Series LA/LX/LXR Infrared Heater
Installation, Operation and Service Instructions
FOR YOUR SAFETY
If you smell gas:
1. Open windows
2. Don't touch electrical switches
3. Extinguish any open flame
4. Immediately call your gas supplier
CONSIGNES DE SECURITE
Si vous sentez une odeur de gaz:
1. Ouvrez les fenetres
2. Ne touchez pas aux interupteurs
electriques
3. Eteignez tout flamme nue
4. Contactez immediatment votre
fournisseur de gaz
Read and thoroughly understand these instructions before attempting any installation.
Improper installation, adjustment, alteration, service or maintenance can cause injury, death or property
damage. Read the installation, operation and service instructions thoroughly before installing or
Retain this manual for reference.
WARNING
servicing this equipment.
Superior Radiant Products
23-428 Millen Road, Stoney Creek, Ontario L8E 3N9
www.superiorradiant.com
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
CONSIGNES DE SECURITE
Il est interdit d'utiliser des liquides
inflammables ou degageant des
vapeurs inflammables, a proximites de
tout appareil fonctionnent au gaz.
Installer
Owner
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Superior Radiant LA series
Summary of Contents for Superior Radiant LA series
- Page 1 Improper installation, adjustment, alteration, service or maintenance can cause injury, death or property damage. Read the installation, operation and service instructions thoroughly before installing or servicing this equipment. Superior Radiant Products 23-428 Millen Road, Stoney Creek, Ontario L8E 3N9 www.superiorradiant.com...
- Page 2 CAUTION: FIRE OR EXPLOSION HAZARD Maintain clearance to combustible constructions as further specified in this manual. Failure to do so could result in a serious fire hazard. Heaters should not be located in hazardous atmospheres containing flammable vapors or combustible dusts. Signs should be provided in storage areas specifying maximum safe stacking height.
-
Page 3: Table Of Contents
Table Of Contents INTRODUCTION ..........................2 Important ..............................2 Installation Codes ............................ 2 General Installation and Gas Codes ..................... 2 Aircraft Hangar Installation ......................2 Public Garage Installation ......................2 Gas Supply Lines ........................3 Electrical ............................ 3 Venting ............................3 GENERAL SPECIFICATIONS...................... -
Page 4: Introduction
Superior Radiant offers its 15 years of infrared expertise in a cost effective unitary heater design as culmination of that commitment. Series LA/LX/LXR models are field assembled, low intensity infrared heaters that are easy to install and maintain, and which were engineered with significant input from our customers. -
Page 5: Gas Supply Lines
Introduction Gas Supply Lines Gas supply pipe sizing must be in accordance with the National Fuel Gas Code, ANSI Z223.1 (NFPA 54) in the US and CAN/CGA B149.1 and B149.2 Installation Codes in Canada. A 1/8" inch NPT plugged tap must be installed in the gas line connection immediately upstream of the burner farthest from the gas supply meter to allow checking of system gas pressure. -
Page 6: Dimensional Charts
Dimensional Charts 18" 6" 16" 24" 14" 44" 12" 15" 12" 10' - 4" 9" Figure 1: Overall Dimensional Information ELBOW BAFFLE SECTION 16" WHEN INSTALLING, ORIENT BAND CLAMP LOCK BOLTS TO TOP, AT 10 O'CLOCK OR 2 O'CLOCK POSITION 4' OR 6' REFLECTOR COUPLING... -
Page 7: Configurations
Configurations Heat Exchanger Length (ft.) Rate Baffle Model (BTU/Hr) Length (ft.) Minimum Maximum LA/LX/LXR-40 40,000 LA/LX/LXR-60 60,000 LA/LX/LXR-80 80,000 LA/LX/LXR-100 100,000 Three 4' lengths Table1: Configuration Information Note: Baffles are always placed in the last section of radiant tube except for the 100,000 BTU burner. Baffles are either aluminized or stainless steel sections 6' ft. -
Page 8: Clearance To Combustibles
Clearance To Combustibles It is important to observe minimum clearance to combustibles at all times to avoid any possibility of property damage or personal injury. Clearances must be maintained from vehicles parked beneath heaters. Signs should be posted identifying any possible violation of the clearance distances from the heater in vehicle areas. -
Page 9: Clearance To Combustibles Materials
Clearance To Combustibles Model No.: LA / LX / LXR Reflector Configurations Dimension Horizontal 2" 2" 2" 2" 4" 4" 4" 6" 31" 31" 31" 36" 4" 4" 4" 6" 45° Reflector Tilt 3" 3" 3" 4" 3" 3" 3" 3"... -
Page 10: Installation Detail
Installation Detail Generally, there is no unique sequence for installation of the burner or heat exchanger. A review of the job site will usually indicate a logical installation order. However, time and expense can be saved if installation is begun at the most critical dimension, watching for interference from overhead doors, cranes, auto lifts etc. - Page 11 Installation Detail Figure 5 Installation Configuration for 80,000 BTUH Model Series-LA/LX/LXR Page 9 6/15/2010...
