to get WAN IP, the phone could access to network as long as there is DHCP server. If there is not DHCP server, the phone has to be changed to Static IP or PPPoE.
Page 15: Chapter 3 Basic Function
Copyright ©ZYCOO All rights reserved. V1.0 Chapter 3 Basic Function 3.1 Making a Call 3.1.1 Call Device You can make a phone call via the following devices: 1) Pick up the handset， icon will be displayed in the idle screen.
Page 16: Dnd
Copyright ©ZYCOO All rights reserved. V1.0 3.3 DND Press DND softkey to active DND Mode. Further incoming calls will be rejected and the LCD shows: icon. Press DND twice to cancel DND mode. You can find the incoming call record in the Call History.
Page 17: Mute
Copyright ©ZYCOO All rights reserved. V1.0 3.7 Mute Press Mute button during the conversation, icon will be shown on the LCD. Then the caller will not hear you, but you can hear the caller. Press it again to get the phone to normal conversation.
Page 18: Multiple-Way Call
Copyright ©ZYCOO All rights reserved. V1.0 3.10 Multiple-Way Call If you have 2 lines calls and want to invite the third party during the call, you can press softkey Conf or softkey XFER “New Call”, press OK, enter the number, then press Send and wait for the other party to answer. When there are multiple way calls, you can press an arrow key to select a call.
Page 19: Chapter 4 Advanced Function
Copyright ©ZYCOO All rights reserved. V1.0 Chapter 4 Advanced Function 4.1 Call Pickup Call pickup is implemented by simulating pickup function of PBX; that is, when A calls B, B rings but no answer, at this moment, C can hook off and input an appointed prefix plus B’s number, pick up A’s call and talk to A.
Page 20: Click To Dial
Copyright ©ZYCOO All rights reserved. V1.0 4.4 Click to Dial When user A browses on an appointed Web page, user A can click to call user B via a link (this link to user B), then user A’s phone will ring, after A hooks off, the phone will dial to B.
Page 21: Memo
Copyright ©ZYCOO All rights reserved. V1.0 4.8.2 Memo You can add some memos to record some important things to remind you. Press Menu->Application->Memo->Enter->Add. There are some options to configure: Mode, Date, Time, text, Ring. When the configuration is completed, press Save.
Page 22: Speed Dial
Copyright ©ZYCOO All rights reserved. V1.0 Speed dial You can configure the key as a simplified speed dial key. This key function allows you to easily access your most dialed numbers. Intercom You can configure the key for Intercom code and it is useful in an office environment as a quick access to connect to the operator or the secretary.
Page 23 Copyright ©ZYCOO All rights reserved. V1.0  Headset  Release：Press this button, you can end all calls  Lock：You can select whether the keypad lock in the standby interface   Call Back  Power Light  Hide DTMF ...
Page 24: Chapter 5 Other Functions
Copyright ©ZYCOO All rights reserved. V1.0 Chapter 5 Other Functions 5.1 Auto Handdown 1. Press Menu ->Features-> Enter->Auto Handdown-> Enter. 2. Enable the mode through the navigation key, then set Time, unit is minute, then press Save. 3. When the call ends, after the time that you have set, the phone will back to the idle mode.
Page 25: Call Completion
Copyright ©ZYCOO All rights reserved. V1.0 5.6 Call Completion 1. Press Menu ->Features-> Enter->Call Completion-> Enter. 2. Enable the function through the navigation key, and then Save. 3. Call out others, if he/she is busy, it will pop up a prompt Call Completion Waiting number. Press OK, when he/she is idle, it will pop up a prompt Call Completion Call number.
Page 26: Pre Dial
Copyright ©ZYCOO All rights reserved. V1.0 5.12 Pre Dial 1. Press Menu ->Features-> Pre Dial-> Enter. 2. Enable this function and you will realize Pre-Dial function. 5.13 Action URL & Active URI 1.Action URL: The action that the phone carries out. For example, opening DND can produce one URL, and then the phone can send the HTTP to get the URL to PC.
