Related Manuals for King Pigeon K2
Summary of Contents for King Pigeon K2
- Page 1 An Advanced Programmable Multifunctional GSM Security Alarm GSM Auto-Dialer GSM SOS Call System GSM Alarm Panel In The Worldwide! User Manual Ver 1.1 Date Issued: 2013-02-01 All rights reserved.
-
Page 2: Table Of Contents
6.11Setup the Arm Delay Time---------------------10 This handbook has been designed as a guide to the installation and operation of K2 GSM Alarm&Dialer. Statements contained in the handbook are general guidelines only and in no way are designed to supersede the instructions contained with other products. -
Page 3: Brief Introduction
SMS Commands, or remotely switch the K2 to arm or disarm with free call from mobile phone, or remotely call in the K2 to two way voice combination, or send SMS Command to request the K2 call back to create two way voice communication. -
Page 4: Standard Packing List
GSM SMS Alarm & Dialer GSM SOS Call System! 3. Standard Packing List Package A Package B Item Item GSM Alarm Panel GSM Alarm Panel Wireless Fall Down Detector Wireless Door Contact AC/DC Adaptor Wireless PIR Motion Detector User Manual Remote Control AC/DC Adaptor User Manual... -
Page 5: Installation And Connection Diagram
5.2 Contacting the Siren, hooter The user can connect one 9~12V rated siren, or hooter to the K2 Panel’s siren output, once alarm occurrence, this output ports will start the siren or hooter to make sounds. The positive of the siren connect to the Siren+ port, and the negative of the siren contact to the Siren–... -
Page 6: Switching On/Off The K2
ENGLISH INPUT METHOD and CAPS LOCK. If the password incorrect will not return any SMS. 9. When power on the K2, will alert Di sound once, and all zones’ LED will turn on once, then the LED which registered wireless sensor already will turn on once more. -
Page 7: Setup New Password
Tips: When any number with this value call in the K2, the K2 will change from Stay to Armed or Armed to Stay, if the K2 in Disarmed mode, then the first time call in will change theK2 to Stay mode. -
Page 8: Inquiry The Authorized Number
K2 will performance when this zone activated. =0, stands for entrance, when armed the K2, this zone will delay 30 seconds to enter into Armed mode, for leaving the home or office. When come back the home or office, will delay 20 seconds to alarm in order... -
Page 9: Inquiry The Zone Attribute
=5, stands for 24hours emergency silent zone. In any mode if triggered will cause alarm immediately, the siren will not sound. =6, stands for Armed Button, trigged it to make the K2 change to Arm Mode. =7, stands for Stay Button, triggered it to make the K2 change to Stay Mode. -
Page 10: Setup The Arm Delay Time
If enable this function, when the Authorized Number that Function 2 Code=1 (can dial in to change the status from Stay to Arm) call in the K2, will send SMS to the 1st Authorized Number. If any other number armed or disarmed the K2, it... -
Page 11: Setup Automatically Report Status Function
6.16 Setup Automatically report Status function pwd+T+xx+# XX=00~99, unit is hour, stands for the interval time to report the K2 status to the first SMS Alert Number. default is 00, means disable report function. If no SMS number, this function will be invalid. The return SMS is the same as by 8.4 Inquiry Status and GSM Module IMEI Code... - Page 12 Please see the Affix table. 2) Read the Switch-Combination-Zone Number Corresponding Table The K2 with fixed switch-combination positions for different wireless detectors and wireless remote controls, please see Switch Positions-Zone Number Corresponding Table Structure and Switch-Combination -Remote Control Corresponding Table.
- Page 13 ,03 should be setup as: 3) Enter Leaning Mode Please press the Learn button, and switch on the K2, after switch on the K2, will alert Di once, then after enter learning mode, will alert Di—Di two sounds, total 3 Di sounds(about 5 Seconds), it being learning mode, then loose the button.
- Page 14 When the wireless PIR Motion detection is PIR-100B, please remember setup the PIR-100B to Test Mode while learning to the K2, after learned to the K2, then please setup to Normal Mode by change the Black PIN Jumpers in the PCB, please see the PIR-100B user manual.
-
Page 15: Operating Instructions
Disarmed: Except the 24 Hours emergency zones triggered will cause alarm, all of the other zones triggered will not cause alarm. Usually for maintain or other special requirements. Alarm Occurrence When alarm occurrence, the K2 will send out Alarm SMS Content firstly, then automatically dial the authorized G S M A l a r m... -
Page 16: Operation By Remote Controls
GSM SOS Call System! numbers one by one, if picked up the call, the K2 will stop to sound and enter to listen mode, can not speak. If nobody picked up or rejected, the K2 will dial all of the authorized numbers 3 times in cycle then stop to dial any more. -
Page 17: Sms Commands For Arm Or Disarm Or Switch On /Off Siren
This function is very useful while you leave or come back home. 8.3 SMS Commands for Arm(Away) or Disarm or Switch On/Off Siren. The User can Arm/Disarm/Switch on or off the siren by sending SMS to the K2. The SMS Commands are below: Notice: The system will carry out the commands immediately (with no delay) after the K2 receive this SMS command. -
Page 18: Android Apps Instructions
11. Affix Table Table 1. K2 Installation Schedule Before install the K2, please write down the installation plan firstly, it is very useful for saving your test and installation time. After installed successful, then tear down this Schedule for review in further. - Page 19 Alarm! Smoke Detector Alarm! Water Leakage Alarm! Gas Leakage Alarm! Panic Help Alarm! Emergency Silent Alarm! K2 Authorized Number Schedule SIMCard Number in the K2: ___________________ Authorized Type Serial User Name Phone Number Alert when Alarm Occurrence Access the K2 Number SMS&Call...
- Page 20 GSM SMS Alarm & Dialer GSM SOS Call System! Table 2. K2 Program and Operation SMS Command List K2 SMS Command List(Caps Lock) S.N. Function Description SMS Command Format Example Arm(Away) pwd+AA 1234AA (Password is 1234) pwd+BB 1234BB (Password is 1234)
