- Page 1 Take a photo of intruder to your mobile phone! GSM MMS Alarm System User Manual S3622 Ver 1.10 Date Issued: 2008-04-18 All rights reserved by King Pigeon Hi-Tech.Co.,Ltd. www.GSMalarmsystem.com...
-
Page 2: Table Of Contents
Quality Warranty -----------------------------------15 This handbook has been designed as a guide to the installation and operation of S3622 GSM MMS Security Alarm System. Statements contained in the handbook are general guidelines only and in no way are designed to supersede the instructions contained with other products. -
Page 3: Brief Introduction
GSM Communication network and IR Cameras. When any sensor triggered, it will send the photo to users cellphone through GPRS. Also, if the user want to require a photo, he can send a command to the S3622, Then it will reply a photo immediately. - Page 4 Http://www.GSMalarmsystem.com Out 1 Output Relay 1, when it flash, means the relay 1 close. Out 2 Output Relay 2, when it flash, means the relay 2 close. Reversed for furture Out 3 Signal Control Unit Status. 1. Power on it, Led will on for 20S then starting to register the GSM Network, 20S later the LED color will change to Orange, means reading the SIMCard;...
-
Page 5: Functions And Features
Http://www.GSMalarmsystem.com 4. Functions&Features 1) Tri_band 900/1800/1900MHZ; 2) 2 Output relays, (10A 220VAC; 10A 30VDC)which can remotely control other electrical appliances; 3) 3 Wired zones and 8 Wireless Zones; 4) Can arm or disarm by SMS or remote control; 5) Equiped with CCD camera with infrared led; 6) Automaticed send SMS Alert to pre-set cellphone when it triggered;... -
Page 6: Installation
Http://www.GSMalarmsystem.com 14) The IR Camera supports Motion detection funtion; 15) Standby internal rechargeable battery which can last 12 hours; 16) Adjustable photo size, optional size rang is: 160×128, 320×240, 640 480; 17) More programmable, e.g.: if send SMS, or turn on Siren or dial preset alarm number and so on;... - Page 7 Http://www.GSMalarmsystem.com In some circumstances an Infrared beam fence is more appropriate than magnetic sensors. i.e. veranda, picture window balcony, boundary wall e.t.c. Wired or wireless glass break sensor can also be used (see below) For a Scrolling Steel Door, a special Wireless Scroll Steel Door magnetic sensor, must be used due to interference of the wireless signal caused by the steel door.
- Page 8 Http://www.GSMalarmsystem.com Scroll Steel Door 5.5 Install the wireless PIR Motion Sensor The PIR sensor will detect a person since human temperature is different to ambient temperature. When triggered, the PIR will signal the Control Unit. Apply the detection area illustration below when installing. Wireless curtain sensor, detection area illustration below: King Pigeon Hi-Tech.
- Page 9 Http://www.GSMalarmsystem.com 5.6 Install other sensors For smoke, you can use wireless smoke sensor, for gas leakage detection, you can install gas leakage sensor below For temperature, you can install the temperature sensor below: 5.7 Install the Control Unit In order to avoid destruction of the Control Unit by intruders, please install it in a concealed location, convenient to the operator.
-
Page 10: Settings
MMS and change the language, the default setting is China Mobile Ltd and the language is Chinese , and the deflaut password is 123456. The S3622 can be set by SMS or call the SIMCard. The commands please help to see the below table. Commands... - Page 11 Http://www.GSMalarmsystem.com 123456 is the password. 1#0# Disarm 2#*# Require photo, *=1~20, means can Want to get 6photos, require 1~20 photos in one time. edit a SMS: 123456#2#6# , then send to the Control Unit. 3#1# Start the Siren immediately 3#0# Stop the siren immediately 4#1# Start to listen into the house...
- Page 12 Http://www.GSMalarmsystem.com Camera, will alarm. (Deflaut) 24#0# Set IR Camera Motion detect Disable. 27#*# Adjust the IR Camera’s Motion detect level of sensitivity, value is 1-100, default is 15, 1 is the best senstivity level. 31#*# Set the password, default is “123456”, * means password.
- Page 13 Http://www.GSMalarmsystem.com 31charaters 80## Inquire the pre-set SMS 81#*# Set wired sensor 1’s alert SMS * means content, the content. content should not more than 20 82#*# Set wired sensor 2’s alert SMS characters. content. 83#*# Set wired sensor 3’s alert SMS content.
-
Page 14: Operating Instructions
Http://www.GSMalarmsystem.com 5. Set MMS in your local, for the MMS informations, please help to connect your GSM SIMcard provider. For S3622, the MMSC Port Number must be 9021. the format is below: 123456#41# Access Point Name#42#Username #43#Password#44# MMS gateway address #45# MMSC port number #46# MMS Message Server URL # E.g.: Orange MMS settings (the below Orange MMS information from the... -
Page 15: Technical Specifications
Http://www.GSMalarmsystem.com 7.1 Arm or Disarm Press the button “ ” on the remote control, the Control Unit enters arm status, the Signal LED will be Red color. Press the button “ ” on the remote control, the Control Unit disarms immediately. -
Page 16: Maintenance
Http://www.GSMalarmsystem.com 9.2 Do not install the system in close vicinity with objects that generate strong interference, such as TV set and computer. 9.3 Install the system in a hidden place. 9.4 Avoid getting water into the Control Unit. 9.5 Have a secure connection to the main power supply and provide good ventilation.. -
Page 17: King Pigeon Hi-Tech. Co., Ltd. Page Of 17 Ver 1.1 File No
Http://www.GSMalarmsystem.com The End! Any questions please help to contact us feel free. Email Us: Sales@Kingpigeon.com.cn Http://www.GSMalarmsystem.com Http://www.Kingpigeon.com.cn Warranty Card Model ______________ Product ID ___________ Date of Purchase__________________ Date of Production___________________ Maintenance Record __________________________________________________ __________________________________________________ __________________________________________________ Dealer _____________________________ King Pigeon Hi-Tech. Co., Ltd. Page of 17 Ver 1.1 File No.: 36220010...
