ELECTRIC INFRARED HEATERS
The manufacturer's instructions, the layout drawing, national and local codes and ordinances, and all applicable
standards which apply to electrical wiring comprise the basic information needed to complete the installation. These
criteria must be thoroughly understood before proceeding.
Only personnel who have been trained and understand all applicable codes should undertake the installation.
Manufacturer representatives are Factory Certified in the service and application of this equipment and can be
called on for helpful suggestions about installation.
Series sWAVE
Installation, Operation and Service Instructions
WARNING
Canada:
563 Barton Street, Stoney Creek, Ontario L8E 5S1`
USA:
315 N Madison Street, Fortville, IN 46040
www.superiorradiant.com
Page 1
SERIES sWAVE ™
Medium Wave Infrared Heater
SW18M12, SW36M12,
SW25M20, SW50M20, SW75M20
SW25M24, SW50M24, SW75M24
SW25M48, SW50M48, SW75M48
SW25M60, SW50M60, SW75M60
MODELS
LT446 Nov 14, 2024
Advertisement
Table of Contents
Related Manuals for Superior Radiant sWAVE SW18M12
Summary of Contents for Superior Radiant sWAVE SW18M12
- Page 1 Installation, Operation and Service Instructions ELECTRIC INFRARED HEATERS SERIES sWAVE ™ Medium Wave Infrared Heater MODELS SW18M12, SW36M12, SW25M20, SW50M20, SW75M20 SW25M24, SW50M24, SW75M24 SW25M48, SW50M48, SW75M48 SW25M60, SW50M60, SW75M60 WARNING The manufacturer’s instructions, the layout drawing, national and local codes and ordinances, and all applicable standards which apply to electrical wiring comprise the basic information needed to complete the installation.
-
Page 2: Table Of Contents
ONTENTS APPLICABLE CODES AND STANDARDS ............................ 2 TECHNICAL SPECIFICATIONS ..............................3 IMPORTANT INSTRUCTIONS ..............................4 SAFETY INSTRUCTIONS ................................4 ELECTRICAL AND OPERATING INSTRUCTIONS ......................... 5 DIMENTIONS ..................................5 WIRING DIADRAMS ................................6 CLEARANCE TO COMBUSTIBLES .............................. 7 SUPPLIED WALL/CEILING SUPPORT ............................11 INSTALLATION INSTRUCTIONS .............................. -
Page 3: Technical Specifications
Technical Specifications Voltage / Dimensions Weight Model Wattage Voltage Phase Connection L x W x H AL (SS) Residential / Commercial Models SW18M12 1800 W 120 Vac 15.0 A 1Φ2W, 120Vac 23.5” x 6.5” x 7” 4.0 (6.5) lbs SW25M20 2500 W 208 Vac 12.0 A... -
Page 4: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: 1. Read all instructions before installing or using this heater. 2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, etc. -
Page 5: Electrical And Operating Instructions
ELECTRICAL AND OPERATING INSTRUCTIONS General Requirements Turn the heater on only when you need heat and avoid any misuse. Do not use the heater if the ambient temperature exceeds 80°F (25°C). Before connecting the heater make sure that the supply voltage is the same as indicated on the rating plate. -
Page 6: Wiring Diadrams
WIRING DIAGRAMS Note: Replace L2 with Neutral for 120 VAC model. Unit with one heating element (1.8kW and 2.5kW) Unit with two heating elements (3.6kW and 5.0kW) Unit with three heating elements – single phase (7.5kW) Unit with three heating elements – three phase (7.5kW) Series sWAVE Page 6 LT446 Nov 14, 2024... -
Page 7: Clearance To Combustibles
CLEARANCE TO COMBUSTIBLES 1. The minimum installation height from the floor to the heater shall be 8ft (244cm). 2. The minimum clearances from the ceiling, walls and other objects are shown in the pictures below. 3. The stated clearance to combustibles represents a surface temperature of 117°F (65°C) above room temperature. 4. -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS The heater can be suspended with chains, or rigid threaded rod. Consult all local codes before installation. Maintain the clearances to combustibles all time. Ensure wire guard is installed before hanging the heater 13in [330mm] Note: The mounting distances vary when utilizing the hanging kit! 19in [485mm] 35in [890mm]... - Page 9 Note: Hanger supplied with heater. Hanger can be used for 0° & 30° mounting angles. 2. Use #8 Phillips Screw (supplied) to secure Hanger Bracket Base unto heater as shown. 3. Insert the safety guard into the slots, starting from the side of the heater marked with dots. Series sWAVE Page 9 LT446 Nov 14, 2024...