Page 27: Chapter 6 Basic Settings
Copyright ©ZYCOO All rights reserved. V1.0 Chapter 6 Basic Settings 6.1 Keyboard 1. Press Menu ->Settings-> Enter->Basic Settings-> Enter->Keyboard->Enter. 2. There are four items: DSS Key settings, Programmable Key Settings, Desktop Long Pressed, Soft Key. You can set up respectively on them. Press Enter to enter the interface, then use the navigation keys to choose the function for the key according to your requirement.
Page 28: Language
Copyright ©ZYCOO All rights reserved. V1.0 6.7 Language 1. Press Menu ->Settings-> Enter->Basic Settings-> Enter->Language ->Enter. 2. The D60 supports three languages. You can use the navigation keys to choose. The default two languages are English and Chinese.
Page 29: Chapter 7 Advance Settings
Copyright ©ZYCOO All rights reserved. V1.0 Chapter 7 Advance Settings 7.1 Accounts Press Menu->Enter->Advanced settings, and input the password to enter the interface, the default password is 123. You can set it through the web page. Then choose Account and press Enter, you can do some sip settings.
Page 30: Chapter 8 Web Configuration
Copyright ©ZYCOO All rights reserved. V1.0 Chapter 8 Web Configuration 8.1 Introduction of Configuration 8.1.1 Ways to Configure D60 has three different ways to different users.  Use phone keypad.  Use web browser (recommended way).  Use telnet with CLI command.
Page 31: Configuration Via Web
Copyright ©ZYCOO All rights reserved. V1.0 After you configure the IP phone, you need click save button in config under Maintenance in the left catalog to save your configuration. Otherwise the phone will lose your modification after power is off and on.
Page 32 Copyright ©ZYCOO All rights reserved. V1.0 8.2.1.2 WIZARD Wizard Please select the proper network mode according to the network condition. D60 provides three different network settings:  Static: If your ISP server provides you the static IP address, please select this mode, and then finish Static mode setting.
Page 33 Copyright ©ZYCOO All rights reserved. V1.0 Display Name Set the display name. Server Address Input your SIP server address. Server Port Set your SIP server port. Authentication User Input your SIP register account name. Authentication Password Input your SIP register password.
Page 34 Copyright ©ZYCOO All rights reserved. V1.0 Server name, if PPPOE service providers are no special requirements, this name is PPPoE Server usually the default value. User Input your ADSL account Password Input your ADSL password Notice: Click Finish button after finished your setting, IP Phone will save the setting automatically and reboot.
Page 35: Network
Copyright ©ZYCOO All rights reserved. V1.0 8.2.1.4 LANGUAGE LANGUAGE Item Explanation Language Set the language of phone, English is default. The greeting words will display on LCD when phone is idle. It can support 12 Greeting Words characters. the default chars are VOIP PHONE.
Page 36 Copyright ©ZYCOO All rights reserved. V1.0 Active IP Address The current IP address of the phone Current Subnet Mask The current Net mask address MAC Address The current MAC address of the phone Current IP Gateway The current Gateway IP address...
Page 37 Copyright ©ZYCOO All rights reserved. V1.0 IP Gateway Input the Gateway address distributed to you. Set DNS domain postfix. When the domain which you input cannot be parsed, DNS Domain phone will automatically add this domain to the end of the domain which you input before and parse it again.
Page 38: Lan Configuration
Copyright ©ZYCOO All rights reserved. V1.0 LAN Configuration Item Explanation LAN IP Address Specify LAN static IP Subnet Mask Specify LAN Net mask Select the DHCP server of LAN port or not. After you modify the LAN IP address, phone will amend and adjust the DHCP Lease Table and save the result amended DHCP Service automatically according to the IP address and Net mask.
Page 39 Copyright ©ZYCOO All rights reserved. V1.0 In chart 1, there is a layer 2 that switches without setting VLAN. Any broadcast frame will be transmitted to the other ports except the send port. For example, a broadcast information is sent out from port 1 then transmitted to port 2,3and In chart 2, red and blue indicate two different VLANs in the switch, and port 1 and port 2 belong to red VLAN, port 3 and port 4 belong to blue VLAN.
