DKM KVM Extender TX/RX Interface Modules
Increase the distance between a source (computer,
CPU) and its console (keyboard, mouse, and other
peripheral devices).
Models available for CATx or fiber.
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
Customer
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
Support
www.blackbox.com • info@blackbox.com
Information
ACX1MT Series
ACXMODH2*
ACX1MR Series
ACXMODH4*
ACXMODH6*
ACXMODH21*
