Installation,
Operation, &
Maintenance Instructions
Electric Range
Models:
R30C (AP), 30" Range Top/Convection
Oven with Accu-Plus Controls
R30C (PT), 30" Range Top/Convection
Oven with Platinum Controls
Lang Manufacturing
10 Sunnen Drive
St. Louis, MO.63143-3800
Part Number: 2M-W1092
Ph: 314-678-6315 Fax: 314-781-2714
WWW.LANGWORLD.COM
Rev. B
May 10, 2012
Advertisement
Table of Contents
Related Manuals for Lang R30C AP
Summary of Contents for Lang R30C AP
- Page 1 Maintenance Instructions Electric Range Models: R30C (AP), 30" Range Top/Convection Oven with Accu-Plus Controls R30C (PT), 30" Range Top/Convection Oven with Platinum Controls Lang Manufacturing 10 Sunnen Drive St. Louis, MO.63143-3800 Part Number: 2M-W1092 Ph: 314-678-6315 Fax: 314-781-2714 WWW.LANGWORLD.COM Rev. B...
- Page 2 THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. DANGER POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH. WARNING POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH OR SERIOUS INJURY. CAUTION POTENTIALLY HAZARDOUS SITUATION WHICH, IF NOT AVOIDED, MAY RESULT IN MINOR OR MODERATE INJURY.
-
Page 3: Table Of Contents
Table of Contents Chapter Page Table Of Contents......................... 3 Warnings, Cautions and Notices ....................4 Equipment Description........................6 Unpacking............................. 7 Installation............................. 8 Initial Start-Up ..........................11 Operation ............................12 Maintenance & Cleaning Procedures ................... 14 Troubleshooting ..........................15 Parts List............................17 Wiring Diagram .......................... -
Page 4: Warnings, Cautions And Notices
EACH UNIT WEIGHS 412 POUNDS (186.9 kg). FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED, OR EMPLOY CAUTION APPROPRIATE MATERIALS HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO THE PLACE OF INSTALLATION. ANY STAND, COUNTER OR OTHER DEVICE ON WHICH RANGE WILL BE CAUTION LOCATED MUST BE DESIGNED TO SUPPORT THE WEIGHT OF THE... - Page 5 Service on this or any other Lang appliance must be performed by qualified personnel only. Consult your Lang Authorized Service Agent NOTICE Directory. You can call our toll free number 314-678-6315 or visit our website for the service agent nearest you.
-
Page 6: Equipment Description
Equipment Description Exterior/Interior Construction The range exterior dimensions are 30" wide (76.2 cm), 35.25" high (89.5 cm), 28.5" deep (72.4 cm). The top, front, back, and sides are constructed of stainless steel with an aluminized bottom. The oven door comes standard with a window. The door handle is constructed of Polycarbonate. -
Page 7: Unpacking
If concealed loss or damage is discovered upon unpacking, make a written request for inspection by the carrier's agent within 15 days of delivery. All packing material should be kept for inspection. Do not return damaged merchandise to Lang Manufacturing Company. File your claim with the carrier. Location Prior to un-crating, move the range as near to its intended location as practical. -
Page 8: Installation
48" cord with a NEMA L15-30P plug. Range Voltage The Lang Model R30C range operates as shipped on either 208V or 240V (single or three phase) and 480V (three phase). Amperages, KW rating and phasing can be found in the wiring diagram section of this manual. - Page 9 Installation cont’d Reversing the door 1. Disconnect oven from power. 2. Remove the top and bottom door hinge covers (4) by removing the two 10-32 Phillips head screws (8). 3. Remove the top door hinge bracket (1) from the oven by removing the two 1/4- 20 Phillips head screws (7).
- Page 10 Installation cont’d Ventilation and Clearances Standard minimum clearance from combustible construction is as follows. 4" from side 4" from back 6" from floor These ranges may be set directly, without legs, on a curbed base or non-combustible floor. If the range is set without legs on a non-combustible floor or a curbed base, maintain a 4-inch back clearance.
