Series UAG
Infrared Heater
service or maintenance can cause injury, death or property
damage. Read the installation, operation and service instructions
thoroughly before installing or servicing this equipment.
FOR YOUR SAFETY
If you smell gas:
1. Do not try to light any appliance.
2. Open windows.
3. Don't touch electrical switches or use any
phone in the building.
4. Extinguish any open flame.
5. Immediately call your gas supplier from a
neighbor's phone. If you can't reach your gas
supplier, call fire dept.
CONSIGNES DE SECURITE
Si vous avez une odeur de gaz:
1. N'essayez pas de lumière n'importe quel
appareil.
2. Ouvrez windows.
3. Ne touchez pas commutateurs électriques ou
utiliser téléphone cellulaire dans le bâtiment.
4. Éteindre toute flamme nue.
5. Appelez immédiatement votre fournisseur de
gaz de chez un voisin. Si vous n'arrivez pas à
joindre votre fournisseur de gaz, appelez fire dept.
Improper installation, adjustment, alteration, service or maintenance can cause injury, death or property damage.
Read the installation, operation and service instructions thoroughly before installing or servicing this equipment.
Read and thoroughly understand these Instructions before attempting any installation
Series UAG
Installation, Operation and Service Instructions
Improper installation, adjustment, alteration,
WARNING:
Owner
Retian This Manual & Ensure Available for Service.
Installer
Provide Manual to Owner upon completion of installation!
563 Barton Street, Stoney Creek, Ontario L8E 5S1
www.superiorradiant.com
Page 1
FOR YOUR SAFETY
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
CONSIGNES DE SECURITE
Il est interdit d'utiliser des liquides inflammables
ou degageant des vapeurs inflammables, a
proximites de tout appareil fonctionnent au gaz.
Nov 11, 2015
LT179
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Superior Radiant UAG series
Summary of Contents for Superior Radiant UAG series
- Page 1 Series UAG Infrared Heater Installation, Operation and Service Instructions Improper installation, adjustment, alteration, WARNING: service or maintenance can cause injury, death or property damage. Read the installation, operation and service instructions thoroughly before installing or servicing this equipment. FOR YOUR SAFETY FOR YOUR SAFETY If you smell gas: 1.
- Page 2 CAUTION: FIRE OR EXPLOSION HAZARD Maintain clearance to combustible constructions as further specified in this manual. Failure to do so could result in a serious fire hazard. Heaters should not be located in hazardous atmospheres containing flammable vapors or combustible dusts. Signs should be provided in storage areas specifying maximum safe stacking height.
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ..................................3 ..................................3 NSTALLATION ODES General Installation and Gas Codes ............................3 Parking Structures................................. 3 Gas Supply Lines ................................... 3 Electrical ....................................4 Venting ....................................4 GENERAL SPECIFICATIONS ..............................5 ....................................5 UPPLY Inlet Pressure ..................................5 Manifold Pressure - UAG .............................. -
Page 4: Introduction
Superior Radiant offers its 15 years of infrared expertise in a cost effective unitary heater design as culmination of that commitment. Series UAG models are field assembled, low intensity infrared heaters that are easy to install and maintain, and which were engineered with significant input from our customers. -
Page 5: Electrical
Introduction The appliance must be isolated from the gas piping system by closing equipment shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½ psi (305 Kpa) Electrical All heaters must be electrically grounded in accordance with the National Electric Code, ANSI/NFPA 70 in the US, and the Canadian Electric Code, CSA C22.1 in Canada, and must comply with all local requirements. -
Page 6: General Specifications
General Specifications General Specifications Gas Supply Inlet Pressure Natural Gas: Minimum 5.0" W.C. Propane Gas: Minimum 11.5" W.C. Maximum 14.0" W.C. Maximum 14.0" W.C. Manifold Pressure - UAG Natural Gas: 3.5" W.C. Propane Gas: 10.5" W.C. Inlet Connection Natural Gas or Propane: 1/2" female NPT Electric Supply 120 VAC, 60 HZ, 1 Amp: 36"... -
Page 7: Dimensional Charts
Dimensional Charts 16" CR001 6" 12" 16" 12" 32" UT002 CT001 44" 14.0" 14" 7.5" 9.0" 10' - 4" Up to 30' Figure 1: Overall Dimensional Information S.S BAFFLE SECTION ELBOW CT045 U TUBE CT010 2 - CT024 Elbow Kits COMBUSTION TUBE UT002 MITERED REFLECTOR... - Page 8 Configurations Heat Exchanger Length Rate Baffle Baffle (ft.) Model (BTU/Hr) Length (ft.) Kit P/N Minimum Maximum UAG-40 40,000 CT045 UAG-60 60,000 CT045 Table 1: Configuration Information Note: Baffle CT045 is always placed in the last section of radiant tube. The following special configurations are also approved: 60,000 BTU/Hr 15' heat exchanger with 6' Stainless steel baffle CT045 with red tab (Natural Gas Only)
-
Page 9: Clearance To Combustibles
Clearance To Combustibles A general clearance of 18” (0.5 m) in every direction is recommended (for servicing only) around each burner to ensure adequate air flow in and around the Heating System. In addition to this it is very important to observe the minimum clearance to combustibles at all times to avoid any possibility of property damage or personal injury. - Page 10 Clearance to Combustibles Table 2: Minimum Clearance to Combustibles Reflector Configurations Horizontal 2” 2" 18" 25" (46) (63) 45" 58" (114) (147) 18" 25" (46) (63) 45° Reflector Tilt 4" 4" (10) (10) 4" 4" (10) (10) 40" 50" (102) (127) 38"...