- Page 12 Installation Detail Figure 6 Installation Configuration for 80,000 BTUH Model Series-LA/LX/LXR Page 10 6/15/2010...
-
Page 13: Installation Sequence
Installation Sequence A general ordered sequence for installation is provided below for reference. • Locate hanging chain at predetermined suspension points in the structure. It is required that the • first hanging point be 2" inches to 8" inches from the burner mounting flange, the second Reflector End Cap Reflector... - Page 14 Installation Sequence Locate Tube and Reflector Hangers every 10' thereafter. 8' - 9' Coupling Should Be Loosely Fitted Install "J" Bolt at first hanger Tube Flange Combustion Tube Reflector Support Tube & Reflector 3" Hangers Figure 8 • Suspension mechanism must allow for lateral tubing expansion. A minimum 12" inch length welded link chain with a working load limit of at least 200 lbs.
- Page 15 Installation Sequence • Install the tube and reflector support hanger on the chain with “S-hooks”. • Place the first (flanged, aluminized) tube in the first two hangers. Be sure the flange is toward the intended burner location. The other end of the tube should have the first coupling already loosely fitted.
- Page 16 Installation Sequence • Locate the burner gasket provided, bolt the burner in place on the tube flange with provided hardware. Burner must never be installed in a tilted position. The sense electrode of the burner cup should be in the 12 o’clock position. •...
- Page 17 Installation Sequence Note: In order to obtain smoothly sealed coupling liners, tighten each of the coupling bands progressively and alternately. Tightening one band completely before the other may result in an undesirable wrinkle in the liner. Note: Be sure not to tile reflector sections; that is, reflector sections must be either above both adjacent reflector sections, or below both adjacent reflector sections.
- Page 18 Installation Sequence • If required by the heater layout, install 90° elbows or U-tube where indicated. Refer to Figure 16 for details. Note: Elbows or U-bends are typically installed without reflectors. To reduce the above clearance to combustibles distance use mitered reflectors (see figure 15) and refer to Clearance to Combustibles information.
- Page 19 Installation Sequence • If used, install the Mitered reflector as shown below. Assemble Corner Bracket to Mitered Reflectors as shown Fasten Mitered Reflectors with 4 #8 x 3/8" Screws Mitered Reflector Sections should overlap standard Reflectors. Installation of Mitered Reflector Sections Figure 18 •...
- Page 20 Installation Sequence Reflector Use hole as a guide to position side reflector. The side reflector end must be visible through the hole at room temperature. Side Reflector Retainer Bracket Side Shield Support Side Reflector Side Shield #8 X 3/8" Screw Screws to be installed from inside of side reflector.
- Page 21 Installation Sequence Deco-Grille Option Series LA/LX/LXR heaters are approved for the addition of Deco-Grille either directly to the heater reflector or as part of a T-Bar installation where the heater is above the ceiling structure. Refer to figures 23 and 24 below for details. Install End Cap as per "Installation of End Cap"...