Page 40 Copyright ©ZYCOO All rights reserved. V1.0 QoS & VLAN Configuration Item Explanation Link Layer Discovery Protocol (LLDP) Settings Enable LLDP Enable LLDP by selecting it. After enabling LLDP Learn, telephone can automatically learn the data of DSCP, 802.1p, VLAN ID from the switch. If the data is different from the data of the LLDP...
Page 41 Copyright ©ZYCOO All rights reserved. V1.0 Service Port Item explanation Web Server Type Specify Web Server Type. Set web browser port, the default is 80 port, if you want to enhance system safety, you'd better change it into non-80 standard port;...
Page 42 Copyright ©ZYCOO All rights reserved. V1.0 DHCP SERVICE Item explanation IP-MAC mapping table. If the LAN port of the phone connects to a device, this DHCP Lease Table table will show the IP and MAC address of this device. Shows the DHCP Lease Table， the unit of Lease time is Minute.
Page 43 Copyright ©ZYCOO All rights reserved. V1.0 TIME&DATE Item Explanation Simple Network Time Protocol (SNTP) Settings Enable SNTP Enable SNTP by selecting it. Enable DHCP Time Enable DHCP Time by selecting it, then the phone will automatically synchronize the standard time.
Page 44: Voip
Copyright ©ZYCOO All rights reserved. V1.0 Manual Time Settings Notice: First of all, you need to disable the SNTP service, and above the date hours minutes each of which is required to complete and submit to make manual. 8.2.3 VOIP 8.2.3.1...
Page 45: Sip Configuration
Copyright ©ZYCOO All rights reserved. V1.0 SIP Configuration Item explanation SIP Line Choose line to set info about SIP, there are 4 lines to choose. You can switch by【Load】button. Basic Settings Status Shows if the phone has been registered the SIP server or not; or so, show Unapplied.
Page 46 Copyright ©ZYCOO All rights reserved. V1.0 Server Port Set your SIP server port. Authentication User Input your SIP register account name. Authentication Password Input your SIP register password. SIP User Input the phone number assigned by your VoIP service provider. Phone will not register if there is no phone number configured.
Page 47 Copyright ©ZYCOO All rights reserved. V1.0 SIP Encryption Enable/Disable SIP Encryption. SIP Encryption Key Set the key for sip encryption. RTP Encryption Enable/Disable RTP encryption. RTP Encryption Key Set the key for RTP encryption. Enable Auto Answer Enable Auto Answer by selecting it.
Page 48 Copyright ©ZYCOO All rights reserved. V1.0 it to the set number automatically based the forward type. And the IP phone will not show the record in the call history anymore. Busy CFwd Off Code Set the Busy CFwd Off Code, when you choose to disable the busy forward function on your phone, it will send message to the server, and the server will turn off the function immediately.
Page 49 Copyright ©ZYCOO All rights reserved. V1.0 as you select. For example, if the server is CISCO5300, you need to change to RFC2543; else phone may not cancel call normally. System uses RFC3261 as default. Transport Protocol Set transport protocols, TCP or UDP;...
Page 50: Iax2 Configuration
Copyright ©ZYCOO All rights reserved. V1.0 8.2.3.2 IAX2 IAX2 Configuration Item explanation Status Shows if the phone has been registered the IAX2 server or not. Server Address Input your IAX2 server address. Server Port Set your IAX2 server port, the default is 4569.
Page 51 Copyright ©ZYCOO All rights reserved. V1.0 STUN: By STUN server, the phone in private network could know the type of NAT and the NAT mapping IP and port of SIP. The phone might register itself to SIP server with global IP and port to realize the device both calling and being called in private network.
Page 52 Copyright ©ZYCOO All rights reserved. V1.0 Choose line to set info about SIP, There are 2 lines to choose. Use STUN Enable/Disable SIP STUN. Notice: SIP STUN is used to realize SIP penetration to NAT. If your phone configures STUN Server IP and Port (default is 3478), and enable SIP Stun, you can use the ordinary SIP Server to realize penetration to NAT.
