Installation, Operation, & Maintenance
Model: Chick-Fil-A CR30 (PT),
30" Range Top with Convection Oven
Lang Manufacturing Company
6500 Merrill Creek Parkway
Everett, WA 98203
Rev New
Phone: 425-349-2400 Fax: 425-349-2733
Part #
WWW.LANGWORLD.COM
© Copyright 2002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Chick-Fil-A CR30 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lang Chick-Fil-A CR30

  • Page 1 Installation, Operation, & Maintenance Model: Chick-Fil-A CR30 (PT), 30” Range Top with Convection Oven Lang Manufacturing Company 6500 Merrill Creek Parkway Everett, WA 98203 Rev New Phone: 425-349-2400 Fax: 425-349-2733 Part # WWW.LANGWORLD.COM © Copyright 2002...
  • Page 2 THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. DANGER POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH. WARNING POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH OR SERIOUS INJURY. CAUTION POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, MAY RESULT IN MINOR OR MODERATE INJURY.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS CHAPTER PAGE TABLE OF CONTENTS ..................3 READ FIRST ......................4 EQUIPMENT DESCRIPTION ................6 UNPACKING......................7 INSTALLATION ....................8 INITIAL START-UP .................... 11 OPERATION ......................12 MAINTENANCE & CLEANING PROCEDURES..........15 TROUBLE SHOOTING ..................16 PARTS LIST ......................18 WIRING DIAGRAM ....................
  • Page 4: Read First

    IMPORTANT READ FIRST IMPORTANT EACH UNIT WEIGHS 412 POUNDS (186.9 kg). FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY CAUTION APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF INSTALLATION.
  • Page 5 IMPORTANT READ FIRST IMPORTANT Service on this or any other LANG appliance must be performed by qualified personnel only. Consult your authorized service station NOTICE directory or contact the factory at 1-800-224-LANG (5264) or wwww.langworld.com for the service station nearest you.
  • Page 6: Equipment Description

    EQUIPMENT DESCRIPTION Lang Model: Lang Model: CR30 Exterior / Interior Construction The range exterior dimensions are 30” Wide (76.2 cm), 35.25” High (89.5 cm), 28.5” Deep (72.4 cm). The Top, Front, Back, and Sides are constructed of stainless steel with an aluminized bottom.
  • Page 7: Unpacking

    15 days of delivery. All packing material should be kept for inspection. Do not return damaged merchandise to Lang Manufacturing Company. File your claim with the carrier.
  • Page 8: Installation

    48” cord with a NEMA L15-30P plug. Range Voltage The Lang Model CR30 range operates as shipped on either 208V or 240V (single or three phase) and 480V (three phase). Amperages, KW rating and phasing can be found in the wiring diagram section of this manual.
  • Page 9 INSTALLATION CONT’D Reversing the door 1. Disconnect oven from power. 2. Remove the top and bottom door hinge covers (4) by removing the two 10-32 phillips head screws (8). 3. Remove the top door hinge bracket (1) from the oven by removing the two 1/4-20 phillips head screws (7).
  • Page 10 INSTALLATION CONT’D Ventilation and Clearances Standard minimum clearance from combustible construction is as follows. 4” from side 4” from back 6” from floor These ranges may be set directly, without legs, on a curbed base or non-combustible floor. If the range is set without legs on a non-combustible floor or a curbed base, maintain a 4-inch back clearance.
  • Page 11: Initial Start-Up

    INITIAL START UP Pre-Power On After the range is installed and connected to power, prior to turning on, verify the following: • The door opens and closes freely. • All racks are in the oven correctly. • All packing materials have been removed from the inside of the oven. •...
  • Page 12: Operation

    OPERATION Oven Function keys. Keys are active when a program option is displayed on Alpha-Numeric Display. display. Cancel button. When scrolling through menu’s this will allow you to back up to the previous menu. Arrow down button. In program mode this will Allows you to scroll allow you to advance to the down.
  • Page 13 Typical Operation Sequence Action Result Press the on switch. Control panel comes on, display says “LANG, Run Oven, Time Date Program. Select “Run Oven”. Display will show a list of product to choose. Select Product button next to Icon desired.
  • Page 14 OPERATION CONT’D ALWAYS KEEP THE AREA NEAR THE APPLIANCE FREE FROM CAUTION COMBUSTIBLE MATERIALS AND DO NOT OBSTRUCT FLOW OF COMBUSTION OR VENTILATION AIR. KEEP FLOOR IN FRONT OF EQUIPMENT CLEAN AND DRY. IF SPILLS CAUTION OCCUR, CLEAN IMMEDIATELY TO AVOID THE DANGER OF SLIPS OR FALLS.
  • Page 15: Maintenance & Cleaning Procedures

    Care should be taken to prevent caustic cleaning compounds from coming in contact with the blower wheel. • The oven racks, rack slides and interior may be cleaned using Lang Mfg. Foam Deluxe (72804-36) oven cleaner. • Discoloration or heat tint may be removed using Lang Mfg. Carbon Release (72804-32) oven cleaner.
  • Page 16: Troubleshooting

    TROUBLESHOOTING Symptoms What follows is a chart of Symptoms and Possible Causes to aid in diagnosing faults with the appliance. Refer to the Symptom column to locate the type of failure, then to the Possible Cause for the items to be checked. To test for a Possible Cause, refer to the Test section.
  • Page 17 TROUBLESHOOTING CONT’D Service on this, or any other, LANG appliance must be performed by qualified personnel only. Consult your authorized service station NOTICE directory or call the factory at 1-800-224-LANG (5264), or WWW.LANGWORLD.COM for the service station nearest you. BOTH HIGH AND LOW VOLTAGES ARE PRESENT INSIDE THIS...
  • Page 18: Parts List

    PARTS LIST Oven DESCRIPTION PART NO. Element EHS Oven 208 Volt 5000 Watts 11090-23 Element EHS Oven 240 Volt 5000 Watts 11090-24 Element EHS Oven 480 Volt 5000 Watts 11090-22 Motor 1/3 HP 480 Volt 2 Speed 30200-16 Motor 1/3 HP 208/240 Volt 2 Speed 30200-17 Cooling Fan 30200-46...
  • Page 19 PARTS LIST Range Top DESCRIPTION PART NO. Griddle Element, 208 Volt 11030-45 Griddle Element, 240 Volt 11030-46 Griddle Element, 480 Volt 11030-47 Hot Plate Element, 208 Volt 11010-341 Hot Plate Element, 240 Volt 11010-351 Hot Plate Element, 480 Volt 11010-361 French Plate Element, 208 Volt 11120-12 French Plate Element, 240 Volt...
  • Page 20: Wiring Diagram

    WIRING DIAGRAM 208/240 UL File# E8138 Rev. New...
  • Page 21 WIRING DIAGRAM 480V UL File# E8138 Rev. New...