- Page 10 4. Horizontal Mounting: Attach chain to Center hole at the correct distance as shown in Step 1. 30° 5. 30 Degree Mounting: Attach Chain at one of the other holes at the correct distance as shown in Step 1. Heaters installed between 0° and 45° shall maintain clearances for 0°...
-
Page 11: Supplied Wall/Ceiling Support
OPTIONAL WALL/CEILING HANGING KIT #SS071 Ceiling Hanging Orientation Wall Hanging Orientation (* Refer to Clearances Table) Ensure that the wall where you intend to install the heater is solid and that no electrical cables or water pipes pass behind it. Maintain the clearances to combustibles all time. - Page 12 3. Use #8 Phillips Screw (supplied with kit) to secure Hanger Bracket Base unto heater as shown. 4. Secure the brackets in place by inserting and tightening the provided screws and nuts. Series sWAVE Page 12 LT446 Nov 14, 2024...
- Page 13 Note: Square Hole are This orientation allows used to position unit into for removal of service easy service position. cover. 5. To acess control box of Heater, undo the top screw and rotate heater as shown above. Series sWAVE Page 13 LT446 Nov 14, 2024...
- Page 14 Heater Installation is complete. Series sWAVE Page 14 LT446 Nov 14, 2024...
-
Page 15: Junction Box Wiring
JUNCTION BOX WIRING Conduit Hole size: 1.0in [25mm] Note: Each Element wire is labeled 1. Junction Box Outline as shown. Single phase Three phase Heater side – Factory connected. Heater side – factory connected. AWG 14-6 AWG 18-8 AWG 18-6 AWG 22-10 2.5 kW &... -
Page 16: Maintenance Instructions
MAINTENANCE INSTRUCTIONS Before cleaning, make sure the power has been turned off at the circuit breaker panel. Clean metal surfaces with a damp cloth. 1. It is important that heaters are regularly cleaned to ensure a long and efficient operating life. 2. -
Page 17: Replacement Parts
REPLACEMENT PARTS Heating elements Element Position (from electrical box) Watts/Volts 1800W, 120V RP-CE472-1 RP-CE472-2 2500W, 208V RP-CE473-1 RP-CE473-2 RP-CE473-3 2500W, 240V RP-CE474-1 RP-CE474-2 RP-CE474-3 2500W, 480V RP-CE544-1 RP-CE544-2 RP-CE544-3 2500W, 600V RP-CE501-1 RP-CE501-2 RP-CE501-3 Optional kits SS070 - Conversion kit single phase to three phase 300V. SS071B - Hanger Kit Black, Wall/Ceiling (sWAVE) SS071S - Hanger Kit S/S, Wall/Ceiling (sWAVE) Series sWAVE... - Page 18 REPLACEMENT PARTS Model Part # Description 1.8 kW/5.0 kW RP-SS061 Safety Guard - One Element Heater 3.6 kW/5.0 kW RP-SS062 Safety Guard - Two Element Heater 7.5 kW RP-SS063 Safety Guard - Three Element Heater All models SS073S / SS073B Hanger Bracket, Standard (sWave) All models CH157...
-
Page 19: Warranty Terms & Conditions
The customer warrants using the product in accordance with: • Any instructions provided to it by Superior Radiant Products from time to time. • All government and local regulations, including but not limited to all relevant electrical, environmental laws and regulations governing the installation, storage, use, handling and maintenance of the goods.
