COUNTERTOP RANGE
Read
Do not store or use
Retain This Manual for Future Reference.
GAS
GHP2, GHP4, GHP6, GHP8
Installation and
WARNING:
This appliance shall be installed
in accordance with current regulations and
used only in well-ventilated space. Refer to
instructions before installing and using this
appliance.
In addition, there should be posted, in a
prominent location, detailed instructions to
be followed in the event the operator smells
gas. Obtain the instructions from the local
gas supplier.
Operation
Instructions
2M-W1662 Rev. A 11/08/13
Advertisement
Table of Contents
Related Manuals for Lang GHP2
Summary of Contents for Lang GHP2
- Page 1 COUNTERTOP RANGE GHP2, GHP4, GHP6, GHP8 Installation and Operation Instructions 2M-W1662 Rev. A 11/08/13 WARNING: WARNING: Improper installation, adjustment, This appliance shall be installed alteration, service or maintenance can cause in accordance with current regulations and property damage, injury or death.
- Page 2 REPAIRS SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY. NOTICE Using any part other than genuine Lang factory supplied parts relieves the manufacturer of all liability. Lang reserves the right to change speci cations and product design without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions or replacements for previously purchased equipment.
-
Page 3: Table Of Contents
Exploded View & Parts List ..... 12 - 16 NOTICE Service on this or any other Lang appliance must be performed by qualified personnel only. -
Page 4: Specifications
Height x Width x Depth combustible surface* Class Actual Shipping 15 3/8” x 11 7/8” x 28 3/16” GHP2 (39.1cm x 30.2cm x 71.6cm) 15 3/8” x 23 7/8” x 28 3/16” GHP4 (39.1cm x 60.6cm x 71.6cm) Sides & Back: 7”... -
Page 5: Equipment Description
EQUIPMENT DESCRIPTION Optional Power Burner Grate “Instant-ON” Cord On/Off Switch IL2181 Hinged Front Panel Drip Burner Lighting 4” Adj. Legs Standard Wall Knob Instructions (Tall Legs & Casters Optional) Inlet Mounting When the switch is in the “ON” position, it allows gas to flow through the solenoid On/Off Switch to the burners. -
Page 6: General Installation Data
CAUTION The Lang Chefseries® gas countertop range is equipped for the type of gas indicated on the nameplate mounted on the side panel. -IMPORTANT- Be sure to remove all paper protection and packing material from unit prior to lighting. -
Page 7: Leveling Unit
GENERAL INSTALLATION DATA (continued) LEVELING UNIT This range is supplied with 4 feet or floor stand legs which must be screwed into the body. Unit must be level. Level unit by adjusting the (4) feet which have an adjustment of. 1-3/4"... -
Page 8: Gas Piping
GENERAL INSTALLATION DATA (continued) GAS PIPING Gas piping shall be of such size and so installed as to provide a supply of gas sufficient to meet the full gas input of the appliance. If the appliance is to be connected to existing piping, it shall be checked to determine if it has adequate capacity. -
Page 9: Pilot Lighting Instructions
GENERAL INSTALLATION DATA (continued) PILOT LIGHTING INSTRUCTIONS The range is equipped with an automatic pilot/ignter with an electronic spark. Be sure all gas control knobs on the units front panel are turned OFF. Turn on main gas supply valve to unit. Turn "ON"... -
Page 10: General Operating Instructions Drip Pan
GENERAL OPERATING INSTRUCTIONS DRIP PAN The drip pan is located at the bottom of the unit, and is easily removed from the front of the unit. The pan helps collect spills, drips and catches grease. This should be checked daily and cleaned using mild detergent and warm water. -
Page 12: Exploded View & Parts List
See Detail... - Page 13 To Pilot Burner Detail...
- Page 14 PARTS LIST.. November 08, 2013, Rev A GAS HOTPLATES, MODEL GHP2, GHP4, GHP6 & GHP8 Fig No Part Number.. Description Quantity. Application GHP4ODB GHP8ODB 2R-W1664 TOP CAP - DOMED, “INSTANT ON” GHP6ODB GHP8ODA GHP2 GHP4 2F-Z0637 CASTING GHP6 GHP8 GHP2...
- Page 15 PARTS LIST.. November 08, 2013, Rev A GAS HOTPLATES, MODEL GHP2, GHP4, GHP6 & GHP8 Fig No Part Number.. Description Quantity. Application T9-143-109 GREASE TRAY ASSY-GHP2 GHP2 T9-143-209 GREASE TRAY ASSY-GHP4 GHP4 T9-143-209 GREASE TRAY ASSY-GHP6 GHP6 T9-143-409 GREASE TRAY ASSY-GHP8...
- Page 16 BUSHING HEYCO SB500-6 GHP6 GHP8 2M-60304-W1 LABEL-LIGHTING INST. GHP8 2M-61133-W1WL LABEL - W/D GHP GHP8 STAR INTERNATIONAL HOLDINGS INC. COMPANY Star - Holman - Lang - Wells - Bloomfield - Toastmaster 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (314) 678-6303 www.star-mfg.com...
