Series S Infrared Heater
Installation, Operation and Service Instructions
FOR YOUR SAFETY
If you smell gas:
1. Open windows
2. Don't touch electrical switches
3. Extinguish any open flame
4. Immediately call your gas
supplier
CONSIGNES DE SECURITE
Si vous sentez une odeur de gaz:
1. Ouvrez les fenetres
2. Ne touchez pas aux interupteurs
electriques
3. Eteignez tout flamme nue
4. Contactez immediatment votre
fournisseur de gaz
Read and thoroughly understand these instructions before attempting any installation.
Improper installation, adjustment, alteration, service or maintenance can cause injury, death or property
damage. Read the installation, operation and service instructions thoroughly before installing or servicing
Installer
Owner
Retain this manual for reference.
WARNING
this equipment.
Superior Radiant Products
www.superiorradiant.com
FOR YOUR SAFETY
Do not store or use gasoline or
other flammable vapors and liquids
in the vicinity of this or any other
appliance.
CONSIGNES DE SECURITE
Il est interdit d'utiliser des liquides
inflammables ou degageant des
vapeurs inflammables, a proximites
de tout appareil fonctionnent au
gaz.
01/15 LT017
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Superior Radiant S series
Summary of Contents for Superior Radiant S series
- Page 1 Retain this manual for reference. WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury, death or property damage. Read the installation, operation and service instructions thoroughly before installing or servicing this equipment. Superior Radiant Products www.superiorradiant.com 01/15 LT017...
- Page 2 CAUTION: FIRE OR EXPLOSION HAZARD Maintain clearance to combustible constructions as further specified in this manual. Failure to do so could result in a serious fire hazard. Heaters should not be located in hazardous atmospheres containing flammable vapors or combustible dusts. Signs should be provided in storage areas specifying maximum safe stacking height.
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ________________________________________________________________________ 4 Installation Codes ____________________________________________________________________________ 5 General Installation and Gas Codes/Electrical Codes _________________________________________________________ 5 Aircraft Hangar Installation ______________________________________________________________________________ 5 Public Garages ________________________________________________________________________________________ 5 Parking Structures _____________________________________________________________________________________ 5 LAYOUT RECOMMENDATIONS ____________________________________________________________ 6 Layout Considerations ________________________________________________________________________ 6 Spot Heating ________________________________________________________________________________ 6 Full Building Heat ____________________________________________________________________________ 7 HEATER SPECIFICATIONS _________________________________________________________________ 8 Dimensional Chart ___________________________________________________________________________ 8... -
Page 4: Introduction
INTRODUCTION Superior Radiant Products is a company in the infrared heating industry founded on the principles of product quality and customer commitment. Quality commitments are evidenced by superior design, a regard for design detail and an upgrade of materials wherever justifiable. -
Page 5: Installation Codes
INTRODUCTION Installation Codes Installations must comply with all local building codes or in their absence; the latest edition of the national regulations and procedures applicable to gas fired and suspended heaters. General Installation and Gas Codes/Electrical Codes Heaters must be installed only for use with the type of gas appearing on the rating plate, and the installation must conform to the National Fuel Gas Code, ANSI Z.223.1 (NFPA 54) in the US and CAN/CGA B149.1 and B149.2 Installation Codes in Canada. -
Page 6: Layout Recommendations
LAYOUT RECOMMENDATIONS Layout Considerations 1. Because high intensity heaters are un-vented, verify local codes for guidance on air supply and dilution air. Also see section on Ventilation. 2. Check local codes for mounting requirements and the requirement for flexible gas connectors or rigid mounting. -