Page 53 Copyright ©ZYCOO All rights reserved. V1.0 DIAL PEER Item explanation Phone number There are two types of matching conditions: one is full matching, the other is prefix matching. In the Full matching, you need input your desired phone number in this blank, and then you need dial the phone number to realize calling to what the phone number is mapped.
Page 54 Copyright ©ZYCOO All rights reserved. V1.0 Examples of Different Alias Application Set by web explanation example You need set phone number, Destination, Alias and Delete Length. Phone number is XXXT; Destination is 255.255.255.255 (0.0.0.2) and Alias is del. If you dial “93333”, the SIP2 This means any phone No.
Page 55 Copyright ©ZYCOO All rights reserved. V1.0 8.2.3.5 MCAST Use the multicast function to send notice to every member of the multicast is simple and easy. By setting the multicast key on your phone, you can send multicast RTP flow to the pre-configured multicast address. By listening multicast address is configured on the phone, listen and play the multicast address to send the RTP stream.
Page 56: Phone
Copyright ©ZYCOO All rights reserved. V1.0 2、 Press the hold key to hold the current multicast session 3、 Press the end key again or multicast function key, multicast session can be stopped Notice: RTP stream is one side that is from a sender to a receiver. When the phone initiates a multicast RTP session in a call, the current call is on hold.
Page 57 Copyright ©ZYCOO All rights reserved. V1.0 AUDIO Configuration Item explanation First Codec The first preferential DSP codec: G.711A/u, G.722, G.723.1,726-32 G.729AB,None. Second Codec The second preferential DSP codec: G.711A/u, G.722, G.723.1,726-32 G.729AB,None. Third Codec The third preferential DSP codec: G.711A/u, G.722, G.723.1,726-32 G.729AB,None.
Page 59 Copyright ©ZYCOO All rights reserved. V1.0 FEATURE Item explanation Do Not Disturb Select DND, the phone will reject any incoming call, the callers will be reminded by busy, but any outgoing call from the phone will work well. Ban Outgoing If you select Ban Outgoing to enable it, and you cannot dial out any number.
Page 60 Copyright ©ZYCOO All rights reserved. V1.0 Time after Auto Hand down Time at hands-free mode, and play dial tone Auto Hand down Time at handset mode. Ring From Enable Ring From Handset by selecting it, the phone plays ring tone from handset.
Page 61 Copyright ©ZYCOO All rights reserved. V1.0 Block out Wildcard x means matching any single digit. For example, 4xxx expresses any number with prefix 4 which length is 4 will be forbidden to be dialed out; 6 expresses any number with prefix 6 will be forbidden to be dialed out.
Page 62 Copyright ©ZYCOO All rights reserved. V1.0 DIAL PLAN Configuration Item Explanation Basic Setting Press "#" to Send Set Enable/Disable the phone ended with “#” dial. Dial Fixed Length Specify the Fixed Length of phone ending with. Press # to Do Blind...
Page 63 Copyright ©ZYCOO All rights reserved. V1.0 Contact Item Explanation Phonebook Table Name Shows the name corresponding to the phone number. Shows the detail of current phonebook. Notice: the maximum capability of the phonebook is 500 items, you can select many or a contact to add to...
Page 64 Copyright ©ZYCOO All rights reserved. V1.0 Add Contact List Name Specify the name corresponding to the phone number. Office Number Specify the office number. Mobile Number Specify the mobile number. Other Number Specify the other number. Ring Type Specify the ring type for the phone number.
Page 65 You need to match a XML Phonebook address and you can directly access to the corresponding remote phonebook on the phone. For example: Set the Phonebook Name as ZYCOO, Server URL is tftp://192.168.1.3/admin/phonebook/index.xml. Or Set the Phonebook Name as ldap, Server URL is ldap://192.168.1.3/dc=winline,dc=com.
