WARRANTY
YEARS
ERB112BTE
150MM BENCH GRINDER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERB112BTE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Erbauer ERB112BTE

  • Page 1 WARRANTY YEARS ERB112BTE 150MM BENCH GRINDER...
  • Page 3 Congratulations on your purchase of a quality power tool from Erbauer (UK) Ltd. This product should give you reliable service but for your peace of mind this power tool does carries a 24-month guarantee, the terms of which are detailed below.
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS Warning! When using electric tools basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury including the following. Read all these instructions before attempting to operate this product and save these instructions.
  • Page 5: Additional Safety Rules For Bench Grinders

    15. Disconnect tools. When not in use, before servicing and when changing accessories such as blades, bits and cutters, disconnect tools from the power supply. 16. Remove adjusting keys and wrenches. Form the habit of checking to see that keys and adjusting wrenches are removed from the tool before turning it on.
  • Page 6 11. Always allow a new wheel to run for a few minutes at full speed before using it. Stand to one side at start up. 12. Check that the wheel rotates freely each time before start up. 13. Do not use the grinder unless all the guards are properly fitted and secure. 14.
  • Page 7: Component List

    COMPONENT LIST 1.Base 2.On/Off switch 3.Adjustable work rest 4.Grinding wheel (Pre-fitted ) 5.Spark arrester 6.Eye shield 7.Wheel dressing set 8.Work light 9.Magnifier eye shield 10.Outer guard 11.Tool storage 150MM BENCH GRINDER...
  • Page 8: Technical Data

    TECHNICAL DATA Rated voltage 230V-240V~50Hz Rated power 370W(S2:30min) Rated no load speed 2850min Wheel diameter 150mm Wheel size Ø150mm x 20mm x Ø12.7mm Wheel grit Left 36#/Right 60# Machine weight 11kg NOISE DATA Sound power level 91.6dB(A) with grinding wheel 89.6dB(A) with finishing wheel Sound pressure level 67 .5dB(A) with no load...
  • Page 9 ASSEMBLY NOTE: Before using the tool, read the instruction book carefully. Caution! During use, it is important not to overload the grinder.The grinder should run at close to full speed. If you are applying too much pressure, the grinder will start to slow Fig.A down.
  • Page 10 points and tighten firmly to secure the eye shield in place. Note: The Magnifier eye shield features a mag- nifying glass incorporated into the design to pro- vide greater visibility and improved accuracy. 3. Fitting the work rests (See Fig.E) The work rests are required for each high speed grinding wheel to assist in grinding operation.
  • Page 11: Operating Instructions

    OPERATING INSTRUCTIONS Important: Ensure that the eye shields, spark arresters and the work rests are fitted and correctly adjusted and that you are wearing safety gear including eye, hearing and breathing protection before us- ing the tool. Fig.F Warning: Never attempt to grind Magnesium.
  • Page 12: Maintenance

    3. Changing the grinding wheels (See Fig. G, H) Important: Remove the plug from the socket before changing a wheel. 1) Remove both work rests and spark arresters. 2) Remove the outer guards by loosening three retaining screws. See Fig. G 3) Using two spanners (not supplied), loosen the grinding wheel retention nuts.
  • Page 13 fortable and most effective angle to suit the task being performed. • As the wheels wear, the spark arresters must be adjusted to ensure that the distance from its bot- tom edge to the wheel surface is not more than 2mm.
  • Page 14: Troubleshooting

    TROUBLESHOOTING 1. Grinder will not start If your grinder will not start check the power at the mains plug. 2. Wheel wobbles or vibrates Check that the lock-nut is tight. Check that the wheel is correctly located on the shaft and locat- ing washer.
  • Page 15: Plug Replacement

    PLUG REPLACEMENT The fuse in the main plug of your power tool should always be replaced with one of identical rating. Check the voltage given on your power tool matches the supply voltage. The power tool is supplied with a fitted plug, however if you should need to fit a new plug follows the instruction below.
  • Page 17: Declaration Of Conformity

    Declaration of Conformity We, Importer Erbauer (UK) Ltd BA22 8RT Declare that the product 150MM BENCH GRINDER ERB112BTE Complies with the essential health and safety requirements of the following directives: Machinery Directive 98/37/EC Low Voltage Directive 2006/95/EC Electromagnetic Compatibility Directive 2004/108/EC Restrictions of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment 2002/95/EC Standards and technical specifications referred to:...
  • Page 19 150MM BENCH GRINDER...
