  • Page 1 F O R S M A L L B U S I N E S S Quick Installation Guide IP PHONE SYSTEM CooVox-T100S...
  • Page 2 CooVox-T100S Thank you for using the ZYCOO IP PBX, Thank you for using the ZYCOO IP PBX, Please read the instructions carefully before use. Please read the instructions carefully before use. CooVox-T100S is an easy-to-configure and delicate diminutive IPPBX system for small and medium-sized enterprises worldwide, especially for SIP trunk users.
  • Page 3: Table Of Contents

    CONTENTS ..... Package Contents ....Hardware Installation 2 .
  • Page 4: Package Contents

    Package Contents Thank you for purchasing ZYCOO IP phone system. These are the items Included with your IP phone system purchase: IP PBX T100S(1PCS) Power Adapter(1PCS) Network cable(1PCS) Quick Installation Guide (1PCS) Warranty Card (1PCS)
  • Page 5: Hardware Installation

    Hardware Installation The followings are the instructions for setting up ZYCOO T100S IP PBX. Please refer to the illustration and follow the simple steps below to quickly install your IP phone system. Safety Precautions To avoid any device damage and bodily injury caused by improper use, please observe the following rules.
  • Page 6 Site Requirements 40℃ 0℃ Temperature Humidity Environment 0℃~40℃ 10%~90% RH Non-condensing Operating -40℃~70℃ 5%~90% RH Non-condensing Storage Clearness Dust the device regularly, and keep the indoor air clean. Keep the device well grounded and ensure static electricity has been transferred.
  • Page 7 Please keep T100S far away from the electromagnetic interference to avoid damage to the device. Desktop Installation Please place the CooVox T100S on a steady platform Caution: 1.Please set a 5-10cm gap around the device and keep the room well ventilated.
  • Page 8: Physical Connection

    Physical Connection Power Adapter Router...
  • Page 9: Led Definitions

    LED De nitions Label Function Status Indication Power on Power Status Off Power off System loading System Flash System running Status Off System unstart Connected Flash Data transfer Status Off Disconnected Connected Flash Data transfer Status Off Disconnected...
  • Page 10: Basic System Configuration

    Basic System Con guration Connect the CooVox-T100S with a PC directly via the WAN or LAN port. Make sure the PC and the IP-PBX are in the same network segment, that is, 192.168.1.xx if you are connected to WAN or 192.168.10.xx if you have connected to LAN. Open a web browser, preferably Firefox, Google Chrome, or IE 11 or higher.
  • Page 11 Fu her Information Thank you for the purchase of ZYCOO products. The above steps introduce basic configurations for CooVox–T100S. For further configurations, please refer to the user manual. If you have other questions, please contact the ZYCOO local dealers or distributors from where you purchased this product.
  • Page 12 Leading IP Phone System Provider ZYCOO Co., Ltd. No. 1602, 16th Floor, Building No. 599, Centu City South Road, High-tech Zone, Chengdu, Sichuan Province, China +86(0)28 85337096 sales@zycoo.com...