Page 66: Function Key
Copyright ©ZYCOO All rights reserved. V1.0 You can make a call through the WEB DIAL, enter the Dial Number then press Dial, if you want to finish the talk, press Hang-up. 8.2.5 FUNCTION KEY 8.2.5.1 FUNCTION KEY...
Page 67 Copyright ©ZYCOO All rights reserved. V1.0 Function Key Item Explanation Contrast Set contrast of screen. Enable Backlight Set enable/disable backlight. Line Key Settings Line: select Auto, SIP1, SIP2 or IAX2 in function key type. After you set it, you pick up handset or hands-free, press this function key, and then you can use the corresponding SIP line.
Page 69: Maintenance
Auto Provision Settings ZYCOO endpoint supports PnP and DHCP and Phone Flash to obtain the parameters. The PnP and DHCP and Phone Flash are all deployed, endpoint will go by the following process to try to obtain the server address and other parameters, when it boots up: DHCP option ...
Page 70 Copyright ©ZYCOO All rights reserved. V1.0 PnP Transport Specify the PnP Transfer protocol. PnP Interval Specify the Interval time, unit is hour. Phone Flash Server Address Set FTP/TFTP/HTTP server IP address for auto update. The address can be IP address or Domain name with subdirectory.
Page 71: Syslog Configuration
Copyright ©ZYCOO All rights reserved. V1.0 Syslog Configuration Item Explanation Syslog Setting Server Address Set Syslog server IP address. Server Port Set Syslog server port. MGR Log Level Set the level of MGR log. SIP Log Level Set the level of SIP log.
Page 72 Copyright ©ZYCOO All rights reserved. V1.0 Update Item Explanation Web Update Click the browse button, find out the config file saved before or provided by manufacturer, Web Update download it to the phone directly, press “Update” to save. You can also update downloaded update file, logo picture, ring, mmiset file by web.
Page 73 Copyright ©ZYCOO All rights reserved. V1.0 Select File Select the logo that you want to delete. Logo File Logo File Show the logo file. 8.2.6.5 ACCESS You can add or delete user account, and change the authority of each user account in this web page.
Page 74: Security
Copyright ©ZYCOO All rights reserved. V1.0 8.2.6.6 REBOOT If you modified some configurations which need the phone’s reboot to be effective, you need click the Reboot, then the phone will reboot immediately. Notice: Before reboot, you need confirm that you have saved all configurations.
Page 75: Firewall Configuration
Copyright ©ZYCOO All rights reserved. V1.0 8.2.7.2 FIREWALL Firewall Configuration In this web interface, you can set up firewall to prevent unauthorized Internet users from accessing private networks connected to the Internet (input rule), or prevent unauthorized private network devices from accessing the Internet (output rule).
Page 76 Copyright ©ZYCOO All rights reserved. V1.0 Dest Mask Set the destination address’ mask. For example, 255.255.255.255 means just point to one host; 255.255.255.0 means point to a network which network ID is C type. Click the Add button if you want to add a new output rule.
Page 77 Copyright ©ZYCOO All rights reserved. V1.0 NAT Configuration Item Explanation IPSec ALG It is an encryption technology. Select it to enable IPSec ALG, the default is enabled. FTP is a service of connection layer which can transform intranet IP into extranet IP FTP ALG when intranet IP is sending out packet.
Page 78 Copyright ©ZYCOO All rights reserved. V1.0 Notice: After finish setting, click the Add button to add new mapping table; click the Delete button to delete the selected mapping table. Shows the outside WAN port IP address and the inside LAN port IP address.
Page 79: Logout
Copyright ©ZYCOO All rights reserved. V1.0 VPN Configuration Item Explanation VPN IP Shows the current VPN IP address. Select L2TP. You can choose only one for current state. After you select it, you’d better save configuration and reboot your phone.
Page 80: Chapter 9 Appendix
Copyright ©ZYCOO All rights reserved. V1.0 Chapter 9 Appendix Digit-character map table Keypad Character Keypad Character 7 P Q R S p q r s 2 A B C a b c 8 T U V t u v 3 D E F d e f...
