Technical Specifications - Kramer VM-1H4C User Manual

8

Technical Specifications

INPUTS:
OUTPUTS:
BANDWIDTH:
COMPLIANCE WITH HDMI
STANDARD:
INDICATOR LEDs:
POWER SOURCE:
OPERATING
TEMPERATURE:
STORAGE TEMPERATURE:
HUMIDITY:
DIMENSIONS:
WEIGHT:
ACCESSORIES:
OPTIONS:
10
1 HDMI connector
1 IR on a 3.5mm mini jack
4 TP on RJ-45 connectors
Supports up to 4.95Gbps (1.65Gbps per graphic channel)
Supports HDMI and HDCP
Power, INPUT, OUTPUT 1, 2, 3 and 4
12V DC, 2A
0° to +55°C (32° to 131°F)
–45° to +72°C (–49° to 162°F)
10% to 90%, RHL non-condensing
21.5cm x 16.2cm x 4.4cm (8.5in x 6.38in x 1.7in) W, D, H
0.9kg (1.98lbs) approx.
Power supply
HDMI/HDMI male to male cables, RK-1 19" rack adapter
VM-1H4C – Technical Specifications