-
Page 11: Initial Start-Up
Initial Start Up Pre-Power On After the range is installed and connected to power, prior to turning on, verify the following: The door opens and closes freely. All racks are in the oven correctly. All packing materials have been removed from the inside of the oven. All shipping preservatives have been removed from the range top surface. -
Page 12: Operation
Operation Oven Typical Operation Sequence (Platinum) Control Indicator Control panel comes on; "LANG, Run Press the On/Off switch. Oven, Time Date Program is displayed Select "Run Oven". Products that can be baked are displayed Select product button next to Icon desired. -
Page 13: Range Top
Operation cont’d Hints & Suggestions Convection ovens constantly circulate air over and around the product. This strips away the thin layer of moisture and cool air from around the product allowing heat to penetrate more quickly. Cooking times can be shortened and cooking temperatures can be reduced. To convert standard deck oven recipes, reduce the temperature 50°F and the time by 25%. -
Page 14: Maintenance & Cleaning Procedures
Maintenance & Cleaning KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER SPRAY OR WARNING HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC. MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE SHIELD AND CAUTION PROTECTIVE CLOTHING. -
Page 15: Troubleshooting
Troubleshooting Oven Symptoms Troubleshooting is not an exact science. Several factors may play a part in why your machine is not operating correctly. The following symptoms are a general idea of what may be causing the malfunction and should not be considered the complete answer to the situation that you have with your machine. - Page 16 Troubleshooting cont’d Service on this or any other Lang appliance must be performed by qualified personnel only. Consult your Lang Authorized Service Agent NOTICE Directory. You can call our toll free number 314-678-6315 or visit our website for the service agent nearest you.
-
Page 17: Parts List
Parts List March 12, 2008, Rev. B Oven Model: RCOHRAP208KR, RCOHAP, RCOHRAP_Electric Convection Oven Part No. Description Application 2A-72500-05 LEG 4 W/BOLT DOWN ADJ RCOHRAP-480M 2B-50200-34 RACK HALF SIZE OVENS 2B-50200-83 RACK SLIDE EHS 2E-30301-02 SWT MICRO #2HLT-5 UNIMAX 2E-30303-06 SWT TOG ON-ON DPDT BLK 2E-30304-16 CIR.BD.SWITCH 140'-450'F... - Page 18 Parts List October 8, 2012, Rev. B Range Top Model: R30A, B, C, D, E, F, G Electric Range Top Part No. Description Application 2B-50200-34 RACK HALF SIZE OVENS R30C-APD-208 2B-50200-83 RACK SLIDE EHS R30C-APD-208 2E-30301-02 SWT MICRO #2HLT-5 UNIMAX R30C-APD-208 2E-30303-06 SWT TOG ON-ON DPDT BLK...
-
Page 19: Wiring Diagram
RT30B-480VM, RT30D-208V & VM, 240V & VM, 440VM, 480V 2P-51003-01 SPRING LEAF FOR EGO TK & VM, R30C-APF-208, RT30G-208V & VM, 240V, 480V 2P-72900-04 CSTER RIGID 3,5/16W TRD. R30C-APD-208 2P-72901-17 CSTR SWVL W/BRK 35/16TRD R30C-APD-208 2Q-71301-04 WINDOW ASSY 9-5/8X16-5/8 R30C-APD-208 2R-70701-28 KNB BLK 1/4BUSH2SETSCW@90 R30C-APD-208... - Page 20 R30S-ATB RT30A 14 15 RT30D RT30C = Suggested Spare Parts Model: RT30 Range Top Controls SK2338 Rev. - 12/19/07...
- Page 21 RT30F RT30E RT30H RT30G = Suggested Spare Parts Model: RT30 Range Top Controls SK2339 Rev. A 12/11/09...
- Page 22 PARTS LIST October 4, 2012, Rev - Model: RT30A, B, C, E, F, G, H, Commercial & Marine 30” Range Top Control Panel Fig No Part No Description Description RT30B, RT30E, RT30G P9-CR30-750 CONDUIT ASSY - SPEED UNIT RT30A RT30B, RT30E P9-CR30-752 CONDUIT ASSY - HOT TOP RT30C, RT30D RT30E, RT30G P9-CR30-751...
- Page 23 SK2613 Rev. - 7/23/12 MODEL: RTI30 Induction Rangetop...
- Page 24 PARTS LIST July 24, 2012 Model: RTI30 30” Induction Range Top Fig No Part No Description P9-CR30-621 TOP GLASS ASSY-30” INDUCTION PS-71300-21 GLASS-INDUCT 30” REPLACMENT P9-CR30-623 TOP GLASS ASSY WELD-30” P9-RF21-783 CLIP - GLASS INDUCTION 2C-20102-08 SCRW PHD ST 8-32X.375 P9-CR30-622 INSUL-MANNIGLAS 30”INDUCT P9-RF21-727 INDUCTION MODULE ASSY 2N-11120-26...