-
Page 11: Installation
Installation Installation Sequence Reflector End Cap CR002 Reflector CR001 Bracket-Reflector Reflector Overlap CR004 Approx. 8" Loose Screws Fasten Endcap Tight with Screws Screws Vent Adapter Loose CR011 Screws Bend Tab Tight over End Screws of Tube **Install Baffle(s) as required Close all chain links in the last section of tube or "S"... - Page 12 Installation Truss I-Beam Concrete Beam I-Beam Eye Bolt 12" Anchor Min. Beam Clamp 24" Min. Note: 12" Close all "S" hooks, 3/8" Min. chain links, "J" bolts Threaded and turnbuckles or any open connection. Turnbuckle Chain link Figure 4: Suspension Mechanism •...
- Page 13 Installation NSTALLATION • Always use all the hangers supplied. As a rule the combustion tube (first tube) utilizes 2 hangers and thereafter 1 hanger per 10' section. It is required that the first hanging point be 2" to 8" from the burner mounting flange, and tube weld seam must face down, refer to Figure 6 for more details.
- Page 14 Installation • Tighten the cradle loops of the first hanger with the “J-Bolt” found in the burner box, to snugly hold the combustion tube from rotating see Figure 8. Note: For all coupling joints, ensure that the tube joint is in the center of the coupling length, and that the overlap joint of the coupling is above the centerline of the tube.
- Page 15 Installation EATER AND AFFLE NSTALLATION • Locate the burner gasket provided and bolt the burner in place on the tube flange with provided hardware. Burner must never be installed in a tilted position. The sense electrode of the burner cup should be in the 12 o’clock position (Figure 9). Note: Tube Burner MUST NEVER be...
- Page 16 Installation • A general overall view of the tubes and reflector hangers are shown in Figure 11 below. Figure 11: Overall view of Tubes and Reflector Hangers Locate Tube and Vent 10' Tube Reflector Hangers Adapter every 10' thereafter. CR011 Refer to Installation Sequence for more details.
- Page 17 Installation EFLECTOR NSTALLATION • Slide a reflector section into place within the support hanger, (Figure 12) Slide Reflector through the Hanger and Reflector Support as shown. Note: Close all chain links, "J" bolts and turnbuckles or any open connection. Figure 12: Reflector Installation •...
- Page 18 Installation Note: Reflectors should overlap adjacent reflectors 4" to 6". Be sure not to tile reflector sections; that is, reflector sections must be either above both adjacent reflector sections, or below both adjacent reflector sections.. Secure every second reflector overlap together with a minimum of 2 - #8 x 3/8" inch long screws (not supplied), and secure reflector to the reflector bracket at this point by tightening down #8 x 1¼"...
- Page 19 Installation “U-T ” I LBOW AND NSTALLATION • If required by the heater layout, install 90° elbows or U-tube where indicated. Refer to Figure 15 & 16 for details. Note: Elbows or U-tubes are installed with reflectors. You must use mitered reflector kit(s) to do so.
- Page 20 Installation ITERED EFLECTOR NSTALLATION Mitered Reflector Couplings Hanger Location Get Dimension A, Cut Second Mitered Kit To Length. Fasten Corner Brackets And Reflectors To Each Other Where Possible. Figure 16: U-Tube Reflectors Installation Series UAG Page 19 Nov 11, 2015...
- Page 21 Installation & B EFLECTORS OTTOM HIELDS • If used, install side shields (reflectors) and/or bottom shield as required. Refer to Figure and Figure for details. • Side shields are 124" long. Fasten one side shield per reflector with #8 x 3/8" screws. Use three side shield brackets per side shield.