Page 7: Full Building Heat
LAYOUT RECOMMENDATIONS Suggested heat loading for indoor spot heating under stated conditions: BTU/hr per sq. ft of Floor Area to be Heated Ambient Air Temperature At 50 ft/min of wind At 100 ft/min of wind (15.2 m/min) (30.5 m/min) 150—165 165—180 40°F / 4°C 55°F / 13°C... -
Page 8: Heater Specifications
HEATER SPECIFICATIONS Figure 1: Overall Dimensional Information Dimensional Chart Model # Natural Gas 33,000 66,000 99,000 132,000 160,000 Input BTU/hr 30,000 60,000 90,000 120,000 Propane Gas 16.3 41.4 23.1 58.7 76.2 36.9 93.7 36.9 93.7 24.4 24.4 24.4 24.4 24.4 10.7 10.7 10.7... -
Page 9: Gas Supply
HEATER SPECIFICATIONS Gas Supply Natural Gas Propane Minimum 6.5 W.C. Minimum 11.0 W.C. Pressure Maximum 14.0 W.C. Maximum 14.0 W.C. Connection ½ female NPT Manifold Pressure 6.0 W.C. 10 W.C. Electrical 120 V, 20 VA wired to junction box Requirements 24V, 20 VA Millivolt pilot system (3 options) -
Page 10: Clearance To Combustibles
CLEARANCE TO COMBUSTIBLES The stated clearance to combustibles represents a surface temperature of 90°F (50°C) above room temperature. Building materials with low heat tolerance (such as plastics, vinyl siding, canvas, tri-ply, etc…) maybe subject to degradation at lower temperatures. It is the installer’s responsibility to assure that adjacent materials are protected from degradation. -
Page 11: Installation
INSTALLATION Figure 3 illustrate typical rigid and chain mounting configurations for the Series S heaters; verify which is permissible by local codes. Heaters must be hung at an angle between 10° and 35°. Typically, at the walls they are at 35° facing into the building. -
Page 12: Electric
INSTALLATION Electric Figure 4 illustrates typical wiring arrangements for the Series S heater. Two options are available; 230V and 24V supply. Up to six heaters may be operated from one thermostat. (Verify thermostat electrical capacity if non SRP product is used.) ... - Page 13 INSTALLATION TRANSFORMER THERMOSTAT POWER CORD JUNCTION BOX CNE MODULE BROWN YELLOW GROUND ROD 24 V GREEN SPARK ELECTRODE PINK GAS VALVE FLAME SENSOR If any of the original wire as supplied with the Si l'un des fils électriques original fournis avec appliance must be replaced, it must be replaced cet appareil doit etre remplacé, le remplace avec with wiring material having a temperature rating...
-
Page 14: Ventilation / Condensation
VENTILATION / CONDENSATION Ventilation Buildings using high intensity radiant heaters require ventilation. High Intensity type heaters are considered un-vented gas fired appliances, requiring ventilation to supply combustion air and dilute/remove the products of combustion. Requirements for combustion air supply and dilution air vary by jurisdiction, building type and specific installation details. -
Page 15: Operation / Maintenence
OPERATION / MAINTENENCE Operation Ensure the gas supply line has been purged. Open all gas cocks to the heaters and electrically energize the system. Follow the instructions on the heaters Lighting Instructions Label. Check to ensure that the thermostat starts and shuts down the system. -
Page 16: Troubleshooting
TROUBLESHOOTING Symptom Possible Cause Corrective Acton Defective thermostat Repair or replace Heaters will not turn off Stuck solenoid valve Repair or replace Verify all connections are sealed by Gas Odor Loose pipe connection using an appropriate leak test Burning of gas/air mixture inside Cracks between or across ceramic grids Replace burner head assembly venturi (flashback) -
Page 17: Parts
PARTS GAS VALVE (P/N SG003 - NAT GAS) (P/N SG004 - LPG) TRANSFORMER (P/N SE004) IGNITION MODULE (P/N CE109) IGNITION WIRE (P/N CE006) BURNER HEAD ASSEMBLY (P/N SG009) ELECTRODE ASSEMBLY (P/N SE001) Figure 6: Replacement Parts Page - 17 - Series S March 4, 2014... -
Page 18: Warranty
WARRANTY SERIES S INFRARED HEATERS WARRANTY The Manufacturer warrants to the original owner that the product will be free of defects in material and workmanship. For the Series S, the warranty for all components except for the ceramic burner head assembly is limited to 24 months from the date of installation. The ceramic burner head assembly shall be warranted for an additional eight years for units which are proven to the satisfaction of the manufacturer to be inoperative due to defects in material or workmanship.