-
Page 22: Venting / Combustion Air Ducting
Venting / Combustion Air Ducting General Requirements • Refer to the National Fuel Gas Code, ANSI Z223.1 (NFPA 54) in the US and CAN/CGA B149.1 and B149.2 Installation Codes in Canada, as well as all local requirements for general venting guidance. -
Page 23: Vented Operation
Venting / Combustion Air Ducting Vented Operation In all cases, be sure vent pipes and outside air supply ducts are sealed with approved sealant, such as high temperature RTV silicone. Double wall venting (B vent) may not require sealant. Horizontal Venting •... -
Page 24: Common Roof Venting
(Refer to ANSI Z223.1 and CAN/CGA B149.1 and B149.2 for sizes and installation information). Copies can be obtained from your local SRP representative or directly from Superior Radiant Products. • Use of an approved thimble to pass through combustible roof materials is required. Additionally, B type vent materials are required for stacks above the roof line. -
Page 25: Combustion Air Supply (Optional)
Combustion Air Supply Combustion Air Supply (Optional) • An outside combustion air supply is strongly recommended if the building space encloses a negative pressure due to exhaust etc. or if the building contains materials which would expose the heater to halogenated hydrocarbon atmospheres. •... -
Page 26: Gas Piping
Gas Piping General Requirements • The gas meter and service must be sufficiently large to supply gas to the connected building gas load including the heating equipment and any other gas fired equipment. Additionally, the gas distribution piping must be designed according to local and national ordinances. Generally (low pressure) systems designed with a maximum ½"... -
Page 27: Electrical Wiring
Electrical Wiring General Requirements Heaters are normally controlled by line voltage or low voltage (24V) thermostats. In all cases, heaters must be grounded in accordance with the National Electric Code, ANSI/NFPA 70 in the US, and the Canadian Electric Code, CSA C22.1 in Canada, and must comply with all local requirements. Heaters may also be controlled with a manual line switch or timer switch in place of the thermostat. -
Page 28: Burner Operation
Burner Operation Starting Sequence of Operation • Turn the thermostat up. When the thermostat calls for heat, the blower motor will energize. • When the motor approaches nominal running RPM, the air-proving switch closes and activates the ignition module. • The ignition module, after a pre-purge period of approximately 30 seconds, energizes the igniter. Additionally, the gas valve is energized for this ignition trial period of 15 seconds. -
Page 29: Troubleshooting
Troubleshooting Blower Motor Fails to Run • Is the thermostat calling for heat? Is there 115V at the burner receptacle? • Check blower side door for seal. Repair as necessary. • Check blower for obstructions. Replace blower if necessary. No Gas Supply •... -
Page 30: Troubleshooting Chart
Troubleshooting Chart Series-LA/LX/LXR Page 28 6/15/2010... -
Page 31: Replacement Parts
Replacement Parts GAS VALVE, MOTOR/BLOWER - HONEYWELL P/N CG003 NAT. (Models with 40,000 - 80,000 Btu input) - CE004 - HONEYWELL P/N CG010 LP. (Model with 100,000 Btu input) - CE013 - WHITE RODGERS P/N CG060 NAT. - WHITE RODGERS P/N CG061 LP. TRANSFORMER Models LA LX (40 VA) CE058 PRESSURE SWITCH... - Page 32 Notes Series-LA/LX/LXR Page 30 6/15/2010...
-
Page 33: Warranty
Warranty SERIES LA, LX and LXR INFRARED HEATERS WARRANTY The manufacturer warrants to the original owner that the product will be free of defects in material and workmanship as described below. Warranty Period Series Component Years Years Years Years Burner & Controls Hot Rolled Heat Exchanger w/o Post Purge Aluminized Heat Exchanger w/o Post Purge Hot Rolled Heat Exchanger with Post Purge...
