- Page 1 Installation, Operation, and Maintenance Instructions with Troubleshooting Model: Range - Marine RTC36A-480VM RTC36B-440VM RTC36E-240VM Star Manufacturing International 10 Sunnen Drive St. Louis, MO 63143 Part No. 2M-W1094 Phone: 314-781-2777 Fax: 314-781-2714 Rev. A WWW.STAR-MFG.COM May 18, 2007...
- Page 2 THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. THE INFORMATION IN THIS MANUAL IS CRUCIAL AND MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CHAPTER PAGE 1. TABLE OF CONTENTS................3 2. READ FIRST ..................4 3. EQUIPMENT DESCRIPTION ..............6 4. UNPACKING ..................7 5. INSTALLATION ..................8 6. INITIAL START-UP.................9 7. OPERATION...................10 8. MAINTENANCE & CLEANING ...............11 9. PARTS LIST ...................14 10. WIRING DIAGRAM.................15... -
Page 4: Read First
CLOTHING. CAREFULLY READ THE WARNING AND FOLLOW THE DIRECTIONS ON THE LABEL OF THE CLEANER TO BE USED. Service on this, or any other, LANG appliance must be performed by qualified NOTICE personnel only. Consult your LANG authorized service agent directory or call the factory at 1-800-807-9054, or WWW.STAR-MFG.COM For the service agent... - Page 5 POWER SUPPLY. USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY CAUTION LANG OR THEIR AUTHORIZED DISTRIBUTORS CAN CAUSE BODILY INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT AND WILL VOID ALL WARRANTIES. MAKE SURE THE RANGE HAS BEEN PROPERLY SECURED FROM POWER WARNING BEFORE REMOVING ANY COMPONENTS.
-
Page 6: Equipment Description
The Sides, Bottom, and Rear wall are constructed stainless steel. The Range surface comes with a 24” griddle and two 9” in diameter French Plates. ITEMS 1 ea. RTC36A-480VM (Range Top) 4 ea. 4-inch legs 1 ea. Operation Manuals 1 ea. Marine Handle 4 ea. -
Page 7: Unpacking
If concealed loss or damage is discovered upon unpacking, make a written request for inspection by the carrier's agent within 15 days of delivery. All packing material should be kept for inspection. Do not return damaged merchandise to Lang Manufacturing Company. File your claim with the carrier. LOCATION Prior to un-crating, move the range as near its intended location as practical. -
Page 8: Installation
INSTALLATION THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED. DANGER FAILURE TO GROUND THE APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH. WARNING INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. -
Page 9: Initial Start-Up
INITIAL START-UP INITIAL PREHEAT Prior to putting any range into full time operation at normal cooking temperatures, it must be thoroughly dried out. Moisture absorption in the closed spaces, in the insulation, and even inside the heating elements can cause future trouble if not properly treated. Griddles To “dry out”... -
Page 10: Operation
OPERATION During the first few hours of operation you may notice a small amount of NOTICE smoke coming off the range, or out of the oven, and a faint odor from the smoke. This is normal for a new range and will disappear after the first few hours of use. -
Page 11: Maintenance & Cleaning
Locate power disconnect at source and remove power from range. LONG TERM STORAGE Secure range from power. Apply a generous amount of Lang Mfg. Prima Shine (72804-41) to the stainless steel. Apply a generous amount of Lang Mfg. Shipping Preservative Grease... -
Page 12: Trouble Shooting
MAINTENANCE & CLEANING Cont’d Service on this, or any other, LANG appliance must be performed by NOTICE qualified personnel only. Consult your LANG authorized service agent directory or call the factory at 1-800-807-9054, or WWW.STAR-MFG.COM For the service station nearest you. - Page 13 MAINTENANCE & CLEANING Cont’d CALIBRATION Calibration Check Place thermometer or thermocouple in the center of grill section. Set thermostat to 350°F. Allow the grill to preheat for at least half an hour. Note cycle on temperatures and cycle off temperatures for 3 cycles. After 3 cycles average the temperature, (Add all six temperatures and divide by 6).
-
Page 14: Parts List
PARTS LIST May 18, 2007, Rev. A RTC36A-480VM, RTC36B-440VM, RTC36E-240VM RANGE CTR TOP RTC-36 RANGE TOPS MARINE Part No. Description Application 2E-30304-09 SWTROT 6 HEAT+OFF208/240V RTC36A-480VM 2E-30304-09 SWTROT 6 HEAT+OFF208/240V RTC36E-240VM 2E-30500-08 TRM BLOCK 2 POLE SMALL 95 RTC36A-480VM 2E-30500-09... - Page 15 PARTS LIST May 18, 2007, Rev. A RCOHAP, RCOHRAP, CONVECTION OVEN FOR RANGE RCOH CONVECTION OVENS Part No. Application 2B-50200-34 RACK HALF SIZE OVENS 2B-50200-83 RACK SLIDE EHS 2E-30301-02 SWT MICRO #2HLT-5 UNIMAX 2E-30303-06 SWT TOG ON-ON DPDT BLK 2E-30304-16 CIR.BD.SWITCH 140'-450'F 2E-30500-09 TRM BLOCK 3 POLE SMALL 95...
-
Page 16: Wiring Diagram
WIRING DIAGRAM... - Page 17 PERFORMANCE OF THIS WARRANTY. sole responsibility of purchaser/user. VI. Lang Equipment is for commercial use only. If sold as a III. Lang, or an authorized service representative, will repair component of another(OEM) manufacturer’s equipment, or replace, at Lang’s sole election, and Lang Equipment,...
- Page 20 STAR MANUFACTURING 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (800) 807-9054 (314) 781-2777 Parts & Service (800) 807-9054 www.star-mfg.com...