- Page 22 Installation OTTOM HIELD EFLECTOR NSTALLATION • Bottom shields need not overlap. Each 5' section is held with two support brackets (see Figure 18). Note: Close all open ended "S" hooks, chain links, and turnbuckles or any open connection. Tighten Screw Tubing Section #8 x 3/8"...
- Page 23 Installation RILLE PTIONAL Series UAG heaters are approved for the addition of Deco-Grill directly to the heater reflector. See below for details. Deco-Grille Panel Note: Close all open ended "S" hooks, chain links, and turnbuckles or any open connection. Reflector Deco-Grille Cross Strap Fasten with Screws At Every 5ft Section...
-
Page 24: Venting / Combustion Air Ducting
Venting / Combustion Air Ducting General Requirements • Refer to the National Fuel Gas Code, ANSI Z223.1 (NFPA 54) in the US and CSA B149.1 and B149.2 Installation Codes in Canada, as well as all local requirements for general venting guidance. -
Page 25: Vented Operation
Venting / Combustion Air Ducting Vented Operation In all cases, be sure vent pipes and outside air supply ducts are sealed with approved sealant, such as high temperature RTV silicone. Double wall venting (B vent) may not require sealant. Horizontal Venting •... -
Page 26: Common Horizontal Venting
Venting / Combustion Air Ducting SINGLE HEATER MULTIPLE HEATERS FOR VERTICAL VENTING REFER TO ANSI Z223.1 AND CAN/CGA B149.1 FOR VERTICAL VENTING REFER TO AND B149.2 FOR FAN ASSISTED ANSI Z223.1 AND CAN/CGA B149.1 APPLIANCES. AND B149.2 FOR FAN ASSISTED TYPE B-VENT APPLIANCES. -
Page 27: Combustion Air Supply
Venting / Combustion Air Ducting Combustion Air Supply • An outside combustion air supply is strongly recommended. • The outside air terminal must be of an approved type, and should be located at an elevation equal to or below the vent terminal elevation to prevent back-venting of flue gases into the burner compartment. -
Page 28: Gas Piping
Gas Piping General Requirements • The gas meter and service must be sufficiently large to supply gas to the connected building gas load including the heating equipment and any other gas fired equipment. Additionally, the gas distribution piping must be designed according to local and national ordinances. Generally (low pressure) systems designed with a maximum ½"... -
Page 29: Electrical Wiring
Electrical Wiring General Requirements Heaters are normally controlled by line voltage (120V) or low voltage (24V) thermostats. Line voltage thermostats are wired directly while low voltage thermostats use a relay. In all cases, heaters must be grounded in accordance with the National Electric Code, ANSI/NFPA 70 in the US, and the Canadian Electric Code, CSA C22.1 in Canada, and must comply with all local requirements. -
Page 30: Burner Operation
Burner Operation Starting Sequence of Operation • Turn the thermostat up. When the thermostat calls for heat, the blower motor will energize. • When the motor approaches nominal running RPM, the air-proving switch closes and activates the ignition module. • The ignition module, after a pre-purge period of approximately 30 seconds, energizes the igniter. Additionally, the gas valve is energized for this ignition trial period of 15 seconds. -
Page 31: Troubleshooting
Troubleshooting Blower Motor Fails to Run • Is the thermostat calling for heat? Is there 115V at the burner receptacle? • Check blower side door for seal. Repair as necessary. • Check blower for obstructions. Replace blower if necessary. No Gas Supply •... -
Page 32: Troubleshooting Chart
Troubleshooting Chart Troubleshooting Chart Series UAG Page 31 Nov 11, 2015... -
Page 33: Replacement Parts
Replacement Parts ITEM # PART # DESCRIPTION ITEM # PART # DESCRIPTION CE057 INDICATOR LIGHT CE003 FLAME SENSOR ELECTRODE CE002 SPARK ELECTRODE CE015C IGNITION MODULE CE006 IGNITION WIRE UG001P BURNER CUP CG142 UAG-HONEYWELL VALVE TRAIN REPLACEMENT KIT - NAT. BURNER CUP ASSEMBLY (C/W ELECTRODES) UG007 UAG-HONEYWELL VALVE TRAIN REPLACEMENT KIT - LPG. -
Page 34: Warranty
Warranty SERIES UAG WARRANTY The manufacturer warrants to the original owner that the product will be free of defects in material and workmanship as described below. Warranty Period Series Component Years Years Years Years Burner & Controls Hot Rolled Heat Exchanger w/o Post Purge Aluminized Heat Exchanger w/o Post Purge Hot Rolled Heat Exchanger with Post Purge Aluminized Heat Exchanger with Post Purge...
